i so LOVE how this thread is still going. Anyway i needed a small place to remove the mess from my desk.

Joined
Nov 20, 2013
Messages
3,886 (1.78/day)
Location
Kiev, Ukraine
System Name WS#1337
Processor Ryzen 5 1600X
Motherboard Gigabyte x470 AORUS Ultra Gamin
Cooling Xigmatek Scylla 240 AIO
Memory 2x8GB Team T-Force Vulkan DDR4-3000
Video Card(s) MSI RTX 2060 Super Armor OC
Storage Adata SX8200 256GB, Sandisk X400 512GB
Display(s) Samsung U24E590D (4K/UHD)
Case Chieftec AL-01B-OP
Audio Device(s) ALC1220
Power Supply SeaSonic SSR-550FX (80+ GOLD)
Mouse Logitech G503
Keyboard Zalman K500 modded (Gateron brown)
Software Windows 10, Ubuntu 18.04 LTS
i needed a small place to remove the mess from my desk.
LoL. And back in a day people used to spend $10-$15 on 5.25" storage drawers )))

Ok, now that I'm done backing up pictures off my phone, it's time to share my latest "inventions".

#1. Noise cancelling for G603.
Got really tired of super-loud clicks in semi-empty mouse, so I've decided to try some foam before I come up with a permanent solution.
For some reason only LBM feels more resistant. RBM is kinda the same. Noise levels reduced. Mission accomplished.

#2 My super-secret project codenamed "F#$K ASUS". :D:D:D
Got a PCE-AC55BT not too long ago, cause my new board has no M.2 slot for WiFi adapter. Basically sidegraded from Intel 8260 to another Intel 8260 and lost $50 in process, all for the sake of not losing WiFi on Ubuntu.
While my old adapter had no issues delivering 680-780Mbit/s, this one barely managed half that.
Stock antenna is [was:p] total garbage. Not only did it under-perform, but it also looked pathetic and sad. :cry:
I swore a couple of years ago that I'll never-ever buy another ASUS wireless adapter, but unfortunately it was the only Intel-based alternative that was in stock in my area.
So, today I got very pissed off and took that piece of shit for a ride to my secret laboratory on the outskirts of the city.

First, we take it apart and mutilate the wires. I do have some thin coax cables in my office, but couldn't find any female SMA connectors of the right size.
IMG_20190501_124858.jpgIMG_20190501_124906.jpgIMG_20190501_132324.jpgIMG_20190501_132309.jpg

Then, we take some big-ass 12dBi antennas from hell(previously used on my ASUS RT-N66U) and a couple of random mutilated SMA pigtails.
Next, I dug up some random plastic enclosure from a no-name powerbank and drilled some holes for SMA connectors:
Now, I can finally solder the stock cable to my DIY fankentenna.
Electrical tape is only there for protective reasons (to avoid bending/breaking the cable on sharp edges). Actual solder points are isolated with some hot snot (not shown).

Last step is to add stability and sturdiness to the whole structure. Stock ASUS antenna had no rubber feet and was so light that it rolled on my desk every time I farted.
For this part I'm gonna use one of my spare AsRock heatsinks ripped of a dead embedded board. Two middle sections were removed in order to accomodate that plastic housing.
"Underbelly" was cleaned off the remaining thermal paste. As you can see - it already has some rubber standoffs (originally I wanted to put on some aftermarket rubber feet, leftover from my previous project).
Last step - gluing it all together with more hot snot... lots of hot snot... :rockout:




End result: WiFi back to normal with speeds ranging from 700 to max 866 Mbit/s, no ping anomalies, no bluetooth issues.
Maybe it's overkill... maybe it wasn't wort it in terms of performance gain, but it looks intimidating! ...and I won't see that ugly cheap and miserable piece of plastic on my desk ever again.
P.S. ... and I can do some wifi mischief almost 2 street away from the house, if I put it near the window ))
