Gigabyte to Pack Wireless-N and Bluetooth 4.0 Addon Card with Some X79 Boards

btarunr

Editor & Senior Moderator
Staff member
Joined
Oct 9, 2007
Messages
41,083 (8.27/day)
Location
Hyderabad, India
Processor AMD Ryzen 7 2700X
Motherboard ASUS ROG Strix B450-E Gaming
Cooling AMD Wraith Prism
Memory 2x 16GB Corsair Vengeance LPX DDR4-3000
Video Card(s) Palit GeForce RTX 2080 SUPER GameRock
Storage Western Digital Black NVMe 512GB
Display(s) BenQ 1440p 60 Hz 27-inch
Case Corsair Carbide 100R
Audio Device(s) Creative Sound Blaster Recon3D PCIe
Power Supply Cooler Master MWE Gold 650W
Mouse ASUS ROG Strix Impact
Keyboard Microsoft Sidewinder X4
Software Windows 10 Pro
There sure is going to be fierce competition between motherboard vendors once "Sandy Bridge-E" Core i7 processors come out, a little later this month. Even the tiniest edge over competitors in terms of features can go a long way with market success. Gigabyte is ready with one such feature of its own: the Bluetooth 4.0 + WiFi b/g/n card, which it will bundle with the GA-X79-UD5, GA-X79-UD7(OC), and G1.Assassin 2. Simply put, this is a special addon card that will provide a Wireless b/g/n (wireless n at 150 Mbps), and Bluetooth 4.0 (24 Mbps) connectivity.

Here's how it works: the card sits on one of the board's PCI-Express x1 slots (or any PCIe slot for that matter), the PCIe connection is wired to the wireless network controller on the mini-PCIe card. We expect this to be a common Atheros AR9285-based card. The main card also has a Bluetooth 4.0 controller, which connects to the system using USB 2.0. A cable runs from the card to any of the board's USB 2.0 front-panel headers. The Bluetooth controller only uses one port, so the other is wired out as an internal USB 2.0 port (good for any DRM dongles you may have). The card is then wired to two antennas (included), one for the wireless network controller, the other for the Bluetooth, both have activity LEDs. It's not known if Gigabyte will sell this card separately, so just about anyone can use it.



View at TechPowerUp Main Site

Joined
Aug 11, 2008
Messages
334 (0.07/day)
Location
Ireland
/start mini rant
just 150Mbps? external antennas(on a cable)? usb header needed for bluetooth?
no offense but I would rather not bother with it
/end mini rant
more is better but also quality over quantity :D

Joined
Nov 11, 2004
Messages
8,003 (1.33/day)
Location
Formosa
System Name Overlord Mk MXVI
Processor AMD Ryzen 7 3800X
Motherboard Gigabyte X570 Aorus Master
Cooling Corsair H115i Pro
Memory 32GB Viper Steel 3600 DDR4 @ 3800MHz 16-19-16-19-36
Video Card(s) Gigabyte RTX 2080 Gaming OC 8G
Storage 1TB WD Black NVMe (2018), 2TB Viper VPN100, 1TB WD Blue 3D NAND
Display(s) Asus PG27AQ
Case Corsair Carbide 275Q
Audio Device(s) Corsair Virtuoso SE
Power Supply Corsair RM750
Mouse Logitech G502 Lightspeed
Keyboard Wooting Two
Software Windows 10 Pro
Benchmark Scores https://valid.x86.fr/33u9si
Well, you can change the antennas, as they're using standard connectors and the idea behind the cables is that most people shove their PC under a desk and as such the Wi-Fi antennas are blocked and the range is reduced, same goes for Bluetooth, although I guess the range is generally not as important in that case.

The USB cable is required unless you add a USB 2.0 host controller to the PCI Express adapter, as there are no PCI Express Bluetooth chips.

As for 150Mbps, yeah, that part kinda sucks, but in all fairness, no other motherboard maker offers anything better.

Also, I'd rather have this than Asus proprietary module that fits one, yes one, of their motherboards, or the nasty solution from ECS with a wire attached to a PCB antenna which is connected to the rear of the USB dongle which is part of the I/O ports, but hey...

Joined
Dec 8, 2008
Messages
1,334 (0.29/day)
GB should make this an entirely standalone product instead of putting it into some sort of "jumbo pack".
Enthusiasts know enough to choose two or three stream N instead of this halfhearted solution.

*also, no 5GHz.


Mussels

Moderprator
Staff member
Joined
Oct 6, 2004
Messages
49,815 (8.21/day)
Location
Australalalalalaia.
System Name Rainbow Sparkles
Processor Ryzen R7 5800X
Motherboard Asus x570 Gaming-F
Cooling EK 240mm RGB AIO | Custom 280mm EK loop
Memory 64GB DDR4 3600 Corsair Vengeance RGB @ 3800 C16
Video Card(s) Galax RTX 3090 SG 24GB (0.8v 1.8GHz) - EK ARGB block
Storage 1TB Sasmsung 970 Pro NVME + 500GB 850 Evo
Display(s) Gigabyte G32QC + Phillips 328m6fjrmb (32" 1440p 165Hz/144Hz curved )
Case Fractal Design R6
Audio Device(s) Razer Leviathan + Corsair Void pro RGB, Blue Yeti mic
Power Supply Corsair HX 750i (Platinum, fan off til 300W)
Mouse Logitech G Pro wireless + Steelseries Prisma XL
Keyboard Razer Huntsman TE
Software Windows 10 pro x64 (all systems)
Benchmark Scores Lots of RGB, so you know it's fast.
bluetooth FOUR?


i didnt even realise they'd passed TWO

Joined
Nov 11, 2004
Messages
8,003 (1.33/day)
Location
Formosa
System Name Overlord Mk MXVI
Processor AMD Ryzen 7 3800X
Motherboard Gigabyte X570 Aorus Master
Cooling Corsair H115i Pro
Memory 32GB Viper Steel 3600 DDR4 @ 3800MHz 16-19-16-19-36
Video Card(s) Gigabyte RTX 2080 Gaming OC 8G
Storage 1TB WD Black NVMe (2018), 2TB Viper VPN100, 1TB WD Blue 3D NAND
Display(s) Asus PG27AQ
Case Corsair Carbide 275Q
Audio Device(s) Corsair Virtuoso SE
Power Supply Corsair RM750
Mouse Logitech G502 Lightspeed
Keyboard Wooting Two
Software Windows 10 Pro
Benchmark Scores https://valid.x86.fr/33u9si
Joined
Jan 11, 2009
Messages
9,075 (2.01/day)
Location
Montreal, Canada
System Name Homelabs
Processor Ryzen 3900x | Ryzen 1920X
Motherboard shopping for mobo | AsRock X399 fatal1ty gaming
Cooling Dark Rock Pro 4 | Dark Rock Pro 4 TR
Memory 128GB (4x8gb) DDR4 3600Mhz | 128GB (8x16GB) DDR4 2933Mhz
Video Card(s) GTX 1060 | GTX 1060
Storage Optane 900p, 15~20TB of SSDs mix of NVMe and SATA, 100+TB (50TB after RAID 10) HDDs
Display(s) Korean 1440p | Dell refurb 19"
Case BeQuiet! SilentBase 800 | some ATX case
Audio Device(s) AKG KXXX
Power Supply EVGA P2 750W | none yet
meh... I guess it's an OK addition. I thought it might have been integrated onto the MB, silly me :rolleyes:

Joined
Nov 13, 2009
Messages
5,614 (1.34/day)
Location
San Diego, CA
System Name White Boy
Processor Core i7 3770k @4.6 Ghz
Motherboard ASUS P8Z77-I Deluxe
Cooling CORSAIR H100
Memory CORSAIR Vengeance 16GB @ 2177
Video Card(s) EVGA GTX 680 CLASSIEFIED @ 1250 Core
Storage 2 Samsung 830 256 GB (Raid 0) 1 Hitachi 4 TB
Display(s) 1 Dell 30U11 30"
Case BIT FENIX Prodigy
Audio Device(s) none
Power Supply SeaSonic X750 Gold 750W Modular
Software Windows Pro 7 64 bit || Ubuntu 64 Bit
Benchmark Scores 2017 Unigine Heaven :: P37239 3D Mark Vantage
Wait so despite using 1x PCI-e it needs additional USB connection for the whopping 24 mb of bluetooth, this seems like an over complicated bother to put it nicely.

Joined
Jan 11, 2009
Messages
9,075 (2.01/day)
Location
Montreal, Canada
System Name Homelabs
Processor Ryzen 3900x | Ryzen 1920X
Motherboard shopping for mobo | AsRock X399 fatal1ty gaming
Cooling Dark Rock Pro 4 | Dark Rock Pro 4 TR
Memory 128GB (4x8gb) DDR4 3600Mhz | 128GB (8x16GB) DDR4 2933Mhz
Video Card(s) GTX 1060 | GTX 1060
Storage Optane 900p, 15~20TB of SSDs mix of NVMe and SATA, 100+TB (50TB after RAID 10) HDDs
Display(s) Korean 1440p | Dell refurb 19"
Case BeQuiet! SilentBase 800 | some ATX case
Audio Device(s) AKG KXXX
Power Supply EVGA P2 750W | none yet
The USB is to communicate with the OS I believe, as I'm guessing the BT can't communicate through PCI-E... and it keeps it separated from the wireless :p

Joined
May 22, 2010
Messages
50 (0.01/day)
Location
Los Angeles, CA
System Name Akuma, Iluminati
Processor 2 x Intel i7 4930K @ 4.6GHz
Motherboard 2 x Asus Rampage IV Gene
Cooling 2 x Corsair H110 Push-Pull
Memory 2 x Mushkin Ridgeback Redline 16GB @ DDR3-2400
Video Card(s) 2 x EVGA GTX 670 FTW SLI, EVGA GTX 650 Ti Boost
Storage 2 x Intel 320 120GB RAID0, 2 x Intel 520 180GB RAID0, TOO MANY MORE TO LIST!
Display(s) Asus PB298Q, 2 x Asus VH236H
Case Custom Tech Bench, Antec 300 Illusion
Audio Device(s) 2 x Onboard Soundblaster X-Fi III
Power Supply Corsair HX1000, Rosewill 1000w
Software Windows 7 Ultimate x64
*also, no 5GHz.

5GHz is actually not very good. That frequency is easily absorbed by building materials such as concrete which greatly reduces the wireless range. 2.4GHz isn't affected by this absorption problem, but it is prone to interference due to so many other devices using this frequency such as the microwave, wireless phones, your cell phone...etc. Even with that interference issue it isn't as bad as it sounds unless you use all the devices at the same time. This is why if you look at wireless standards 802.11a used 5GHz while the rest 802.11b, g, and n use 2.4GHz.
