At the ongoing CeBIT event, Gigabyte showed off its latest offer of motherboards including an interesting one based on AMD's upcoming 890FX chipset. Made for socket AM3 processors from AMD, the GA-890FXA-UD5 is based on the AMD 890FX chipset with SB850 southbridge. It expands a little on the chipset's features. The CPU is powered by a 10-phase VRM. It is wired to four DDR3 memory slots that are powered by a 2-phase VRM. The AMD 890FX drives four PCI-Express 2.0 x16 slots (electrical x8 when all are populated, x16 on alternate slots otherwise). There are two PCI-E x1 and one PCI. All six of the SATA 6 Gb/s ports from the southbridge are internal, while an additional GSATA2 controller gives out two SATA 3 Gb/s ports, and drives the IDE connector. Connectivity options include 8+2 channel audio with Dolby Home Theater, two gigabit Ethernet interfaces, FireWire, and two USB 3.0 ports, apart from a number of USB 2.0 ports. The board is expected to release later next month.

MSI has undertaken a very interesting project: to use the Lucid Hydra chip on an AMD platform motherboard, its second design with Lucid Hydra. The 870A-GD60 Hydra is a socket AM3 motherboard based on the AMD 870 + SB850 chipset. The AMD 870 chipset succeeds the AMD 770, in being suited for single discrete-graphics setups. The chipset packs no PCI-Express external switching, and hence there is only one PCI-Express 2.0 x16 link it can give to a graphics card. MSI connected this link to a Hydra Engine chip, to give out two full-bandwidth PCI-Express 2.0 x16 links. "Why not simply use the 890FX?" could be a question for many, but its answer lies in Hydra's advantage over it: it allows you to pair two NVIDIA graphics cards, two ATI graphics cards, or even mix an NVIDIA and an ATI card in a mixed multi-GPU array, as has been demonstrated with MSI's P55 Big Bang Fuzion motherboard.

The AM3 socket is powered by a 10-phase DrMOS based VRM. The CPU connects to four DDR3 DIMM slots for dual-channel memory. It connects to the AMD 870 northbridge over the HyperTransport 3.0 interface. Its lone PCI-E 2.0 x16 port is taken up by the Hydra Engine chip located between the two PCI-E 2.0 x16 slots. Other expansion slots include three PCI-E x1, and one PCI. The SB850 southbridge gives out six internal SATA 6 Gb/s ports. Connectivity includes 8 channel HD audio with SPDIF connections, eSATA by an additional controller, FireWire, two USB 3.0 ports, and a number of USB 2.0 ports. The 870A-GD60 Hydra could be released late next month.

At its displays at the ongoing CeBIT event, ASUS surprised many with a pair of Crosshair IV Series motherboards showing a renewed interest at the very high-end of the AMD platform. Incidentally, the company is also preparing a mid-range motherboard based on the AMD 890FX chipset, the M4A89TD PRO. The new board builds entirely on what the chipset has to offer with a slight addition of a two-port USB 3.0 controller. The AM3 socket is powered by a 10-phase VRM, supporting 140W CPUs. It is wired to four DDR3 DIMM slots with its own 2-phase VRM.

The 890FX chipset gives out two PCI-Express 2.0 x16 full-bandwidth slots, other expansion slots include an open-ended PCI-E 1.1 x4, a PCI-E x1, and two PCI slots. All six SATA 6 Gb/s ports the SB850 southbridge gives out are internal, an additional JMicron controller gives out IDE and eSATA. The board boasts of ASUS' "Core Unlocker" switch which simplifies unlocking disabled physical cores on some dual, triple, and quad-core chips. Other features include 7.1 channel audio, gigabit Ethernet, and USB 3.0 for connectivity. The M4A89TD PRO should be released around the time when AMD unveils its latest processors.

Biostar is readying a mid-range motherboard in its T-Series lineup based on AMD's upcoming 890FX + SB850 chipset. The T-Series TA890FXE was pictured at the ongoing CeBIT event without its cooling assembly. It supports existing and upcoming socket AM3 processors, including Phenom II X6. The CPU is powered by a 5+1 phase VRM, supporting 140W processors. The 890FX chipset gives out four PCI-Express 2.0 x16 slots supporting ATI CrossFireX technology, apart from two legacy PCI slots. The SB850 southbridge gives out six SATA 6 Gb/s ports, of which five are internal, probably one external. An additional storage controller by VIA drives the lone IDE connector. 7.1 channel HD audio, gigabit Ethernet, and FireWire make for the rest of it. The TA890FXE is expected to be out later in April, when AMD unveils its latest processors.

ASUS makes a return to the higher-end of the AMD platform with two motherboards in its elite Republic of Gamers (ROG) series, with the Crosshair IV Formula and Crosshair IV Extreme. Both motherboards are based on the AMD 890FX + SB850 chipset, and support socket AM3 processors. While the Crosshair IV Formula targets high-end gaming builds, the Crosshair IV Extreme goes all out to woo overclockers. The Crosshair IV Formula, to begin with, has six expansion slots, of which four are PCI-Express 2.0 x16 (operating at x8 when all are populated, or x16, NC, x16, NC), and two PCI slots. The SB850 southbridge gives out six SATA 6 Gb/s ports, while an additional controller gives out two 3 Gb/s ports (one being eSATA). The CPU is powered by a 10+2 phase VRM, with two phase memory power. Connectivity includes 8+2 channel audio with SPDIF connectivity, gigabit Ethernet, FireWire, eSATA, two USB 3.0 ports, and a number of USB 2.0 ports. The board supports the iROG feature, along with a host of other overclocker-friendly features.

The Crosshair IV Extreme, on the other hand, is probably the most complex motherboard for the AMD platform. Apart from overclocker-friendly features of the C-4 Formula, C-4 Extreme adds a wide range of electrical enhancements that include better power conditioning with Super ML capacitors, PWM circuitry, voltage measure points, ProbeIT feature, PCI-Express electrical control switches, iROG Bluetooth device control, physically redundant BIOS ROM chips, and a number of other features. The board itself is closer to being EATX sized. There are four PCI-Express x16 slots here too, but with 1U spacing between them. An open-ended PCI-Express 1.1 x4 and PCI make for the other slots. There are six SATA 6 Gb/s ports here, too, with additional SATA 3 Gb/s controllers, and connectivity largely identical to that of the C-4 Formula. We presume ASUS will release these two in late April, around the time when AMD rolls out its Phenom II X6 processors. Pictured in order (below) are the C-4 Formula and C-4 Extreme.Images Courtesy: Tweakers.net, Lab501.ro

MSI seems to have finalized design of its first motherboard based on the AMD 890FX chipset, the 890FXA-GD70. A possible prototype of this, then called the 890FX-GD70, was pictured back in early December, 2009. The 890FXA-GD70 has five PCI-Express 2.0 x16 slots in all. Their electrical configuration, when all are populated, could be x8, x8, x8, x8, 1.1 x4, or x16, NC, x16, NC, 1.1 x4, supporting ATI CrossFireX. A PCI-E x1 and PCI make for the other two expansion slots. A large rectangular heatsink cools both the AMD 890FX chipset, and the 8-phase VRM, while a heat pipe connects this to the heatsink over the SB850 southbridge chip. The CPU is connected to four DDR3 memory slots with one-sided retention clips that don't come in the way of graphics cards in the first slot.

The SB850 gives out six SATA 6 Gb/s ports with RAID 0, 1, 0+1, 5, 10, JBOD support, while a JMicron made controller gives out an additional SATA 3 Gb/s port, an IDE connector, and possibly an eSATA connector. Connectivity options include 8+2 channel HD audio with optical and coaxial SPDIF connections, two gigabit Ethernet interfaces, two USB 3.0 ports (and a number of USB 2.0 ports), FireWire, and eSATA. This motherboard is ready for upcoming Phenom II X6 and Phenom II X4 processors, apart from existing processors in the AM3 package. It should be released in time for the six-core chips, late April.

GIGABYTE TECHNOLOGY Co., Ltd, a leading manufacturer of motherboards, graphics cards and other computing hardware solutions today proudly launched their latest AMD AM3 Socket GA-890GPA-UD3H motherboard, delivering loads of performance enhancing bandwidth for applications such as high end gaming and high speed data transfer on systems featuring new AMD 6 core CPUs.

The first motherboard featuring the AMD 890GX chipset paired with the all new SB850 South Bridge, the GIGABYTE GA-890GPA-UD3H offers the industry's first native support for Serial ATA 6Gbps for up to 6 devices. The AMD SB850 also offers the industry's first Serial ATA 6 Gbps RAID support, allowing users to configure RAID 0,1,5 and 10 for maximum data performance or enhanced data backup. Also equipped with GIGABYTE 3x USB Power Boost and USB 3.0 support by utilizing the industry-leading NEC controller, the GIGABYTE GA-890GPA-UD3H ensures users are ready to take advantage the next wave of high speed data transfer and storage technologies.

Sapphire is readying a bundle of interesting new graphics products to be unveiled at this year's CeBIT event. Two such products that stand out include a non-reference design Radeon HD 5970 accelerator with 4 GB of GDDR5 memory (2 GB per GPU), and the HD 5870 Eyefinity6 2 GB. The HD 5970 model is particularly interesting, as its rival in the field, ASUS, will be showing off a similar accelerator called the ROG Ares "dual HD 5870" accelerator. Sapphire however, prefers to call its creation a custom Radeon HD 5970. It is expected to feature custom cooling, increased clock speeds (and probably overclocking headroom), and twice the amount of memory. There is a likelihood that Sapphire designs this along the lines of its high-end "Atomic" series that includes watercooling, and other exclusive features.

The other offering by Sapphire of course is the HD 5870 Eyefinity6. Probably sticking to AMD's reference design, the Eyefinity6 card is optimised for ATI Eyefinity setups with up to six physical displays. The card has six mini DisplayPort connectors, with which it can connect to each of its display heads. It features 2 GB of GDDR5 memory across a 256-bit wide interface. Using AMD Cypress GPU, it packs 1600 stream processors, 80 TMUs, and 32 ROPs. At the same event, Sapphire will show off several other of its new creations, such as the N450 netbook, Mini Projector 101, and mini-ITX form-factor motherboards supporting socket AM3.

American retailer Newegg.com has started listing Gigabyte's GA-890GPA-UD3H motherboard, one of the first motherboards based on the AMD 890GX + SB850 chipset. This socket AM3 motherboard boasts of native SATA 6 Gb/s support, USB 3.0, Radeon HD 4250 integrated graphics, at a price of $139.99. The GA-890GPA-UD3H supports socket AM3 AMD Athlon II and Phenom II series processors, including support for the upcoming Phenom II X6 six-core processors. It also supports dual-channel DDR3 memory at speeds of over 1866 MHz by overclocking. Expansion slots include two PCI-Express 2.0 x16 (electrical x8/x8 when both are populated), three PCI-E x1, and two PCI, bringing CrossfireX support. The SB850 gives out six SATA 6 Gb/s ports with RAID 0, 1, 0+1, 5, 10, and JBOD modes. An NEC-made USB 3.0 controller also provides two USB 3.0 ports. The IGP connects to displays over D-Sub, DVI, and HDMI. Presumably, this could be the starting point for more AMD 890GX based motherboards to reach stores world over.

EKL brand Alpenföhn unveiled its newest CPU cooler, the Matterhorn. This cooler measures 138 x 100 x 158 mm, and weighs 1067 g (2.35 lbs). The construction is similar to that of several coolers in its category. A pre-lapped copper base draws heat from the CPU. From this, six heatpipes pass, conducting heat to a block of aluminum fins. The fins have notches that help heat dissipation over the air being blown by an attached Föhn120 Wing Boost 120 mm fan, which spins at 500 to 1500 rpm, with a max noise output of 24.8 dBA. The Matterhorn supports most current CPU sockets including LGA-1366, LGA-1156, LGA-775, AM3, AM2(+). Its price and availability are yet to be known.

ASUS seems to be ready with one of its first motherboards based on the AMD 890GX chipset. This socket AM3 series of motherboards seems to come in two variants: M4A89GTD Pro and M4A89GTD Pro USB3 (with the latter having support for USB 3.0 SuperSpeed connectivity. An early development version of this motherboard was displayed at this year's CES event. Fresh pictures show a production-grade model, complete with chipset and VRM cooling, as well as a box design.

The M4A89GTD Pro / USB3 is a socket AM3 motherboard with a 10-phase CPU VRM supporting future AMD CPUs with 140W TDP, 2-phase memory VRM powering the four DDR3 DIMM slots, AMD 890GX chipset with faster DirectX 10.1 compliant graphics, and AMD SB800 southbridge. The SB800 provides six SATA 6 Gb/s ports, while an additional JMicron-made controller gives out the IDE connector (and possibly the lone eSATA port). Expansion slots include two PCI-E 2.0 x16 slots (x8/x8 when both are populated), two PCI, and one each of PCI-E x1 and PCI-E x4. Connectivity includes 8+2 channel HD audio with optical SPDIF output, gigabit Ethernet, USB 3.0 ports (on the USB3 variant), FireWire, and display connectivity including DVI, D-Sub, and HDMI. The M4A89GTD Pro / USB3 is expected to be launched a little ahead of AMD's launch of its six-core Phenom II X6 processors.

AMD's upcoming six-core desktop processor, the Phenom II X6, will introduce a new feature to the Phenom II series, currently known as "C-state performance boost". The feature gives the processor control over individual cores' power states, and the ability to gate power down completely a core. The remaining active core(s), will then be overclocked beyond the normal clock speeds, so that low-power operation with reduced parallel computing load goes on with much lesser energy consumption.

Features such as C-state performance boost and 'power-gating' is relatively new for AMD processors. The two were originally expected to be introduced with AMD's 32 nm "Llano" Fusion APUs. AMD's Phenom II X6 is expected to be released in May 2010, its architecture is derived from the six-core "Istanbul" Opteron processors, albeit in the socket AM3 package that supports dual-channel DDR3 memory. There are as many as four models in the works for an initial release. Known details of these can be found here.

Koolance rolled out its newest CPU water-block, the CPU-360. The new block boasts of broad compatibility with all current CPU socket types, an advanced microfin cold plate with 0.25mm fins, 0.30 mm channels, and an optimized flow path. The cold plate is complemented with a brass top, all metal surfaces have nickel plating to minimize corrosion. The block measures 4.9" x 4.9" x 0.6" (12.5cm x 12.5cm x 1.5xcm), and weighs 411 g (14.5 oz). While the package excludes nozzles, it includes all the retention material needed for Intel sockets LGA-775, LGA-1156, LGA-1366, and AMD sockets AM3/AM2+/AM2. The CPU-360 is listed on Koolance website at US $84.99.

Gigabyte is ready with its first motherboard based on the AMD 890GX + SB800 chipset. The GA-890GPA-UD3H supports socket AM3 AMD Athlon II and Phenom II series processors, including support for AMD's upcoming six-core processors. The CPU is powered by a 5-phase VRM, it is wired to four DDR3 DIMM slots to support dual-channel memory with speeds of over DDR3-1866 MHz by overclocking. The AMD 890GX northbridge embeds a faster DirectX 10.1 compliant integrated graphics with display connectivity including DVI, D-Sub, and HDMI (with 7.1 audio pass).

Expansion slots include two PCI-Express 2.0 x16 (electrical x8/x8 when both are populated), three PCI-E x1, and two PCI. The new SB800 southbridge gives out six SATA 6 Gb/s ports. An additional Gigabyte GSATA2 controller gives out two SATA 3 Gb/s ports and an IDE connector. An NEC-made USB 3.0 controller further provides two external USB 3.0 ports (color-coded blue), next to a number of USB 2.0 ports. 8-channel audio with Dolby Home Theater support, and gigabit LAN make for the rest of it. The board seems to make use of the Ultra Durable 3 Classic construction. Expect the board to be out later this year.

Coolink today introduced its new Corator DS CPU-Cooler. Featuring Coolink's exclusive Gapless Direct Touch (GDT) technology that allows for an all copper contact area, the Corator DS brings the concept of direct contact cooling to the next level by further improving heat transfer. Four large 8mm heatpipes, a dual fin stack design and a PWM controlled SWiF2 120mm fan are among the features that enable the Corator DS to achieve an optimal balance between outstanding cooling performance and quiet operation.

"True to our vision of innovating instead of following, we worked hard to strengthen the advantages of direct contact cooling and to eliminate its drawbacks", explains Timothy Chu, Coolink CEO. "Thus we're proud to introduce the Corator DS today, which is our first product based on Coolink's exclusive GDT-technology. Its innovative contact surface in combination with the other features allows us to offer a complete high-performance cooling solution at an attractive price point".

Scythe is announcing today a new High-End TOP-Flow CPU Cooler by the name "Grand Kama Cross", which is the successor of former Kama Cross CPU Cooler. Grand Kama Cross is based on an X Structure layout using total of four 8 mm copper heatpipes for fast transfer of heat from the copper base to the aluminum fins. Thanks to the X Structure Design, easier mounting on CPU sockets as well as higher compatibility to tall RAM and Northbridge coolers are accomplished. By using the angled fin shape, airflow is redirected to allow additional cooling of surrounding components such as RAM, Northbridge and Voltage Regulators. For the optimum airflow, new Slip Stream 140 mm fan is first introduced with Grand Kama Cross CPU Cooler. PWM support allows flexible fan speed in a range between 500 and 1,300 rpm, automatically controlled by the motherboard creating airflow from 46 to 119 m³/h and accordingly 27.2 to 69.93 CFM. Both Slip Stream 140 mm fan and Grand Kama Cross CPU Cooler are using standard 120 mm fan mounting holes which allow the use of common aftermarkets 120 mm case fans as a replacement.

At the ongoing CES event, ASUS displayed some of its upcoming motherboards which included the M4A89GTOD PRO, an ATX form-factor model based on the AMD 890G chipset. The AMD 890G seems to be a successor to the AMD 790GX, in being a performance integrated graphics part. It integrates a DirectX 10.1 compliant IGP while supporting discrete graphics with 2-way ATI CrossFireX.

The M4A89GTOD PRO comes with an expansive feature-set thanks to the AMD 890G. The more interesting component being the AMD SB800 southbridge chip, which is on its way to being one of the first PC motherboard chipsets to natively support SATA 6 Gb/s. The chip doles out six SATA 6 Gb/s ports, while doing away with its on-die IDE controller. An external JMicron-made storage controller compensates with an IDE connector, a SATA 3 Gb/s port (colored black) and perhaps an eSATA port (at 3 Gb/s speeds), too.

Thermaltake seems to have finished development of its new high-end CPU cooler, the Thermaltake Frio. Designs of this cooler surfaced as early as in June this year, originally slating it for Computex 2009. After some development delay, it has finally taken shape with the disctinct black+red color scheme the company's Level 10 case comes with. The design consists of a CPU contact block from which five seemingly 8 mm heatpipes arise, conveying heat to a dense aluminum fin array which has largely rectangular fins. The array is cooled a 120 mm fan. There is provision to install one on either sides, that rotates at speeds between 1200 - 2500 rpm. The cooler supports all current CPU sockets, including LGA-1366, LGA-1156, LGA-775, AM3/AM2+. The cooler is now slated for CES 2010.

Spire Corp. today officially launched its new TherMax Eclipse towering CPU Cooler. Following up to the success of the original TherMax we're proudly intruducing the TherMax Eclipse. Powered by Innovation and with awesome looks this CPU Cooler is one supreme performer. The TherMax Eclipse is ready to best cool the 130W and upcoming extreme hot 130W Micro-processors.

Universally compatible with the Intel 1156/1366/775 platforms in combination with the AMD AM3/AM2/940/939 platforms giving professionals and gamers a huge scope to utilize this impressive diablo. Another welcome new feature are the possibility of mounting two fans simultaneously for even better cooling results. Simply installed with the included Anti-vibe rubber fan mount s installation is made easy. This towering cooler is build to deliver the best thermal performance.

Corsair, a worldwide leader in high-performance computer and flash memory products, today announced the launch of its new Dominator GTX ultra-high performance DDR3 memory modules for Intel and AMD platforms, designed specifically for performance enthusiasts, gamers and extreme overclockers.

Corsair Dominator GTX modules are individually screened and tested on multiple high-performance Intel X58 and P55 chipset platforms to ensure that they operate at the incredible frequency of 2250MHz at low-latency timings of 8-8-8-24 at 1.65V. They are designed specifically for performance enthusiasts and overclockers who want to achieve the highest performance possible and to break benchmark world records.

ASUS slipped in no less than three value micro-ATX motherboards based on the AMD 760G + SB710 chipset. Two of these, the M4A78L-M LE, M4A78L-M use socket AM2+ to connect to existing AM3 and older AM2(+) processors supporting DDR2 memory, while a third one, the M4A78LT-M LE uses AM3 socket to support AM3 processors and DDR3 memory. All three feature ASUS exclusive features such the EPU (energy processing unit), ExpressGate instant-on OS, and a 'Turbo-key' push-button overclocking feature. All three are to an extant similar, in having two DIMM slots for dual-channel memory, one each of PCI-Express x16, x1, and two PCI, and have an ATI Radeon HD 3000 class IGP.

The differences start with the M4A78L-M LE and M4A78LT-M LE being more office-oriented, with display connectivity being confined to D-Sub, or DVI, presence of legacy serial and parallel ports, a simpler 6-channel audio, and 4-phase CPU VRM, while retaining essential connectivity of the southbridge, including six SATA 3 Gbps ports, and one IDE connector for running two ATA devices. The M4A78L-M is slightly more consumer / home-user oriented, with better display connectivity that includes D-Sub, DVI, and HDMI, 8-channel audio with optical SPDIF output, and a slightly more powerful 4+1 phase VRM. The M4A78L-M LE, M4A78L-M and M4A78LT-M LE are priced at £42.42, £47.87 and £51.68, respectively.

Gigabyte is readying the industry's first socket AM3 motherboard that offers the new connectivity features combo that is turning out to be quite a selling point in itself: USB 3.0 and SATA 6 Gbps. Enter GA-790FXTA-UD5P, a high-end socket AM3 motherboard based on the AMD 790FX + SB750 chipset, that isn't just a revised GA-MA790FXT-UD5P. Apart from the star attractions of USB 3.0 and SATA 6 Gbps, the board features a redesigned expansion slot layout, among other new features. The socket AM3 motherboard supports AMD Phenom II AM3 and Athlon II series processors with support for dual-channel DDR3 memory.

To begin with, the CPU is powered by a 8+2 phase VRM supporting 140W processors, with a 2 phase VRM powering the four DDR3 DIMM slots. The board supports DDR3-1866 by overclocking, while DDR3-1333 and DDR3-1066 are naturally supported. A Precision OV controller provides fine (small step) voltage control for the CPU, memory and chipset voltages. Instead of two PCI-Express 2.0 x16 slots on the MA-790FXT-UD5P, this board features three PCI-Express 2.0 x16 slots (electrical x16, x16, NC, or x16, x8, x8, depending on how they're populated). Each x16 slot as one slot spacing which is occupied by a PCI slot. A lone PCI-E x1 slot heads the pack.

MSI is readying the 770-G45 motherboard, which supports socket AM3 Phenom II and Athlon II series processors from AMD. This is the third in the series of motherboards recently launched by MSI, to be based on the AMD 770 chipset, albeit being the most feature-rich of the lot. The other offerings being 770T-C45, and 770-C35. The motherboard makes use of AMD's SB710 southbridge, and hence supports the ACC feature. The more important feature however, is the provision of two PCI-Express x16 slots, supporting ATI CrossfireX. The second slot however, seems to be wired to the southbridge, and electrical PCI-Express x4.

The CPU is powered by a simple 6 phase VRM circuit, supporting the Active Phase Switching feature, it is wired to four DDR3 DIMM slots to support dual-channel memory. All six SATA 3 Gb/s ports are internal. A PCI-E x1 and three PCI slots make for the rest of the expansion. Connectivity includes gigabit Ethernet, a serial port, and a number of USB 2.0 ports. The OC Switch feature aims to simplify overclocking. Ideally, this motherboard should make it around the $100 price point, though the price isn't known at this point.

Noctua today announced a new special edition of its popular NH-U9B premium cooler, which is renowned for providing excellent quiet cooling performance in a compact package that lends itself to use in HTPCs or smaller cases. The new NH-U9B SE2 now comes with two of Noctua's award-winning NF-B9 92mm fans and adds support for LGA1156 as well as LGA1366 via the latest SecuFirm2 multi-socket mounting system.

"Many customers who are looking for a premium quality quiet cooler but can't accommodate our larger models are choosing our NH-U9B, which offers performance levels close to its bigger brothers while being much more compact", explains Mag. Roland Mossig, Noctua CEO "Given the ongoing popularity of the NH-U9B, we've decided to create a special edition that comes with a second NF-B9 fan and provides support for the latest CPUs."

AMD today made its RB-C3 revision of the Phenom II X4 965 Black Edition quad-core processor official. Carrying a characteristic model number of HDZ965FBK4DGM compared to HDZ965FBK4DGI the older C2 revision. Another important specification change is the TDP, now rated at 125W compared to 140W on the C2. Built on the 45 nm SOI Deneb die, the Phenom II X4 965 Black Edition runs at a clock speed of 3.40 GHz (17.0 x 200 MHz). Each core has 128 KB of L1 and 512 KB of dedicated L2 cache. The four cores share an L3 cache of 6 MB. Based on the socket AM3 package, the new CPU typically supports DDR3 and DDR2 memory on socket AM2+ motherboards. It is priced on par with its 140W twin, at US $196.Image Courtesy: OverclockersClub
