NVIDIA GeForce RTX 5060
- Graphics Processor
- GB206
- Cores
- 3840
- TMUs
- 120
- ROPs
- 48
- Memory Size
- 8 GB
- Memory Type
- GDDR7
- Bus Width
- 128 bit
GPU
Recommended Gaming Resolutions:
- 1920x1080
- 2560x1440
- 3840x2160
The GeForce RTX 5060 is a performance-segment graphics card by NVIDIA, launched on May 19th, 2025. Built on the 5 nm process, and based on the GB206 graphics processor, in its GB206-250-A1 variant, the card supports DirectX 12 Ultimate. This ensures that all modern games will run on GeForce RTX 5060. Additionally, the DirectX 12 Ultimate capability guarantees support for hardware-raytracing, variable-rate shading and more, in upcoming video games. The GB206 graphics processor is an average sized chip with a die area of 181 mm² and 21,900 million transistors. Unlike the fully unlocked GeForce RTX 5060 Ti 16 GB, which uses the same GPU but has all 4608 shaders enabled, NVIDIA has disabled some shading units on the GeForce RTX 5060 to reach the product's target shader count. It features 3840 shading units, 120 texture mapping units, and 48 ROPs. Also included are 120 tensor cores which help improve the speed of machine learning applications. The card also has 30 raytracing acceleration cores. NVIDIA has paired 8 GB GDDR7 memory with the GeForce RTX 5060, which are connected using a 128-bit memory interface. The GPU is operating at a frequency of 2280 MHz, which can be boosted up to 2497 MHz, memory is running at 1750 MHz (28 Gbps effective).
Being a dual-slot card, the NVIDIA GeForce RTX 5060 draws power from 1x 8-pin power connector, with power draw rated at 145 W maximum. Display outputs include: 1x HDMI 2.1b, 3x DisplayPort 2.1b. GeForce RTX 5060 is connected to the rest of the system using a PCI-Express 5.0 x8 interface. The card's dimensions are 241 mm x 111 mm x 40 mm, and it features a dual-slot cooling solution. Its price at launch was 299 US Dollars.
Being a dual-slot card, the NVIDIA GeForce RTX 5060 draws power from 1x 8-pin power connector, with power draw rated at 145 W maximum. Display outputs include: 1x HDMI 2.1b, 3x DisplayPort 2.1b. GeForce RTX 5060 is connected to the rest of the system using a PCI-Express 5.0 x8 interface. The card's dimensions are 241 mm x 111 mm x 40 mm, and it features a dual-slot cooling solution. Its price at launch was 299 US Dollars.
Graphics Processor
- GPU Name
- GB206
- GPU Variant
- GB206-250-A1
- Architecture
- Blackwell 2.0
- Foundry
- TSMC
- Process Type
- 4N FinFET
- Process Size
- 5 nm
- Transistors
- 21,900 million
- Density
- 121.0M / mm²
- Die Size
- 181 mm²
Graphics Card
- Release Date
- May 19th, 2025
- Announced
- Apr 15th, 2025
- Generation
- GeForce 50
- Predecessor
- GeForce 40
- Production
- Active
- Launch Price
- 299 USD
- Bus Interface
- PCIe 5.0 x8
- Reviews
- 10 in our database
Relative Performance
Based on TPU review data: "Performance Summary" at 1920x1080, 4K for 2080 Ti and faster.
Clock Speeds
- Base Clock
- 2280 MHz
- Boost Clock
- 2497 MHz
- Memory Clock
-
1750 MHz
28 Gbps effective
Memory
- Memory Size
- 8 GB
- Memory Type
- GDDR7
- Memory Bus
- 128 bit
- Bandwidth
- 448.0 GB/s
Render Config
- Shading Units
- 3840
- TMUs
- 120
- ROPs
- 48
- SM Count
- 30
- Tensor Cores
- 120
- RT Cores
- 30
- L1 Cache
- 128 KB (per SM)
- L2 Cache
- 32 MB
Theoretical Performance
- Pixel Rate
- 119.9 GPixel/s
- Texture Rate
- 299.6 GTexel/s
- FP16 (half)
- 19.18 TFLOPS (1:1)
- FP32 (float)
- 19.18 TFLOPS
- FP64 (double)
- 299.6 GFLOPS (1:64)
Board Design
- Slot Width
- Dual-slot
- Length
- 241 mm
9.5 inches
- Width
- 111 mm
4.4 inches
- Height
- 40 mm
1.6 inches
- TDP
- 145 W
- Suggested PSU
- 300 W
- Outputs
- 1x HDMI 2.1b
3x DisplayPort 2.1b
- Power Connectors
- 1x 8-pin
- Board Number
- PG152 SKU 25
Graphics Features
- DirectX
- 12 Ultimate (12_2)
- OpenGL
- 4.6
- OpenCL
- 3.0
- Vulkan
- 1.4
- CUDA
- 12.0
- Shader Model
- 6.8
GB206 GPU Notes
| Ray Tracing Cores: 4th Gen Tensor Cores: 5th Gen NVENC: 9th Gen NVDEC: 6th Gen PureVideo HD: VP11 VDPAU: Feature Set K Latest Drivers: Windows 10 / 11: GeForce Release: Latest Quadro Release: Latest Data Center Release: Latest |
Retail boards based on this design (86)
| Name | GPU Clock | Boost Clock | Memory Clock | Other Changes |
|---|---|---|---|---|
| 2280 MHz | 2497 MHz | 1750 MHz | 228 mm/9 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 228 mm/9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 268 mm/10.6 inches | |
| 2280 MHz | 2565 MHz | 1750 MHz | 268 mm/10.6 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 176 mm/6.9 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 176 mm/6.9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 302 mm/11.9 inches, Triple-slot | |
| 2280 MHz | 2640 MHz | 1750 MHz | 302 mm/11.9 inches, Triple-slot | |
| 2280 MHz | 2497 MHz | 1750 MHz | 245 mm/9.6 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 245 mm/9.6 inches | |
| 2280 MHz | 2610 MHz | 1750 MHz | 300 mm/11.8 inches | |
| 2280 MHz | 2580 MHz | 1750 MHz | 231 mm/9.1 inches | |
| 2280 MHz | 2580 MHz | 1750 MHz | 301 mm/11.9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 301 mm/11.9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 231 mm/9.1 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 262 mm/10.3 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 262 mm/10.3 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 292 mm/11.5 inches | |
| 2280 MHz | 2580 MHz | 1750 MHz | 292 mm/11.5 inches | |
| 2280 MHz | 2565 MHz | 1750 MHz | 234 mm/9.2 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 234 mm/9.2 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 225 mm/8.9 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 225 mm/8.9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 225 mm/8.9 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 225 mm/8.9 inches | |
| 2280 MHz | 2512 MHz | 1750 MHz | 235 mm/9.3 inches | |
| 2280 MHz | 2512 MHz | 1750 MHz | 235 mm/9.3 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 312 mm/12.3 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 255 mm/10 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 255 mm/10 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 302 mm/11.9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 223 mm/8.8 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 304 mm/12 inches | |
| 2280 MHz | 2722 MHz | 1750 MHz | 329 mm/13 inches | |
| 2280 MHz | 2595 MHz | 1750 MHz | 281 mm/11.1 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 208 mm/8.2 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 208 mm/8.2 inches | |
| 2280 MHz | 2595 MHz | 1750 MHz | 281 mm/11.1 inches | |
| 2280 MHz | 2512 MHz | 1750 MHz | 182 mm/7.2 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 199 mm/7.8 inches | |
| 2280 MHz | 2512 MHz | 1750 MHz | 199 mm/7.8 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 225 mm/8.9 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 250 mm/9.8 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 250 mm/9.8 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 211 mm/8.3 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 240 mm/9.4 inches, 155 W | |
| 2280 MHz | 2580 MHz | 1750 MHz | 319 mm/12.6 inches | |
| 2280 MHz | 2580 MHz | 1750 MHz | 320 mm/12.6 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 292 mm/11.5 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 248 mm/9.8 inches, 155 W | |
| 2280 MHz | 2625 MHz | 1750 MHz | 248 mm/9.8 inches, 155 W | |
| 2280 MHz | 2497 MHz | 1750 MHz | 300 mm/11.8 inches, 155 W | |
| 2280 MHz | 2625 MHz | 1750 MHz | 300 mm/11.8 inches, 155 W | |
| 2280 MHz | 2625 MHz | 1750 MHz | 300 mm/11.8 inches, 155 W | |
| 2280 MHz | 2497 MHz | 1750 MHz | 300 mm/11.8 inches, 155 W | |
| 2280 MHz | 2497 MHz | 1750 MHz | 204 mm/8 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 204 mm/8 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 197 mm/7.8 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 197 mm/7.8 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 197 mm/7.8 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 197 mm/7.8 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 197 mm/7.8 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 303 mm/11.9 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 303 mm/11.9 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 262 mm/10.3 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 262 mm/10.3 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 292 mm/11.5 inches | |
| 2280 MHz | 2580 MHz | 1750 MHz | 292 mm/11.5 inches, 155 W | |
| 2280 MHz | 2497 MHz | 1750 MHz | 200 mm/7.9 inches | |
| 2280 MHz | 2580 MHz | 1750 MHz | 280 mm/11 inches | |
| 2280 MHz | 2535 MHz | 1750 MHz | 200 mm/7.9 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 221 mm/8.7 inches, 155 W | |
| 2280 MHz | 2527 MHz | 1750 MHz | 293 mm/11.5 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 293 mm/11.5 inches | |
| 2280 MHz | 2497 MHz | 1750 MHz | 165 mm/6.5 inches | |
| 2280 MHz | 2512 MHz | 1750 MHz | 238 mm/9.4 inches | |
| 2280 MHz | 2512 MHz | 1750 MHz | 238 mm/9.4 inches | |
| 2280 MHz | 2527 MHz | 1750 MHz | 221 mm/8.7 inches | |
| 2280 MHz | 2550 MHz | 1750 MHz | 320 mm/12.6 inches |
