AMD's Upcoming Mobile Rembrandt APU Makes an Early Appearance

Joined
Nov 11, 2004
Messages
10,986 (1.72/day)
Location
Formosa
System Name Overlord Mk MXVI
Processor AMD Ryzen 7 5800X
Motherboard Gigabyte X570 Aorus Master
Cooling Corsair H115i Pro
Memory 32GB Viper Steel 3600 DDR4 @ 3800MHz 16-19-16-19-36
Video Card(s) Gigabyte RTX 2080 Gaming OC 8G
Storage 1TB WD Black NVMe (2018), 2TB Viper VPN100, 1TB WD Blue 3D NAND
Display(s) Asus PG27AQ
Case Corsair Carbide 275Q
Audio Device(s) Corsair Virtuoso SE
Power Supply Corsair RM750
Mouse Logitech G502 Lightspeed
Keyboard Wooting Two
Software Windows 10 Pro
Benchmark Scores https://valid.x86.fr/33u9si
If you've been waiting for more details about AMD's next mobile platform, then you're in luck, as the motherload has dropped today, with lots of details about the new Rembrandt APU's that are launching next year. Not only has a picture of the first motherboard, with adhering laptop showed up, but we also have a mostly complete block diagram and a list of expected SKU's, even though not all SKU models are revealed as yet.

AMD's Rembrandt APU will be its first APU with PCIe 4.0 support, which in itself might not be worth the wait, but if paired with the right GPU, this might help increase the performance somewhat compared to the previous generation of APUs from AMD. The bigger news is USB4 support, plus a new GPU which we so far don't know too much about, but it's speculated that it'll be called Radeon RX 680M and should offer 12 compute units. DDR5 memory support is also expected, so Rembrandt clearly has a new memory controller, since the APU is still based on the Zen 3 architecture.




It looks like we can expect as many as 24 different SKU's, with a TDP of either 28 or 45 Watts for now, split between two different packaging types, FP7 and FP7r2. The first three models that have been revealed are the Ryzen 7 6800H with a 4.7 GHz boost clock, the Ryzen 9 6900HX with a 4.9 GHz boost clock and the Ryzen 9 6980HX with a 5 GHz boost clock. All three CPUs are said to have eight cores and 16 threads. The leaked notebook is the Alienware m17 R5 from Dell and it's said to sport up to a Radeon RX 6850M XT GPU with 12 GB of GDDR6 memory, in addition to its Ryzen 9 6980HX APU. The motherboard picture is said to have a Radeon RX 6700M with 10 GB of GDDR6, as it's from a lower-end model. It looks like we have some competition to look forward to next year between AMD and Intel in the mobile space, that is if the current shortages of everything doesn't ruin it.

View at TechPowerUp Main Site

Joined
Jan 14, 2019
Messages
2,407 (1.97/day)
Location
Midlands, UK
System Name Nebulon-B Mk. 3
Processor Intel Core i7-11700 @ ASUS Optimized (200 W)
Motherboard ASUS TUF Gaming B560M-Plus (WiFi)
Cooling be quiet! Silent Loop 2 280 mm
Memory 2x 16 GB Kinston Fury Beast RGB 3200 MHz
Video Card(s) EVGA GeForce RTX 2070 Black 8 GB @ 200 W
Storage 1 TB Crucial P5, 1 TB Crucial P5 Plus
Display(s) Samsung C24F390, 7" Waveshare touchscreen
Case Corsair Crystal 280X black
Audio Device(s) Genius SP-HF160, AKG Y50
Power Supply Seasonic Prime Ultra Platinum 550W
Mouse Cherry MW 8 Advanced
Keyboard MagicForce 68
Software Windows 10 Pro
Benchmark Scores Cinebench R23 multi core: 13,800, single core: 1,500. Superposition 1080p Extreme: 5,250.
"we can expect as many as 24 different SKU's" - Is it April 1st? :wtf:

Joined
Nov 4, 2005
Messages
11,105 (1.84/day)
System Name MoFo 2
Processor AMD PhenomII 1100T @ 4.2Ghz
Motherboard Asus Crosshair IV
Cooling Swiftec 655 pump, Apogee GT,, MCR360mm Rad, 1/2 loop.
Memory 8GB DDR3-2133 @ 1900 8.9.9.24 1T
Video Card(s) HD7970 1250/1750
Storage Agility 3 SSD 6TB RAID 0 on RAID Card
Display(s) 46" 1080P Toshiba LCD
Case Rosewill R6A34-BK modded (thanks to MKmods)
Audio Device(s) ATI HDMI
Power Supply 750W PC Power & Cooling modded (thanks to MKmods)
Software A lot.
Benchmark Scores Its fast. Enough.
"we can expect as many as 24 different SKU's" - Is it April 1st? :wtf:
I’m sure they will have some with better performing GPU or CPU in each power budget, 45W to 15W and then maybe a few lower core count 15W or less for ultra thin platforms, then probably some 45W with beefier GPUs to handle integrated signage and things like multiple casino machines rendering, a whole set of slot machines ran by one APU to save money and power.

Joined
Aug 23, 2013
Messages
352 (0.11/day)
I wasn't expecting to see Navi Apu before Zen4. So this is a surprise. But maybe it's thanks to the Steam Deck.

Joined
Sep 17, 2014
Messages
16,461 (5.88/day)
Location
The Washing Machine
Processor i7 8700k 4.6Ghz @ 1.24V
Motherboard AsRock Fatal1ty K6 Z370
Cooling beQuiet! Dark Rock Pro 3
Memory 16GB Corsair Vengeance LPX 3200/C16
Video Card(s) MSI GTX 1080 Gaming X @ 2100/5500
Storage Samsung 850 EVO 1TB + Samsung 830 256GB + Crucial BX100 250GB + Toshiba 1TB HDD
Display(s) Gigabyte G34QWC (3440x1440)
Case Fractal Design Define C TG
Audio Device(s) Situational :)
Power Supply EVGA G2 750W
Mouse XTRFY M42
Keyboard Lenovo Thinkpad Trackpoint II
Software W10 x64
Joined
Nov 11, 2004
Messages
10,986 (1.72/day)
Location
Formosa
System Name Overlord Mk MXVI
Processor AMD Ryzen 7 5800X
Motherboard Gigabyte X570 Aorus Master
Cooling Corsair H115i Pro
Memory 32GB Viper Steel 3600 DDR4 @ 3800MHz 16-19-16-19-36
Video Card(s) Gigabyte RTX 2080 Gaming OC 8G
Storage 1TB WD Black NVMe (2018), 2TB Viper VPN100, 1TB WD Blue 3D NAND
Display(s) Asus PG27AQ
Case Corsair Carbide 275Q
Audio Device(s) Corsair Virtuoso SE
Power Supply Corsair RM750
Mouse Logitech G502 Lightspeed
Keyboard Wooting Two
Software Windows 10 Pro
Benchmark Scores https://valid.x86.fr/33u9si
Joined
Oct 12, 2005
Messages
412 (0.07/day)
I can't wait to see the benchmark of a Navi APU paired with DDR5.

A faster architecture with way more memory bandwidth might finaly mean acceptable 1080p performance in newer game. My hope aren't very high but i am very interested to see

As for the 24 SKUs, i wonder if there are different sky for LPDDR5 and DDR5 too

Joined
Nov 11, 2004
Messages
10,986 (1.72/day)
Location
Formosa
System Name Overlord Mk MXVI
Processor AMD Ryzen 7 5800X
Motherboard Gigabyte X570 Aorus Master
Cooling Corsair H115i Pro
Memory 32GB Viper Steel 3600 DDR4 @ 3800MHz 16-19-16-19-36
Video Card(s) Gigabyte RTX 2080 Gaming OC 8G
Storage 1TB WD Black NVMe (2018), 2TB Viper VPN100, 1TB WD Blue 3D NAND
Display(s) Asus PG27AQ
Case Corsair Carbide 275Q
Audio Device(s) Corsair Virtuoso SE
Power Supply Corsair RM750
Mouse Logitech G502 Lightspeed
Keyboard Wooting Two
Software Windows 10 Pro
Benchmark Scores https://valid.x86.fr/33u9si
I can't wait to see the benchmark of a Navi APU paired with DDR5.

A faster architecture with way more memory bandwidth might finaly mean acceptable 1080p performance in newer game. My hope aren't very high but i am very interested to see

As for the 24 SKUs, i wonder if there are different sky for LPDDR5 and DDR5 too
Not when it comes to these, expect LPDDR5 on the U SKUs, which might have better GPUs too, just as with the current models.

Joined
Apr 18, 2019
Messages
161 (0.14/day)
Location
Olympia, WA
System Name Sleepy Painter
Processor AMD Ryzen 5 3600
Motherboard Asus TuF Gaming X570-PLUS/WIFI
Cooling FSP Windale 6 - Passive
Memory 2x16GB F4-3600C16-16GVKC @ 16-19-21-36-58-1T
Video Card(s) MSI RX580 8GB
Storage 2x Samsung PM963 960GB nVME RAID0, Crucial BX500 1TB SATA, WD Blue 3D 2TB SATA
Display(s) Microboard 32" Curved 1080P 144hz VA w/ Freesync
Case NZXT Gamma Classic Black
Audio Device(s) Asus Xonar D1
Power Supply Rosewill 1KW on 240V@60hz
Mouse Logitech MX518 Legend
Keyboard Red Dragon K552
Software Windows 10 Enterprise 2019 LTSC 1809 17763.1757
What's the deal with the Dual 10Gb (Linux only)?

Joined
Jul 5, 2013
Messages
18,865 (5.82/day)
Location
USA
The leaked notebook is the Alienware m17 R5 from Dell and it's said to sport up to a Radeon RX 6850M XT GPU with 12 GB of GDDR6 memory
I count 5 VRAM chips in that photo. How do you get 12GB from 5 chips? Something doesn't add up...

Last edited:
Joined
Jan 1, 2021
Messages
26 (0.05/day)
Location
France
Processor FX 8350 4,72GHz, 230Mhz FSB
Motherboard MSI 990FXA GD80
Cooling Hyper212Evo with 2x2400RPM Silverstone Push&Pull
Memory 4x4Go Kingston 1600Mhz @1800Mhz 1.65v
Video Card(s) Asus Strix 980 -72mv @90% PowerLimit, stock clock
Storage 2Tb+1Tb Toshiba HHDs + Crucial mx500 250go
Case Zalman Z11+ with 8 fans
Power Supply Coolermaster MWE bronze 650w
Benchmark Scores Cinebench R15: 748cb
Let's hope for a proper Dual graphics support.
If so, having a full amd ecosystem would be a huge perk as the iGPU will be used for lighter loads and the discrete GPU will back it up with horsepower when needed.
Intel iGPU + Nvidia GPU can switch between them depending on the load but cannot work together, whereas dual graphics would do exactly this.

Joined
Feb 20, 2019
Messages
4,108 (3.47/day)
System Name Bragging Rights
Processor Atom Z3735F 1.33GHz
Motherboard It has no markings but it's green
Cooling No, it's a 2.2W processor
Memory 2GB DDR3L-1333
Video Card(s) Gen7 Intel HD (4EU @ 311MHz)
Storage 32GB eMMC and 128GB Sandisk Extreme U3
Display(s) 10" IPS 1280x800 60Hz
Case Veddha T2
Audio Device(s) Apparently, yes
Power Supply Samsung 18W 5V fast-charger
Mouse MX Anywhere 2
Keyboard Logitech MX Keys (not Cherry MX at all)
VR HMD Samsung Oddyssey, not that I'd plug it into this though....
Software W10 21H1, barely
Benchmark Scores I once clocked a Celeron-300A to 564MHz on an Abit BE6 and it scored over 9000.
I am so ready for an APU with a better IGP. My current daily driver is a 25W HP Envy with a 4700U and I hate to say it but that shitty Vega7 is the best IGP I could get my hands on. The Iris Xe IGP of the 1135G7 was looking good based on Intel's cherry-picked benchmarks but then independent reviewers tested it for real at launch and the decrepit old Vega5 in the lowly R3 4300U was faster even at just 15W.

RDNA2 and DDR5 might make for an amazing sub-25W laptop, RDNA2 scales down well to the 6600XT and most importantly, the performance/Watt is amazing.


Mussels

Freshwater Moderator
Staff member
Joined
Oct 6, 2004
Messages
53,483 (8.31/day)
Location
Oystralia
System Name Rainbow Sparkles
Processor Ryzen R7 5800X (PBO tweaked, 4.4-5.05GHz)
Motherboard Asus x570 Gaming-F
Cooling EK Quantum Velocity AM4 + EK Quantum ARGB 3090 w/ active backplate. Dual rad.
Memory 2x32GB DDR4 3600 Corsair Vengeance RGB @3800 C18-22-22-22-42 TRFC704 (1.4V, SoC 1.15V Hynix MJR)
Video Card(s) Galax RTX 3090 SG 24GB: Often underclocked to 1500Mhz 0.737v
Storage 2TB WD SN850 NVME + 1TB Sasmsung 970 Pro NVME + WD AN1500 1TB + 1TB Intel 6000P NVME USB 3.2
Display(s) Gigabyte G32QC (4k80Hz, 1440p 165Hz) + Phillips 328m6fjrmb (4K 60Hz, 1440p 144Hz)
Case Fractal Design R6
Audio Device(s) Logitech G560 |Razer Leviathan | Corsair Void pro RGB |Blue Yeti mic
Power Supply Corsair HX 750i (Platinum, fan off til 300W)
Mouse Logitech G Pro wireless + Steelseries Prisma XL
Keyboard Razer Huntsman TE (custom white and steel keycaps)
VR HMD Oculus Rift S
Software Windows 11 pro x64 (Yes, it's genuinely a good OS)
Benchmark Scores I don't quite know how i managed to get such a top tier PC, I am not rich.
8x PCI-E 4.0 lanes can handle any desktop GPU out there, so its good to see in the laptop space


The thing is, internally a 1x 4.0 lane provides enough bandwidth for all sorts of peripherals, ports etc laptops often miss out on. 10Gb USB 4 ports? Thunderbolt? 5Gb ethernet? can all be done easier now

Joined
Nov 11, 2004
Messages
10,986 (1.72/day)
Location
Formosa
System Name Overlord Mk MXVI
Processor AMD Ryzen 7 5800X
Motherboard Gigabyte X570 Aorus Master
Cooling Corsair H115i Pro
Memory 32GB Viper Steel 3600 DDR4 @ 3800MHz 16-19-16-19-36
Video Card(s) Gigabyte RTX 2080 Gaming OC 8G
Storage 1TB WD Black NVMe (2018), 2TB Viper VPN100, 1TB WD Blue 3D NAND
Display(s) Asus PG27AQ
Case Corsair Carbide 275Q
Audio Device(s) Corsair Virtuoso SE
Power Supply Corsair RM750
Mouse Logitech G502 Lightspeed
Keyboard Wooting Two
Software Windows 10 Pro
Benchmark Scores https://valid.x86.fr/33u9si
Joined
Jul 20, 2018
Messages
82 (0.06/day)
System Name Multiple desktop/server builds
Processor Desktops: 12900K, 5950X | Servers: 2 x 3900X, 2 x 5950X, 3950X, 2950X
Motherboard 2 main builds are Strix Z690-I & X570 Aorus Xtreme
Cooling All watercooled
Memory 6000C36, 4000C14
Video Card(s) 3090 FTW3 Ultra, 3090 FE, 2080Ti Aorus WB, 2080Ti XC3, 1080Ti Gaming X EK, 2 x 1070, 2 x 1060
Storage dozens of TBs of SSDs, 112TB NAS
Display(s) Odyssey Neo G9, PG35VQ, P75QX-H1
Case Caselabs S8, Cerberus X, Cerberus, 2 x Velka 7, MM U2-UFO, Define C, Bitfenix Shogun, Ghost S1
What's the deal with the Dual 10Gb (Linux only)?
All previous desktop/server(not sure about APUs) Zen CPUs had integrated ethernet controllers, but they required you to sacrifice some serdes lanes and add an actual physical interface. IDK why it would be linux only though.

Joined
Oct 17, 2014
Messages
9,981 (3.60/day)
only 3 days to go for e3... can't wait for the content... really hoping we seem innovation in gaming laptops.

Joined
Feb 20, 2019
Messages
4,108 (3.47/day)
System Name Bragging Rights
Processor Atom Z3735F 1.33GHz
Motherboard It has no markings but it's green
Cooling No, it's a 2.2W processor
Memory 2GB DDR3L-1333
Video Card(s) Gen7 Intel HD (4EU @ 311MHz)
Storage 32GB eMMC and 128GB Sandisk Extreme U3
Display(s) 10" IPS 1280x800 60Hz
Case Veddha T2
Audio Device(s) Apparently, yes
Power Supply Samsung 18W 5V fast-charger
Mouse MX Anywhere 2
Keyboard Logitech MX Keys (not Cherry MX at all)
VR HMD Samsung Oddyssey, not that I'd plug it into this though....
Software W10 21H1, barely
Benchmark Scores I once clocked a Celeron-300A to 564MHz on an Abit BE6 and it scored over 9000.
only 3 days to go for e3... can't wait for the content... really hoping we seem innovation in gaming laptops.
I don't think gaming laptops are going to get any huge changes as they're mostly limited by cooling and power delivery which depends entirely on performance/Watt which hasn't really moved much in the last 3 years, we're still mostly seeing the same 7nm TSMC and Intel 10nm (rebranded Intel7). Samsung 8 for Ampere doesn't seem to bring much to the table over TSMC12 of Turing's dGPUS, it's arguably worse at the low end when comparing performance/Watt of the 3050 against the 1650Ti etc - possibly because the 3050 is bogged down by additional raytracing die area that the 1650/1660 series don't have to bother with. I've yet to see the 3050 convincingly raytrace anything at playable framerates, so IMO that's a step backwards anyway!

Alder Lake may be more efficient than Rocket lake but we already know it's not a game-changer in terms of performance/Watt at "65W" TDPs, more of an evolutionary step that brings Intel up to the peformance/Watt level that AMD have already been operating at since Renoir a couple of years ago.

What I would like to see (but probably won't) is some higher-quality midrange laptops that don't compromise on cooling to be as thin as humanly possible. Call me crazy but a 3060 gets to mostly stretch its legs at about 90W TGP, which is fine in a mainstream 1080p gaming laptop and can be cooled quietly and unobtrusively if the laptop's base is allowed to be 20mm thick instead of 12mm thick. Thin&light is great but it starts to get overly compromised for cooling and battery runtimes once you move into dGPU territory, utterly defeating the purpose of a thin&light.

There will always be fancy $4000+ flagship laptops with two power bricks, a 3080 and all the trimmings but I think the target audience for most gaming laptops is people sitting on a sofa in a social environment with their SO, kids, whatever. Noisy, heavy, barely-portable and inconvenient laptops look cool on the trade show floor but really aren't popularly desirable.

Whoops, that turned into a cynical ramble. Hope I'm wrong, but it's better to be a pessimist who gets better news than they expected, than to be an optimist who is constantly dissappointed by the usually underwhelming reality.
