AMD Radeon R7 240

Graphics Processor
Oland
Cores
320
TMUs
20
ROPs
8
Memory Size
2 GB
Memory Type
DDR3
Bus Width
128 bit
The Radeon R7 240 was an entry-level graphics card by AMD, launched in October 2013. Built on the 28 nm process, and based on the Oland graphics processor, in its Oland PRO variant, the card supports DirectX 12.0. The Oland graphics processor is a relatively small chip with a die area of only 90 mm² and 1,040 million transistors. Unlike the fully unlocked Radeon R7 350X OEM, which uses the same GPU but has all 384 shaders enabled, AMD has disabled some shading units on the Radeon R7 240 to reach the product's target shader count. It features 320 shading units, 20 texture mapping units and 8 ROPs. AMD has placed 2,048 MB DDR3 memory on the card, which are connected using a 128-bit memory interface. The GPU is operating at a frequency of 730 MHz, which can be boosted up to 780 MHz, memory is running at 900 MHz.
Being a single-slot card, the AMD Radeon R7 240 does not require any additional power connector, its power draw is rated at 30 W maximum. Display outputs include: 1x DVI, 1x HDMI, 1x VGA. Radeon R7 240 is connected to the rest of the system using a PCI-Express 3.0 x8 interface. The card measures 168 mm in length, and features a single-slot cooling solution. Its price at launch was 69 US Dollars.

Graphics Processor

GPU Name
Oland
GPU Variant
Oland PRO
(215-0837015)
Architecture
GCN 1.0
Foundry
TSMC
Process Size
28 nm
Transistors
1,040 million
Die Size
90 mm²

Graphics Card

Release Date
Oct 8th, 2013
Generation
Volcanic Islands
(R7 200)
Production
End-of-life
Launch Price
69 USD
Bus Interface
PCIe 3.0 x8
Reviews
5 in our database

Relative Performance

17%
GeForce 210
22%
GeForce 9400 GT
27%
Radeon HD 4550
34%
Radeon HD 5450
40%
Radeon HD 6450
42%
GeForce GT 520
52%
GeForce GT 220
68%
GeForce GT 430
69%
Radeon HD 5570
75%
Radeon HD 4670
79%
GeForce GT 440
81%
GeForce GT 240
93%
GeForce 9600 GT
98%
Radeon HD 5670
100%
Radeon R7 240
106%
GeForce GT 640
109%
GeForce 9800 GT
114%
Radeon HD 6670
117%
Radeon HD 4830
125%
Radeon HD 4770
132%
Radeon HD 4850
135%
GeForce GTS 250
139%
GeForce GTS 450
144%
Radeon HD 5750
164%
Radeon HD 7750
165%
Radeon HD 5770
168%
GeForce GTX 260
170%
Radeon HD 4870
171%
Radeon Vega 8
173%
GeForce GTX 550 Ti
174%
GeForce GTX 650
184%
Radeon HD 5830
194%
Radeon HD 6790
197%
Radeon HD 4890
204%
GeForce GTX 460
206%
Radeon RX Vega 11
208%
GeForce GT 1030
210%
GeForce GTX 275
210%
Radeon HD 7770 GHz Edition
211%
GeForce GTX 280
215%
GeForce GTX 465
225%
Radeon HD 6850
230%
GeForce GTX 285
246%
Radeon HD 5850
251%
GeForce GTX 650 Ti
251%
Radeon HD 7790
261%
Radeon RX 550
262%
GeForce GTX 470
271%
Radeon HD 6870
290%
Radeon HD 5870
299%
GeForce GTX 560 Ti
300%
Radeon HD 4870 X2
306%
GeForce GTX 750 Ti
307%
Radeon HD 6950
318%
GeForce GTX 295
322%
GeForce GTX 650 Ti Boost
324%
Radeon HD 7850
330%
GeForce GTX 480
345%
Radeon HD 6970
352%
Radeon R7 265
358%
Radeon RX 460
358%
Radeon R7 370
359%
GeForce GTX 660
360%
GeForce GTX 570
366%
Radeon RX 560
389%
GeForce GTX 950
392%
Radeon HD 7870 GHz Edition
402%
Radeon R9 270X
406%
GeForce GTX 660 Ti
408%
GeForce GTX 580
412%
GeForce GTX 1050
412%
Radeon HD 7950
421%
Radeon HD 5970
432%
GeForce GTX 760
465%
GeForce GTX 670
478%
GeForce GTX 960
490%
Radeon R9 380
493%
Radeon R9 285
498%
Radeon HD 7970
503%
GeForce GTX 680
514%
GeForce GTX 1050 Ti
528%
GeForce GTX 770
540%
Radeon HD 6990
553%
Radeon R9 280X
561%
GeForce GTX 590
561%
Radeon HD 7970 GHz Edition
622%
GeForce GTX 780
644%
GeForce GTX 1650
684%
Radeon RX 470
694%
Radeon R9 290
731%
Radeon RX 570
740%
Radeon R9 390
744%
Radeon R9 290X
754%
GeForce GTX 970
764%
GeForce GTX TITAN
774%
GeForce GTX 780 Ti
785%
Radeon R9 390X
789%
Radeon HD 7990
792%
Radeon RX 480
799%
GeForce GTX 690
842%
Radeon RX 580
860%
GeForce GTX 980
871%
Radeon R9 FURY
871%
GeForce GTX 1060 6 GB
909%
Radeon RX 590
958%
Radeon R9 295X2
963%
GeForce GTX 1660
974%
Radeon R9 FURY X
991%
GeForce GTX 980 Ti
1016%
GeForce GTX TITAN X
1106%
GeForce GTX 1660 Ti
1106%
GeForce GTX 1070
1177%
Radeon RX Vega 56
1248%
GeForce GTX 1070 Ti
1284%
Radeon RX Vega 64
1302%
GeForce GTX 1080
1302%
GeForce RTX 2060
1355%
Radeon RX 5700
1462%
GeForce RTX 2060 SUPER
1516%
GeForce RTX 2070
1551%
Radeon RX 5700 XT
1569%
Radeon VII
1610%
TITAN X Pascal
1658%
GeForce GTX 1080 Ti
1676%
GeForce RTX 2070 SUPER
1783%
GeForce RTX 2080
1890%
GeForce RTX 2080 SUPER
2086%
GeForce RTX 2080 Ti
Based on TPU review data: "Performance Summary" at 1920x1080
Performance estimated based on architecture, shader count and clocks.

Clock Speeds

GPU Clock
730 MHz
Boost Clock
780 MHz
Memory Clock
900 MHz
1800 MHz effective

Memory

Memory Size
2 GB
Memory Type
DDR3
Memory Bus
128 bit
Bandwidth
28.80 GB/s

Render Config

Shading Units
320
TMUs
20
ROPs
8
Compute Units
5
L1 Cache
16 KB (per CU)
L2 Cache
256 KB

Theoretical Performance

Pixel Rate
6.240 GPixel/s
Texture Rate
15.60 GTexel/s
FP32 (float) performance
499.2 GFLOPS

Board Design

Slot Width
Single-slot
Length
6.6 inches
168 mm
TDP
30 W
Outputs
1x DVI
1x HDMI
1x VGA
Power Connectors
None
Board Number
C552,
C577

Graphics Features

DirectX
12.0 (11_1)
OpenGL
4.6
OpenCL
1.2
Vulkan
1.1.101
Shader Model
5.1

Oland GPU Notes

Architecture Codename: Sea Islands
CLRX Version: GCN 1.0
Graphics/Compute: GFX6 (gfx601)
Display Core Engine: 6.4
Unified Video Decoder: 4.0
Video Compression Engine: 1.0

Retail boards based on this design (34)

Name GPU Clock Boost Clock Memory Clock Other Changes
AREZ R7 240 Low Profile 730 MHz 780 MHz 1150 MHz GDDR5, 5.8 inches/147 mm
AREZ R7 240 Low Profile 730 MHz 780 MHz 900 MHz 6.26 inches/159 mm
AREZ R7 240 Low Profile OC 4 GB 770 MHz 820 MHz 1150 MHz 4 GB, GDDR5, 5.8 inches/147 mm
AREZ R7 240 Low Profile OC 4 GB 770 MHz 820 MHz 900 MHz 4 GB, 6.26 inches/159 mm
ASUS R7 240 1 GB 600 MHz 780 MHz 800 MHz 1024 MB, 5.8 inches/147 mm
ASUS R7 240 Low Profile 730 MHz 780 MHz 900 MHz 6.26 inches/159 mm
ASUS R7 240 Low Profile OC 4 GB 770 MHz 820 MHz 900 MHz 4 GB, 6.26 inches/159 mm
Club 3D R7 240 730 MHz 780 MHz 900 MHz 6.06 inches/154 mm
Digital Alliance R7 240 730 MHz 780 MHz 900 MHz
GIGABYTE R7 240 OC 780 MHz 900 MHz 800 MHz 7.67 inches/195 mm
HIS R7 240 IceQ Boost Clock 2 GB 730 MHz 780 MHz 900 MHz 7.83 inches/199 mm, Dual-slot
HIS R7 240 iCooler Boost Clock 1 GB 730 MHz 780 MHz 1150 MHz 1024 MB, GDDR5, 6.77 inches/172 mm
HIS R7 240 iCooler Boost Clock 2 GB 730 MHz 780 MHz 900 MHz 6.77 inches/172 mm
HIS R7 240 Silence Boost Clock 730 MHz 780 MHz 800 MHz 6.58 inches/167 mm
MAXSUN R7 240 1 GB 730 MHz 780 MHz 1000 MHz 1024 MB, GDDR5, Dual-slot
MSI R7 240 730 MHz 780 MHz 900 MHz 8.19 inches/208 mm, Dual-slot
MSI R7 240 Low Profile 730 MHz 780 MHz 900 MHz 5.67 inches/144 mm
MSI R7 240 Low Profile 4 GB 730 MHz 780 MHz 900 MHz 4 GB, 5.67 inches/144 mm
MSI R7 240 OC 760 MHz 810 MHz 900 MHz 8.19 inches/208 mm, Dual-slot
PowerColor R7 240 OC 750 MHz 800 MHz 900 MHz
Sapphire R7 240 1 GB with Boost 730 MHz 780 MHz 900 MHz 1024 MB, 5.71 inches/145 mm
Sapphire R7 240 1 GB with Boost 730 MHz 780 MHz 1150 MHz 1024 MB, GDDR5, 5.9 inches/150 mm
Sapphire R7 240 2 GB with Boost 730 MHz 780 MHz 800 MHz 5.71 inches/145 mm
Sapphire R7 240 4 GB with Boost 730 MHz 780 MHz 900 MHz 4 GB, 5.71 inches/145 mm
Sapphire R7 240 Low Profile 730 MHz 780 MHz 900 MHz 6.65 inches/169 mm, 2x HDMI
Sapphire R7 240 Platinum Edition 1 GB 730 MHz 780 MHz 1150 MHz 1024 MB, GDDR5, 5.9 inches/150 mm
VisionTek R7 240 Low Profile 730 MHz 780 MHz 900 MHz
VisionTek R7 240 OC 750 MHz 800 MHz 900 MHz
VTX3D R7 240 X-Edition 750 MHz 800 MHz 900 MHz
XFX R7 240 1 GB 730 MHz 780 MHz 800 MHz 1024 MB, 6.9 inches/175 mm
XFX R7 240 2 GB 730 MHz 780 MHz 800 MHz 6.97 inches/177 mm, Dual-slot
XFX R7 240 2 GB 730 MHz 780 MHz 800 MHz 6.9 inches/175 mm
XFX R7 240 BestBuy Exclusive 730 MHz 780 MHz 900 MHz Dual-slot
XFX R7 240 Passive 730 MHz 780 MHz 900 MHz
