ASUS Launches the Radeon HD 7970 DirectCU II TOP Graphics Card

Ushering the finest and most capable graphics card based on new AMD "Tahiti" 28nm GPUs, the ASUS HD 7970 DirectCU II TOP uses a factory-overclocked core and 3 GB of GDDR5. It is cooled by the exclusive DirectCU II, a dual fan thermal design with six copper heatpipes and a large dissipation area that leads to the lowest temperatures and quietest operation of any HD 7970 card.

ASUS DIGI+ VRM 12-phase digital power delivery comes to graphics cards improved with Super Alloy Power components, while overclockers are bound to appreciate the inclusion of exclusive VGA Hotwire hardware overvolting and GPU Tweak software tuning. The new cards further support adapter-free AMD Eyefinity 6.

PowerColor Previews its LCS HD7970 Graphics Card

More Tahiti goodness is coming up as PowerColor has confirmed with a nice clear photo that it's working on a watercooled Radeon HD 7970 card. Dubbed LCS (Liquid Cooling System) HD7970, the card comes equipped with a (single-slot) waterblock from Slovenia's own EK team.

PowerColor's watercooled card also features 2048 Stream Processors, a 384-bit memory interface, 3 GB of GDDR5 VRAM, DVI, HDMI and dual mini DisplayPort outputs, plus DirectX 11.1 capabilities, CrossFireX support, and a PCI-Express 3.0 interface. No word on the card's clocks (yet) but they should be higher than on stock models. Expect more info later this month.

Mouse Computer Launches New Desktops with 23-inch IPS Displays

Japanese company Mouse Computer announced two new desktop PC models featuring the latest hardware and Iiyama ProLite X2377HDS-B IPS LED-backlit LCD display. The 23-inch IPS display provides 1920 x 1080 resolution with a response time of 5 ms. The first of the two desktops featuring it is the LM-iS615B-P23S, and the other is LM-i735X-P23S (pictured in this order below).

The LM-iS615B-P23S features a micro-ATX slim-tower measuring 100 x 393 x 364 mm (WxDxH). It is driven by Intel Core i5-2500 processor, with 8 GB dual-channel DDR3-1333 memory. It lacks discrete graphics, and relies on the embedded Intel HD 3000 graphics. Storage is care of a 500 GB 7200 RPM HDD and DVD-RW drive. It is powered by a 300W PSU. Windows 7 Home Premium x64 is the OS of choice.

Single Fan Non-Reference Design Sapphire Radeon HD 7950 Pictured

A little earlier this month, we were treated to pictures of Sapphire's dual-fan Radeon HD 7950 OC graphics card. It appears that the card pictured earlier is not the only non-reference design HD 7950 from Sapphire, as it has a slightly more affordable single-fan model in the works. This model likely sticks to AMD reference clock speeds of 800 MHz core, 1250 MHz (5.00 GHz GDDR5 effective) out of the box.

The single-fan HD 7950 appears to have a blue-colored PCB that is likely to be AMD's cost-effective reference design. The cooler appears to have a compact heatsink that is cooled by a single central fan. Display outputs include two mini-DisplayPort, and one each of HDMI and DVI. We're also hearing from the source that 900 MHz core with unchanged (1250/5000 MHz) memory will be the maximum factory-OC permitted by AMD to AIB partners. That is not to say that the HD 7950's OC potential beyond that will be limited in any way.

Update: Augmented with more images from Expreview.

Sapphire HD 7950 3 GB Pictured

Pictures of the Sapphire HD 7950 3 GB graphics card have been leaked on the Guru3D forum by user asder00. No further details or specifications were given other than "Product name: Sapphire HD7950 3G GDDR5 PCI-E HDMI/DVI-I/DUAL MINI DP OC VERSION".

As can be seen by the cooler, this is a non-reference design - at least for the cooler. The cooler is coloured black, has a very modern, sharp, angular and somewhat futuristic look to it and sports two large Sapphire-branded fans. Of course, it has heatpipes and five are visible. The design of this cooler suggests that it should work quietly and cool efficiently. Connectivity is aided and abetted by one DVI port, one full size HDMI port and two mini-DisplayPorts, like on its bigger brother the HD 7970. Moving on to the box, one can see that it has a 384-bit bus and 3 GB GDDR5, again like the HD 7970. The box also shows a logo with "OverClock" written boldly in white on it. The inevitable attractive lady box art in this instance has her wearing a grey top, a partial face mask and a helmet from what looks like the wars of yesteryear, plus she is carrying a rifle over her shoulder.

Yeston AMD Branded Cost-Effective Tahiti PCB Pictured with Components Placed

Chinese AMD Radeon add-in board (AIB) partner and motherboard major Yeston, displayed a Radeon HD 7970 PCB, which bears the AMD branding, and is reportedly AMD's cost-effective "Tahiti" PCB. It is quite likely that this PCB will be used for Radeon HD 7950, apart from affordable HD 7970 cards. Radeon HD 7950, like its costlier sibling, will have a 384-bit wide GDDR5 memory interface.

Its designers seems to have done some clever cost-cutting which will make cards based on it more affordable (or at least more profitable), without sacrificing quality much. The PCB uses a 8+1+1 phase VRM, consisting of cost-effective ferrite core chokes, LFPAK MOSFETs, and probably a UPI-made VRM controller. Yeston will most likely use a top-flow cooler, and hence made room for two DVI connectors next to one each of HDMI 1.4a and standard DisplayPort 1.2. The dual-BIOS feature of AMD's high-end reference HD 7970 PCB is blanked out on this PCB.

GIGABYTE Introduces Cutting Edge Mobile Products at CES 2012

GIGABYTE today announced an outstanding lineup of ground breaking mobile computers at CES 2012. All products feature GIGABYTE's longstanding commitment to technological prowess in terms of quality, performance and design. Exciting products to be introduced at CES include the S1081, a 10.1" powerful slate for productivity; and the T1006M, an extraordinary 10.1" convertible tablet notebook. Other products to be presented are the Booktop T1132N, an 11.6" revolutionary 3-in-1 notebook, tablet and desktop; the P2532F, a 15.6" blazing fast Blu-ray gaming and multimedia notebook; and the Booktop M2432, a 14" notebook that delivers the perfect combination of style and performance.

AMD Slips Out Radeon HD 7670 to OEMs

Without making any noise, AMD rolled out an OEM-exclusive graphics card model, the Radeon HD 7670. This GPU is completely identical to the previous-generation Radeon HD 6670, making it a rebrand. It has identical specifications to the 40 nm Turks GPU, which drives the retail HD 6670, with 480 VLIW5 stream processors, a 128-bit wide GDDR5 memory interface holding 512 MB or 1 GB of memory, 24 TMUs, 8 ROPs, and clock speeds of 800 MHz core, and 4.00 GHz memory. This GPU was featured on some of HP's desktop PC products. The product page of this OEM-only GPU can be found here.

MSI Launches GT685 Gaming Laptop

MSI is rolling out its new generation GT685-the ultimate gaming machine. In addition to featuring the Intel second generation Core i7 quad core processor, it is the first laptop to sport the nVidia GeForce GTX 580M, the world's fastest discrete graphics card, 32G DDR3 of memory, and accelerated dual hard disk architecture. It comes with Dynaudio and THX TruStudio Pro smart wrap around sound as well as a full HD screen. You'll be impressed by how smoothly online 3D games play and with the edge that your new GT685 gives you against opponents.

The machine won the CES 2012 award for product innovation, seen by many as the highest honor of the high tech industry. MSI, where designing high-end record-breaking gaming notebooks is par for the course, will continue to design faster, more powerful notebooks that follow in the tradition of its gaming NBs best epitomized in the MSI GT685. The GT685 utilizes the wildly anticipated nVidia GeForce GTX 580M top-end discrete graphics card which boasts 384 more CUDAs (Compute Unified Device Architecture) than the previous generation with advanced 256 bit broadband and 2GB GDDR5 of display memory. You will be awed by how smooth 3D games run and the new edge you enjoy in battles will help you rack up wins.

AMD Radeon HD 7970 Overclocked to 1.70 GHz Core, 8.00 GHz Memory, Benchmarked

So you thought the 1.26 GHz core - 6.30 GHz memory feat was quite something, considering that Sapphire already has a card in the works that does 1.33 GHz core 5.73 GHz memory out of the box? Wait till you see the numbers an overclocker for the MyDrivers community achieved. With the right voltage assistance, coupled with the right kind of cooling (liquid nitrogen), the overclocker achieved a Radeon HD 7970 overclocked speed as high as 1700 MHz core, and 2000 MHz (actual) or 8.00 GHz effective GDDR5 memory speed, churning out memory bandwidth of exactly 384 GB/s. The best part is that this wasn't a hit-and-run feat, the setup was able to run 3DMark 11 and 3DMark Vantage. The scores are pictured below. Details of the volt-mod can be found at the source.

Gigabyte Radeon HD 7970 Custom-Design Graphics Card Pictured

Here is the first picture of a non-reference design Radeon HD 7970 graphics card. Made by Gigabyte, the GV-R797OC-3GD is a factory-overclocked graphics card, which makes use of a custom Ultra Durable VGA+ PCB by the company, and a custom-design triple-fan WindForce cooler. Its Ultra Durable VGA+ PCB makes use of 2 oz copper layer for better electrical stability and heat distribution, ferrite-core chokes, low RDS (on) MOSFETs, hand-picked high-performance GDDR5 memory chips, etc.

The cooler makes use of a combination of heatsinks and aluminum fin arrays to which heat from the GPU, memory, and VRM is fed by copper heat-pipes, and ventilated by three fans. Gigabyte also has a reference-design graphics card, which uses a reference-design cooling assembly, and most likely also a reference design PCB, except that it's colored red. It's not likely that red color PCB will be standard among AIB-branded retail cards, because the HIS and MSI cards pictured by OCUK recently, were found to have black-colored ones. There's no word of the pricing or clock speeds.

Sapphire Readies Radeon HD 7970 Cards with 1335 MHz Core Clock, 6 GB Memory

It looks like AMD's claims of HD 7970's extreme overclocking capabilities weren't the usual PR hoopla. A confidential company document revealing the non-reference models Sapphire has in the works, got leaked to the web, and it is a bundle of surprises. To begin with, Sapphire plans no less than six non-reference Radeon HD 7970 models apart from the vanilla AMD reference design card. Among these, the top-of-the-line cards are codenamed "Atomic RX" and "Atomic WC". One can guess that the "RX" is an air-cooled card, and the "WC" a water-cooled one. It packs blistering clock speeds of 1335 MHz core, with 5735 MHz (1433 MHz actual) memory.

The other card that caught our eyes is codenamed "FLEX 6G". The Flex variant typically features a flexible display output configuration. This card is said to have six mini-DP connectors. While this card sticks to AMD reference clock speeds, it packs a whopping 6144 MB of video memory, all wired to a single GPU. While 4 Gbit GDDR5 chips don't exist, we expect Sapphire to be using 24 * 2 Gbit chips on this card, with twelve sets of two chips sharing 32 bit paths. Then there are other milder factory overclocked cards apart from the Atomic; there's Toxic 3G, and VaporX 3G, both packing impressive out of the box clock speeds.

MCJ Intros NextGear-Note i950PA5-SP Gaming Notebook

Mouse Computer Japan (MCJ) introduced its latest notebook for gamers on the move, the i950PA5-SP. With its 17.3-inch form-factor, it classifies more as a desktop replacement, making it quite the LAN Party-animal. Under its hood is an Intel Core i7-2960XM quad-core processor clocked at 2.70 GHz (3.70 GHz max. turbo), a whopping 32 GB of RAM, two Intel SSD 320 series 120 GB drives in RAID 0, NVIDIA GeForce GTX 580M graphics with 2 GB GDDR5 memory, Blu-ray writer, WiFi b/g/n, and Bluetooth 3.0. The 17.3-inch display packs a resolution of 1920 x 1080 pixels. The i950PA5-SP is priced at 299,880 JPY, that's US $3,850.

Radeon HD 7950 Specifications Leaked

Last Thursday, AMD launched the Radeon HD 7970 graphics card based on its new 28 nm "Tahiti" silicon, but it remained tight-lipped about the specifications of the more important SKU that will be based on it, the Radeon HD 7950. The HD 7970 will carry a launch price of US $550, making the HD 7950 an SKU to watch out for. According to details released by XTReview, the "Tahiti Pro" or HD 7950 will be carved out this way:
  • 1792 stream processors, 28 GCN compute units
  • 112 TMUs, 32 ROPs (derived)
  • 384-bit GDDR5 memory interface
  • 3 GB memory, memory clock around 5.00 GHz
The core clock speed, the exact memory clock speed, and more importantly, the target price-point, remain unknown. The Radeon HD 7950 is expected to be launched on the 9th of January.

AMD Dual-GPU Radeon HD 7990 to Launch in Q1 2012, Packs 6 GB Memory

Even 12 months ago, an Intel Nehalem-powered gaming PC with 6 GB of system memory was considered high-end. Now there's already talk of a graphics card taking shape, that has that much memory. On Thursday this week, AMD launched its Radeon HD 7970 graphics card, which features its newest 28 nm "Tahiti" GPU, and 3 GB of GDDR5 memory across a 384-bit wide memory interface. All along, it had plans of making a dual-GPU graphics card that made use of two of these GPUs to give you a Crossfire-on-a-stick solution. AMD codenamed this product "New Zealand". We are now getting to learn that codename "New Zealand" will carry the intuitive-sounding market name Radeon HD 7990, and that it is headed for a Q1 2012 launch.

This means that Radeon HD 7990 should arrive before April 2012. Tests show that Tahiti has superior energy-efficiency compared to previous-generation "Cayman" GPU, even as it has increased performance. From a technical standpoint, a graphics card featuring two of these Tahiti GPUs, running with specifications matching those of the single-GPU HD 7970, looks workable. Hence, there is talk of 6 GB of total graphics memory (3 GB per GPU system).

Club3D Radeon HD 7970 Graphics Card Pictured

Although AMD's Radeon add-in board partners (AIBs) are still "under oath" (read: NDA) not to disclose their products before the 9th of January, Club3D's Radeon HD 7970 press-shots still made it to the web. Pictured below are the Club3D Radeon HD 7970 graphics card and its box-art. The box art is typical Club3D, nothing exceptionally new there. The card, too, sticks to AMD's reference board design, till the point where it uses a red-colored PCB instead of a black one (found on AMD's HD 7970 press samples).

Based on the 28 nm "Tahiti" silicon, Radeon HD 7970 is the first DirectX 11.1 compliant graphics card, it packs 2048 GCN cores, and 3 GB of GDDR5 memory across a 384-bit wide memory interface. The core is clocked at 925 MHz, and the memory at 1375 MHz (5.50 GHz). It is expected that this card will stick to the price AMD disclosed, around US $550.

MSI Announces GT780DX Gaming Notebook

What makes the GT780DX as the gamers' ultimate weapon? In terms of power, it features the Intel Core i7 quad core CPU and latest NVIDIA's top-end GeForce GTX 570M discrete graphics card with 3 GB of GDDR5 display memory, giving it superior performance, so you can enjoy smooth graphics even when playing the latest games in high resolution. The impressive performance also serves to greatly enhance game realism and make these machines the ultimate weapons for the extreme gamer.

Eric Kuo, associate vice president for global sales, MSI Notebook, explains that the latest GT780DX not only packs performance to keep the extreme gamer engaged, it also comes with a SteelSeries keyboard specifically designed for serious gaming. The new keyboard is much more rugged and the new design better meets the needs of extreme gamers to give you the edge in the heat of battle. MSI has also incorporated Dynaudio and THX TruStudio Pro envelope-pushing sound technologies for a riveting audio experience. Designed both inside and out for gaming, the GT780DX has got your back when you're hip-pocket deep in goblin blood.

Cost-Effective Radeon HD 7900 PCB Already In The Works

A little earlier today, we showed you pictures of AMD's first Radeon HD 7900 series single-GPU PCB that makes use of digital-PWM power delivery. Some of the first batches of Radeon HD 7900 graphics cards will stick to that PCB and board design, as it's backed by AMD's engineering. Even as the SKU's launch is less than 24 hours away, there are pictures of AMD's cost-effective Radeon HD 7900 PCB surfacing on Asian media sites. Once ready, AMD add-in board partners can opt for this cost-effective PCB if they want to fine-tune their prices. It looks like AMD is ready well ahead to face competition from NVIDIA, with its GeForce Kepler 104 (GK104) GPU.

The cost-effective PCB, without any components laid, is pictured below. The first picture shows its obverse side, the second, its reverse side. The PCB is completely up to speed with everything Tahiti GPU will need. It has provision for two 8-pin PCIe power inputs, an 8+2 phase cost-effective analog VRM, probably driven by a cost-effective CHIL controller, and a different display output connector loadout. It has provision for two DVI, and one each of HDMI and full-size DisplayPort. Partners can still use a single DVI connector, and keep their cards single-slot capable. Provisions for 12 GDDR5 chips are right where they should be. There is nothing eventful in the reverse side, just traces for all the supportive components.

Radeon HD 6930 2 GB Tested

Unbeknownst to many, AMD launched the Radeon HD 6930 in some markets. The company apparently doesn't want this launch to disturb reviewers from key high-volume markets, who have their hands full with Radeon HD 7970, and so the HD 6930 got a limited launch. For one, the HD 6930 is most certainly launched in China, and so Expreview gave it a run against the HD 6950 1 GB. The Radeon HD 6930 is carved out of the 40 nm "Cayman" silicon, on which other HD 6900 series products are based. It features 1280 VLIW4 stream processors, 1 GB or 2 GB of GDDR5 memory over a 256-bit wide memory interface, 80 TMUs, 32 ROPs, and clock speeds of 750 MHz (core), 1200 MHz or 4.80 GHz effective (memory). Very few partners made English press-releases about this SKU, HIS was among them. The company launched an IceQ-X graphics card on Monday.
Performance summary follows.

Club3D Intros New GeForce GTX 570 Battlefield 3 Edition Graphics Card

Club3D introduced a new custom-design GeForce GTX 570 special-edition graphics card that's Battlefield 3-themed. Carrying the item code CGNX-X5780B, this card is based on a cost-effective GF110 in-house board design by Club3D, that includes a custom-design blue-colored PCB, and Club3D's CoolStream cooler, which uses a large aluminum fin heatsink to which heat is fed by copper heat pipes, and is ventilated by a single large temperature-controlled fan. The card sticks to reference clock speeds of 732 MHz core, 1464 MHz CUDA cores, and 950 MHz (3.80 GHz GDDR5 effective) memory. The GeForce GTX 570 features 480 CUDA cores, and 1280 MB of GDDR5 memory across a 320-bit wide memory interface. This special-edition package most likely includes a copy of the game. Pricing and availability information is not at hand.

New Radeon Pictures Leaked: HD 7770

First pictures of AMD's mainstream card, HD 7770, have now been leaked online. This card is the first major upgrade to the HD 5770 in two years, since the HD 6770 was just a rebrand. It features the Cape Verde GPU, which replaces the Juniper GPU used in the HD 5770/HD 6770. The card looks somewhat different, with a large fan sitting on top of the GPU, blowing directly onto it and the card's length is the same as the HD 5770, at around 8.25 inches.

AMD Radeon HD 7970 Reference Board Design Detailed, Single Slot Capable - Finally!

AMD Radeon HD 7970 launch is just around the corner. Ahead of its launch, AMD conducted its usual press briefing. DonanimHaber has access to some of the slides shown in that meeting. Earlier this day, we brought you perhaps the most important of them all, specifications. Let's take a look at the reference board design itself. AMD is sticking to the black+red colour scheme, and has come up with a swanky new cooling assembly design. The design, unlike those of higher-end Radeon HD 6000 series graphics cards, is surprisingly curvy and features dashes of red plastic making up its contours, surrounded by tougher black ABS.

A welcome change here from the previous generations, is that the card is truly single-slot capable, when say, a single-slot full-coverage water block is used. High-end cards from previous generation HD 5000 and HD 6000 have a dual DVI connector cluster that extends into two expansion slots, which many enthusiasts found to be annoying, especially when setting up benches with four single-GPU graphics cards in scenarios where PCI-Express slot spacing isn't kind. Moving on to display connectivity, the card has one DVI, one HDMI, and two mini-DisplayPort connectors, all arranged in the confines of a single expansion slot. The space of the second slot is dedicated to a hot-air exhaust of the cooling assembly. All board partners are required to ship HDMI-to-DVI dongles, and active mini-DP dongles.

Radeon HD 7970 Raw Specs Leaked

If slide leaked on Orb-Hardware is to be believed we GPU consumers are in for a pretty big treat in the next month or so. The slide shown below states that the AMD 7970 will have a default core clock speed of 925MHz and a whopping 3 GB of GDDR5 memory.

It also sports a 3.5 TFLOPs precision floating point. Which would put it well beyond the NVIDIA flagship single GPU solution. The slide states the a ROP count of 32, against an earlier speculated count of 48. This could be because AMD may have delinked ROP clusters from memory bus. The cooler itself is under the trademark AMD black shroud so there is no way to see if it uses the rumored "vapor chamber" as seen in after market solutions.

Looking past all the beastly prowess of this slide one cannot help but think about power draw. The "leaked" slide states the 7970 will have a peak power draw of 300 W and an idle draw of 3 W. We will have to wait for review to see if any of these amazing stats are true.

GeForce Kepler 104 and 100 GPU Specifications Compiled

A quick stroll through our previous article about how the GeForce Kepler family of next-generation GPUs is laid out, would tell you that GeForce Kepler 104 (GK104), is going to be NVIDIA's answer to AMD's Tahiti. GK104 will be a high-performance (≠ high-end) GPU by NVIDIA that will have many of the features that were reserved for its previous high-end GPUs (such as a 384-bit wide GDDR5 memory interface), but will not be NVIDIA's most powerful GPU in the series. The throne will be kept empty for GK100, which will comply with NVIDIA's "go all in" design ideology for high-end GPUs.

3DCenter.org compiled a few specifications of the GK104 and GK100. They go like this:
GK104
  • 640 to 768 CUDA cores
  • 80 to 96 TMUs (depending on what the CUDA core count ends up being)
  • 384-bit GDDR5 memory interface, 48 ROPs
  • Built on the 28 nm TSMC process
  • Products based on this will launch in the first quarter of 2012

AMD Tahiti GPU Specifications Compiled

If the word on the optical fibers is true, we are less than a month away from the launch of AMD's next high-end graphics card family based on its next high-performance GPU, codenamed "Tahiti". According to 3DCenter, AMD will launch new graphics card models based on this GPU around January 10, 2012. It is expected that we'll learn a lot more about these GPUs, maybe even come across AIB-branded graphics cards, at the upcoming CES event.

3DCenter compiled specifications of "Tahiti", based on bits and pieces of information from various sources. The specs can be listed out as:
  • 4.50 billion transistors, die-area of 380 mm², built on TSMC 28 nm process
  • Advanced GCN 1D architecture
  • 2048 1D processing cores
  • 128 TMUs, 48 ROPs
  • 384-bit wide GDDR5 memory interface, memory clock slightly below 1 GHz, target bandwidth of 240~264 GB/s
