EKWB Unveils EK-FC R9-295X2 for Radeon R9 295X2

btarunr

Editor & Senior Moderator
Staff member
Joined
Oct 9, 2007
Messages
34,335 (9.22/day)
Likes
17,427
Location
Hyderabad, India
System Name Long shelf-life potato
Processor Intel Core i7-4770K
Motherboard ASUS Z97-A
Cooling Xigmatek Aegir CPU Cooler
Memory 16GB Kingston HyperX Beast DDR3-1866
Video Card(s) 2x GeForce GTX 970 SLI
Storage ADATA SU800 512GB
Display(s) Samsung U28D590D 28-inch 4K
Case Cooler Master CM690 Window
Audio Device(s) Creative Sound Blaster Recon3D PCIe
Power Supply Corsair HX850W
Mouse Razer Abyssus 2014
Keyboard Microsoft Sidewinder X4
Software Windows 10 Pro Creators Update
#1
EK Water Blocks unveiled the first pictures of its full-coverage water block for AMD Radeon R9 295X2. It takes a meaty block to cool the 500-Watt dual-GPU monstrosity, which is also the fastest graphics card money can buy. The EK-FC R9-295X2 from EK is one of the few full-cover blocks that feature coolant channels that actually span the entire obverse length of the card. The channel is designed in a way that coolant is distributed uniformly to both the GPU systems, their neighboring memory, and the central portion of the card, housing its feisty VRM and PCIe bridge chip. The block comes in two variants, one with clear acrylic top over the two GPUs, with an aluminum central top; and one with opaque acetal top instead of clear acrylic. The two blocks come in two further variants, clear copper and nickel-plated copper block material. To top it all off, EK appears to either be bundling, or separately selling a single-slot expansion bracket for the card (a carryover from its HD 7990 block).

Show full news post


MxPhenom 216

Corsair Fanboy
Joined
Aug 31, 2010
Messages
12,134 (4.55/day)
Likes
3,700
Location
Seattle, WA
System Name The Battlestation
Processor Intel Core i7 4770k @ 4.2GHZ 1.275v
Motherboard MSi Z97 Gaming 5
Cooling EK Supremacy w/ EK Coolstream PE360
Memory G. Skill Trident X 16Gb (4x4GB) 2400mhz @ 1.65v
Video Card(s) MSi GTX1070 Gaming X 8GB @ 2GHz
Storage Samsung 830 128GB SSD, Crucial MX200 500GB, Seagate Barracuda 2TB (2x 1TB Partitions)
Display(s) Qnix QX2710 27" 2560 x 1440 PLS @ 100hz
Case Phantek Enthoo Evolv ATX TG
Audio Device(s) MSi Gaming AudioBoost ALC1150 w/ Sennheiser Game Ones
Power Supply Seasonic Flagship Prime Platinum 850
Mouse Steelseries Rival 310 w/ QCK Mass mat
Keyboard Corsair K70 w/ MX Browns and Red Backlit
Software Windows 10 Pro 64-Bit
Benchmark Scores Firestrike: 15439
#3
Sweet jesus, some nice blocks for sure.

Joined
Apr 29, 2014
Messages
3,688 (2.77/day)
Likes
2,106
Location
Texas
System Name Alucard / The Reinforcer / Portable?
Processor i7 5930K @ 4.5ghz (24/7) / 2x Intel Xeon X5670 / Intel i7 3610QM
Motherboard MSI X99S Gaming 9 AC / Dell Dual Socket (R710) / MSI Stock Gaming Laptop
Cooling RX 360mm + 140mm Custom Loop in Push Pull Config. / Dell Stock / MSI Stock
Memory Corsair Vengeance DDR4 2666 16gb (4x4gb) CL 16 / 1333mhz DDR3 96gb 12 x 8gb / 12gb DDR3 3 x 4gb
Video Card(s) GTX Titan XP (2025mhz) / Asus GTX 950 (No Power Connector) / GTX 880m
Storage Samsung 840/850 512gb Raid 0, WD Velociraptor 600gb x 5 Raid 5 / 300gb 15k RPM x 8 / 2x 240gb Adata
Display(s) Acer XG270HU 1440p 144hz Freesync, Acer B286HK 4K UHD Monitor, 1 Hanns-G 27inch 1920x1080p Monitor
Case Corsair Obsidian 800D / Dell Poweredge R710 Rack Mount Case / MSI Gaming 17inch
Audio Device(s) Realtec ALC1150 (On board)
Power Supply Rosewill Lightning 1300Watt
Mouse Logitech G5
Keyboard Logitech G19S
Software Windows 10 Pro / Windows Server 2008 R2 / Windows 10 Pro
#4
Very nice looking block, love my 290x EK blocks.

Joined
Aug 2, 2012
Messages
374 (0.19/day)
Likes
104
Location
Netherlands
System Name TheDeeGee's PC
Processor Intel Core i7 4770K
Motherboard Gigabyte Z87X-UD5H
Cooling Noctua NH-U14S
Memory Crucial Ballistix Tactical LP 16GB
Video Card(s) MSI GTX 1070 AERO OC
Storage Crucial M4 256GB, 2x Western Digital 1TB 2,5"
Display(s) EIZO CX240
Case Antec P280
Audio Device(s) Creative SoundBlaster ZxR
Power Supply Seasonic P-760
Mouse Logitech G500s
Keyboard Logitech G710+
Software Windows 10 Pro 64-Bit
#5
I'm far from an expert in Watercooling.

But wouldn't it be better if the In/Out was in the middle of the block, so the pressure is even for both GPUs?

Joined
Jan 21, 2013
Messages
3,800 (2.12/day)
Likes
1,320
System Name Out of the game..
Benchmark Scores d1nky@hwbot.org
#6
I'm far from an expert in Watercooling.

But wouldn't it be better if the In/Out was in the middle of the block, so the pressure is even for both GPUs?

Maybe but it would need to be where it is so that multiple blocks/cards can be used in line

Joined
Dec 8, 2008
Messages
1,334 (0.40/day)
Likes
163
#7
I'm far from an expert in Watercooling.

But wouldn't it be better if the In/Out was in the middle of the block, so the pressure is even for both GPUs?
Looks like the water flows through gpu-vrm-gpu in a single path so it makes no difference. Restriction causes pressure drop which reduces flow rate and flow rate is what affects heat removal(other than block design obviously). Where in the loop is the pressure dropped doesn't matter, there's only one flow rate in a simple serial loop. And unlike air, water has a huge thermal capacity so unless you're removing a LOT of heat and have a VERY low flow rate the temperature difference of cooled and heated water is very minor.

Joined
Apr 29, 2014
Messages
3,688 (2.77/day)
Likes
2,106
Location
Texas
System Name Alucard / The Reinforcer / Portable?
Processor i7 5930K @ 4.5ghz (24/7) / 2x Intel Xeon X5670 / Intel i7 3610QM
Motherboard MSI X99S Gaming 9 AC / Dell Dual Socket (R710) / MSI Stock Gaming Laptop
Cooling RX 360mm + 140mm Custom Loop in Push Pull Config. / Dell Stock / MSI Stock
Memory Corsair Vengeance DDR4 2666 16gb (4x4gb) CL 16 / 1333mhz DDR3 96gb 12 x 8gb / 12gb DDR3 3 x 4gb
Video Card(s) GTX Titan XP (2025mhz) / Asus GTX 950 (No Power Connector) / GTX 880m
Storage Samsung 840/850 512gb Raid 0, WD Velociraptor 600gb x 5 Raid 5 / 300gb 15k RPM x 8 / 2x 240gb Adata
Display(s) Acer XG270HU 1440p 144hz Freesync, Acer B286HK 4K UHD Monitor, 1 Hanns-G 27inch 1920x1080p Monitor
Case Corsair Obsidian 800D / Dell Poweredge R710 Rack Mount Case / MSI Gaming 17inch
Audio Device(s) Realtec ALC1150 (On board)
Power Supply Rosewill Lightning 1300Watt
Mouse Logitech G5
Keyboard Logitech G19S
Software Windows 10 Pro / Windows Server 2008 R2 / Windows 10 Pro
#8
I'm far from an expert in Watercooling.

But wouldn't it be better if the In/Out was in the middle of the block, so the pressure is even for both GPUs?
In reality it would not make a noticeable difference. The flow is so fast that it just gets over all the components at a high enough rate that doing different locations of the connectors on the block itself won't really help much so they mostly put the focus on putting it in an area for convenience.

So its not much of a difference if any.


manofthem

WCG-TPU Team All-Star!
Joined
Jan 9, 2011
Messages
10,727 (4.23/day)
Likes
26,179
Location
Florida
System Name bBox | tOffice | mDonk
Processor i7 4770k @4.3 | i7 2600k @3.5 | i7 4790 @3.8
Motherboard MSI Z87 G45 | MSI Z68 GD55 | MSI H97M G43
Cooling Water | Reeven Justice RC-1204 | can't remember
Memory G Skill TridentX 8GB 2400 | Patriot Viper 3 8GB 1600 | G Skill Ripjaws 8GB 1600
Video Card(s) 2x R9 290's | 980 SC ACX2.0 | n/a
Storage 850 Evo 250GB & 2TB Desktar 5K3000 | 830 256GB & 1.5TB & 3TB Barracudas| 830 256GB
Display(s) QNIX WX2710 (96Hz OC) & Shimian Achieva QH270-Lite | Acer 27HL | n/a
Case 900D | Fractal Define S | n/a
Audio Device(s) Siberia v2 | onboard | n/a
Power Supply Corsair AX1200 | XFX 550Pro | SeaSonic 660XP2
Mouse Razer Mamba 2012 | Corsair M95 | n/a
Keyboard Das Keyboard Pro 4 (blues) | Cougar Attack X3 (blues) | n/a
Software Win 10 Pro x64 | Win 10 Pro x64 | Win 10 Pro x64
#9
I'm far from an expert in Watercooling.

But wouldn't it be better if the In/Out was in the middle of the block, so the pressure is even for both GPUs?


An echo...? ;)

Now i'm not using Watercooling, nor am an expert at it.

But should't the In/Out be in the middle of the Block? The second GPU is quite far away. Wouldn't it lose flow pressure?

Joined
Oct 26, 2011
Messages
3,121 (1.39/day)
Likes
892
Processor Ci7 5960X
Motherboard RVE
Cooling Triple Aquacomputer AMS 840 with D5
Memory Some random DDR4
Video Card(s) GTX 1080 Ti
Storage 960 EVO
Display(s) Dell U3011 2560x1600 + Dell 2408WFP 1200x1920 (Portrait)
Case Dimastech Bench EasyXL
Audio Device(s) Essence STX
Power Supply AX 1500i
Software Win10
#10
Aquacomputer blocks look 10x times better imo.
