Bios Rx 570 4GB Phantom Gaming ??

Chuecook

New Member
Joined
Mar 11, 2023
Messages
12 (0.01/day)
Hi, could anyone help me? I need a BIOS for this Asrock 570 4GB GPU. I've already tried the links I found on techPowerUp, but they all seem to be for mining, and I want one for gaming. Thanks for any help.

links visited in TechPowerUp:

images:
s


Attachments

  • TechpowerUP4.JPG
    51.4 KB · Views: 35
Photos of the actual GPU shroud showing all stickers and part numbers please.

Hi, could anyone help me? I need a BIOS for this Asrock 570 4GB GPU. I've already tried the links I found on techPowerUp, but they all seem to be for mining, and I want one for gaming. Thanks for any help.

links visited in TechPowerUp:

images:
View attachment 403779 s
View attachment 403780View attachment 403781
If you are going to flash with amdvbflash, DONT USE THE GUI since that doesnt allow to force a flash. Also you need to use amdvbflash v2.93 and not newer!

As requested by Caring1, please provide useful pictures of the card.

Hi guys. These are the only two labels on the GPU. I don't have the box.

Images:



You have already found to correct bios for your card:

You need to follow the flash guide of eidairaman1:
For RX 500 Series (Polaris) and Older:

Get amdvbflash 2.93

https://www.techpowerup.com/download/ati-atiflash/

Then look for Version 4.68, underneath 4.68 you will see a link to show older version, click that and you should see version 2.93

Here is a fix to make 2.93 work in Windows 10 and 11, Get the zip for version 5.0.567, extract it, then find the AMDVBDriverInstaller, execute the file and follow prompts, then restart the computer, that should help with bypassing Win8 Security feature prompt, if you get that prompt hit ok. Once done flashing run the file again to uninstall it for safety reasons

Follow these steps carefully:

1. Open your "C:" drive in Windows, create a new folder, call it atiflash.

2. Extract the contents of atiflash_293.zip to the "C:\atiflash" folder

3. Find the bios file you downloaded and rename the bios file to 5 digits with .rom on end Example RX 580, change file to rx580.rom (r****.rom)

4. Move r****.rom to the "C:\atiflash" folder

5. Open the start menu, type cmd, when cmd.exe appears right click it and hit "Run as administrator"

6. At the command prompt type in cd\ and press enter until only C:\> is on the screen.

7. Type in cd/atiflash and press enter, you should see C:\atiflash>

8. Type in amdvbflash.exe -i to identify the gpu you want to flash with a 0, 1, or 2)

9. At the C:\atiflash> prompt type in
amdvbflash.exe -unlockrom 0
(there is a space between the e and -unlockrom and 0)(0 is the number zero)
press enter and you will be prompted that the "ROM Unlocked" (or 1, 2)

10. At the C:\atiflash> prompt type in
amdvbflash.exe -f -p 0 r****.rom
(there is a space between the .exe and -f, and a space between -f and -p and 0).
(Or 1, 2)

Press Enter

Follow directions on screen and if flash is successful exit the command prompt and restart, windows should show up on screen.
