AMD Unveils "Zen 2" CPU Architecture and 7 nm Vega Radeon Instinct MI60 at New Horizon

btarunr

Editor & Senior Moderator
Staff member
Joined
Oct 9, 2007
Messages
37,807 (8.50/day)
Location
Hyderabad, India
Processor AMD Ryzen 7 2700X
Motherboard ASUS ROG Strix B450-E Gaming
Cooling AMD Wraith Prism
Memory 2x 16GB Corsair Vengeance LPX DDR4-3000
Video Card(s) Palit GeForce RTX 2080 SUPER GameRock
Storage Western Digital Black NVMe 512GB
Display(s) Samsung U28D590 28-inch 4K UHD
Case Corsair Carbide 100R
Audio Device(s) Creative Sound Blaster Recon3D PCIe
Power Supply Cooler Master MWE Gold 650W
Mouse Razer Abyssus
Keyboard Microsoft Sidewinder X4
Software Windows 10 Pro
AMD today held its "New Horizon" event for investors, offering guidance and "color" on what the company's near-future could look like. At the event, the company formally launched its Radeon Instinct MI60 GPU-based compute accelerator; and disclosed a few interesting tidbits on its next-generation "Zen 2" mircroarchitecture. The Instinct MI60 is the world's first GPU built on the 7 nanometer silicon fabrication process, and among the first commercially available products built on 7 nm. "Rome" is on track to becoming the first 7 nm processor, and is based on the Zen 2 architecture.

The Radeon Instinct MI60 is based on a 7 nm rendition of the "Vega" architecture. It is not an optical shrink of "Vega 10," and could have more number-crunching machinery, and an HBM2 memory interface that's twice as wide that can hold double the memory. It also features on-die logic that gives it hardware virtualization, which could be a boon for cloud-computing providers.



If you've been paying attention to our "Zen 2" coverage over the past couple of weeks, you would've read our recent article citing a Singapore-based VLSI engineer claiming that AMD could disintegrate the northbridge for its high core-count enterprise CPUs, in an attempt to make the memory I/O "truly" wide, without compromising on the idea of MCM CPU chiplets. All of that is true.

"Rome" is codename for a multi-chip module of four to eight 7 nm CPU dies, wired to a centralized die over InfinityFabric. This 14 nm die, called "I/O die," handles memory and PCIe, providing a monolithic 8-channel memory interface, overcoming the memory bandwidth bottlenecks of current-generation 4-die MCMs. The CPU dies and an I/O die probably share an interposer. Assuming each die has 8 CPU cores, "Rome" could have up to 64 cores, an 8-channel DDR4 memory interface, and a 96-lane PCI-Express gen 4.0 root-complex, per socket. If AMD has increased its core-count per CPU die, Rome's core count could be even higher.



The broader memory I/O, assuming InfinityFabric does its job, could significantly improve performance of multi-threaded workloads that can scale across as many cores as you can throw at them, utilizing a truly broader memory interface. AMD also speaks of "increased IPC," which bodes well for the client-segment. AMD has managed to increase IPC (per-core performance), with several on-die enhancements to the core design.

With "Zen" and "Zen+," AMD recognized several components on the core that could be broadened or made faster, which could bring about tangible IPC improvements. This includes a significantly redesigned front-end. Zen/Zen+ feature a front-end that's not much different than AMD's past micro-architectures. The new front-end includes an improved branch-predictor, a faster instruction prefetcher, an improved/enlarged L1 instruction cache, and an improved prefetcher cache (L2).

The number-crunching machinery, the floating point unit, also receives a massive overhaul. "Zen 2" features 256-bit FPUs, which are doubled in width compared to Zen. load/store/dispatch/retire bandwidths have been doubled over the current generation. These changes are massive. Given that even without these core-level changes, by simply improving cache latencies, AMD managed to eke out a ~3% IPC uplift with "Zen+," one can expect double-digit percentage IPC gains with "Zen 2." Higher IPC, combined with possible increased core counts, higher clock speeds, and power benefits of switching to 7 nm, complete AMD's "Zen 2" proposition.

View at TechPowerUp Main Site


M2B

Joined
Jun 2, 2017
Messages
201 (0.22/day)
Location
Iran
Processor Intel Core i5-8600K @4.9GHz
Motherboard MSI Z370 Gaming Pro Carbon
Cooling Cooler Master MasterLiquid ML240L RGB
Memory XPG 8GBx2 - 3200MHz CL16
Video Card(s) Asus Strix GTX 1080 OC Edition 8G 11Gbps
Storage 2x Samsung 850 EVO 1TB
Display(s) BenQ PD3200U
Case Thermaltake View 71 Tempered Glass RGB Edition
Power Supply EVGA 650 P2
12 Cores at 4.6-4.7GHz with Intel level IPC for 320$? Sounds good.

Joined
Apr 12, 2013
Messages
2,684 (1.10/day)
They haven't said anything about clocks or cores for mainstream, yet. Live stream ~

  • Like
Reactions: HTC

T4C Fantasy

CPU & GPU DB Maintainer
Staff member
Joined
May 7, 2012
Messages
2,348 (0.85/day)
Location
Rhode Island
System Name Whaaaat Kiiiiiiid!
Processor Intel Core i9-9900K @ 5.0GHz
Motherboard Gigabyte Z390 AORUS Ultra
Cooling Corsair H150i AIO Cooler
Memory Corsair Dominator Platinum 16GB DDR4-3200
Video Card(s) Zotac GeForce RTX 2080 Ti Triple Fan @ 2040MHz
Storage Samsung 970 PRO 512GB + Crucial MX300 512GB + OCZ Vertex 4 256GB
Display(s) 27" LG 27MU67-B 4K, + 27" Acer Predator XB271HU 1440P
Case Thermaltake Core X9 Snow
Audio Device(s) Logitech G933 Headset
Power Supply SeaSonic Platinum 1050W Snow Silent
Mouse Logitech G900
Keyboard Logitech G910
Software Windows 10 Pro
Benchmark Scores FFXV: 19329
They haven't said anything about clocks or cores for mainstream, yet. Live stream ~
its around 1800 core clock

  • Like
Reactions: HTC

T4C Fantasy

CPU & GPU DB Maintainer
Staff member
Joined
May 7, 2012
Messages
2,348 (0.85/day)
Location
Rhode Island
System Name Whaaaat Kiiiiiiid!
Processor Intel Core i9-9900K @ 5.0GHz
Motherboard Gigabyte Z390 AORUS Ultra
Cooling Corsair H150i AIO Cooler
Memory Corsair Dominator Platinum 16GB DDR4-3200
Video Card(s) Zotac GeForce RTX 2080 Ti Triple Fan @ 2040MHz
Storage Samsung 970 PRO 512GB + Crucial MX300 512GB + OCZ Vertex 4 256GB
Display(s) 27" LG 27MU67-B 4K, + 27" Acer Predator XB271HU 1440P
Case Thermaltake Core X9 Snow
Audio Device(s) Logitech G933 Headset
Power Supply SeaSonic Platinum 1050W Snow Silent
Mouse Logitech G900
Keyboard Logitech G910
Software Windows 10 Pro
Benchmark Scores FFXV: 19329
Joined
Dec 28, 2012
Messages
1,257 (0.49/day)
Those Zen improvements sound amazing. Crossing fingers for a 10% IPC improvement.

I may finally buy a CPU day 1.

Joined
Dec 16, 2017
Messages
547 (0.75/day)
Location
Argentina
System Name Desktop5
Processor AMD Ryzen 5 3600
Motherboard Asus Prime X570-P
Cooling AMD Wraith Stealth
Memory 2x8GB Ballistix Sport LT 3200 MHz (BLS8G4D32AESCK.M8FE) (CL16-18-18-36)
Video Card(s) Gigabyte AORUS Radeon RX 580 8 GB
Storage Kingston HyperX Fury 240 GB // Toshiba 2 TB HDD // WD 2 TB HDD // Mushkin Triactor 3DL 256 GB
Display(s) LG 22MP55 IPS Display
Case Corsair Carbide 100R
Audio Device(s) Logitech G430 Headset
Power Supply Corsair CX650M
Mouse Logitech Wireless Mouse M280 // Microsoft Trackball Optical 1.0
Keyboard HP Vectra VE keyboard (Part # D4950-63004)
Software Windows 10
Regarding Zen 2: Yes, yes, YEEESSSSS!! *Pumps fist into the air* I'll wait until Zen 2 ships and reviews are available, but now I feel like it was a good idea to hold back on making a Ryzen rig (not that I wanted to hold back, but my country almost went straight to hell just before I pulled the trigger)

Regarding Vega: Meh, I guess, since it's not aimed at consumers. Although it's probably a lot more interesting for those that work in HPC, datacenters, cloud computing and the like.

Joined
Apr 12, 2013
Messages
2,684 (1.10/day)
Lisa Su reemphasizing that the chiplet design decision was taken 4 years back, one heck of a gamble that & everyone from the current CEO, Mark Papermaster & quite likely Jim Keller(?) as well deserve massive accolades for it!

Last edited:

HTC

Joined
Apr 1, 2008
Messages
3,737 (0.87/day)
Location
Portugal
System Name HTC's System
Processor Ryzen 5 2600X
Motherboard Asrock Taichi X370
Cooling NH-C14, with the AM4 mounting kit
Memory G.Skill Kit 16GB DDR4 F4 - 3200 C16D - 16 GTZB
Video Card(s) Sapphire Nitro+ Radeon RX 480 OC 4 GB
Storage 1 Samsung NVMe 960 EVO 250 GB + 1 3.5" Seagate IronWolf Pro 6TB 7200RPM 256MB SATA III
Display(s) LG 27UD58
Case Fractal Design Define R6 USB-C
Audio Device(s) Onboard
Power Supply Corsair TX 850M 80+ Gold
Mouse Razer Deathadder Elite
Software Ubuntu 19.04 LTS
New Epyc chiplet disposition (see the reflection):

Screenshot from 2018-11-06 19-22-31.jpg

Last edited:
Joined
Feb 19, 2009
Messages
1,002 (0.25/day)
Location
I live in Norway, in the province Buskerud.
System Name 3 sys spec seperated by "|"
Processor R9 3900| R7 1700 3.75 | Xeon 2680v2
Motherboard Asrock X570M | AB350M Pro 4 | HP Z620
Cooling Water1x360,1x240 | Air | air
Memory 64gb G.skill SniperX 3466mhz CL16 | 64gb | 128 gb
Video Card(s) EK-FC - RX Vega 64 | server | GTX970
Storage 960 Evo 500gb, 860 evo 1tb, Intel 660P 1tb PM871 256gb | various intel ssd's.
Display(s) AOC 28" 4K something + 1440p 144hz something.
Case Phanteks EvolvX M-Atx
Power Supply Corsair RM850
Mouse G402
Keyboard TT Meka G1
New Epyc chip disposition (see the reflection):

View attachment 110021
Nice catch, we knew it'd be 8 chiplets for 64 cores but that arrangement is new!
They also said 2x core density and a lot of confimations on leaks which wasn't said outright but confirm our leaks..

IPC is an unknown but I expect Intel levels of IPC and I doubt Intel have left any ipc on the table so I think we're close to the max possible IPC as both enter the same realm after decades of optimizations.
But thankfully memory always give IPC and that'll be on Zen3 (DDR5).

Also we do not know what the I/O chip will be in the different classes, Epyc, TR, Desktop\laptop.
Furthermore clocks, but if IPC and 4.5 ghz i think we have a pretty good cpu in the future :) (1.25x performance = frequency = 4.5 allcore possibility ~)


HTC

Joined
Apr 1, 2008
Messages
3,737 (0.87/day)
Location
Portugal
System Name HTC's System
Processor Ryzen 5 2600X
Motherboard Asrock Taichi X370
Cooling NH-C14, with the AM4 mounting kit
Memory G.Skill Kit 16GB DDR4 F4 - 3200 C16D - 16 GTZB
Video Card(s) Sapphire Nitro+ Radeon RX 480 OC 4 GB
Storage 1 Samsung NVMe 960 EVO 250 GB + 1 3.5" Seagate IronWolf Pro 6TB 7200RPM 256MB SATA III
Display(s) LG 27UD58
Case Fractal Design Define R6 USB-C
Audio Device(s) Onboard
Power Supply Corsair TX 850M 80+ Gold
Mouse Razer Deathadder Elite
Software Ubuntu 19.04 LTS
Nice catch, we knew it'd be 8 chiplets for 64 cores but that arrangement is new!
They also said 2x core density and a lot of confimations on leaks which wasn't said outright but confirm our leaks..

IPC is an unknown but I expect Intel levels of IPC and I doubt Intel have left any ipc on the table so I think we're close to the max possible IPC as both enter the same realm after decades of optimizations.
But thankfully memory always give IPC and that'll be on Zen3 (DDR5).

Also we do not know what the I/O chip will be in the different classes, Epyc, TR, Desktop\laptop.
Furthermore clocks, but if IPC and 4.5 ghz i think we have a pretty good cpu in the future :) (1.25x performance = frequency = 4.5 allcore possibility ~)
Better shot:

Screenshot from 2018-11-06 19-22-31.png

The chiplet arrangement seems odd but i'm no expert on the matter.

The good thing is that the NUMA thing seeems to be gone, meaning in TR CPUs and Epyc CPUs will have the whole chip running certain things that required "legacy mode", or whatever it's called, will no longer need it. I'm assuming the bigger AM4 platform Zen 2 version (in cores) will also not require NUMA, which is quite good, i think.

Last edited:

Arpeegee

New Member
Joined
May 21, 2018
Messages
20 (0.03/day)
Been holding back on a new system build for a couple years now due to mining craze and RAM price fixing but it looks like next year will finally be the year to make the jump!

No more excuses for not building a Ryzen system next year, lower price with close to/same/or possibly above IPC of Intel chips means there's hardly anything to sacrifice for red team. Of course, always wait for reviews kids ;-) !


HTC

Joined
Apr 1, 2008
Messages
3,737 (0.87/day)
Location
Portugal
System Name HTC's System
Processor Ryzen 5 2600X
Motherboard Asrock Taichi X370
Cooling NH-C14, with the AM4 mounting kit
Memory G.Skill Kit 16GB DDR4 F4 - 3200 C16D - 16 GTZB
Video Card(s) Sapphire Nitro+ Radeon RX 480 OC 4 GB
Storage 1 Samsung NVMe 960 EVO 250 GB + 1 3.5" Seagate IronWolf Pro 6TB 7200RPM 256MB SATA III
Display(s) LG 27UD58
Case Fractal Design Define R6 USB-C
Audio Device(s) Onboard
Power Supply Corsair TX 850M 80+ Gold
Mouse Razer Deathadder Elite
Software Ubuntu 19.04 LTS

So a single PCB & 9 chiplets spread out, I wonder how they're connected without the interposer :confused:
Hadn't noticed the lack of interposer. Wondering the same, really.

Intel is a victim of their own increased frequencies: with the higher and higher base / boost frequencies for the current manufacturing processes, they either come up with a significant boost in IPC and reduce the clocks or improve the clocks and keep (or slightly improve) the IPC and they assumed they could do the former with 10nm but that backfired spectacularly and they are being forced to use an even more refined version of the same process and that means pretty much the same IPC, meaning they need higher clocks on these than the previous gen, which in turn aggravates the issue with frequencies / IPC for the next gen.

AMD must be careful not to fall for the same "frequency trap" or they risk getting caught in it. I'd prefer CPUs with lower frequencies but higher IPC than CPU with high frequencies but lower IPC, so long as the performance ends up being roughly the same, ofc.

Joined
Mar 10, 2010
Messages
6,849 (1.92/day)
Location
Manchester uk
System Name RyzenGtEvo
Processor Amd R7 3800X@4.350/525
Motherboard Crosshair hero7 @bios 2703
Cooling 360EK extreme rad+ 360$EK slim all push, cpu Monoblock Gpu full cover all EK
Memory Corsair Vengeance Rgb pro 3600cas14 16Gb in two sticks.
Video Card(s) Sapphire refference Rx vega 64 EK waterblocked
Storage Samsung Nvme Pg981, silicon power 1Tb samsung 840 basic as a primocache drive for, WD2Tbgrn +3Tbgrn,
Display(s) Samsung UAE28"850R 4k freesync, LG 49" 4K 60hz ,Oculus
Case Lianli p0-11 dynamic
Audio Device(s) Xfi creative 7.1 on board ,Yamaha dts av setup, corsair void pro headset
Power Supply corsair 1200Hxi
Mouse Roccat Kova
Keyboard Roccat Iksu force fx
Software Win 10 Pro
Benchmark Scores 8726 vega 3dmark timespy

So a single PCB & 9 chiplets spread out, I wonder how they're connected without the interposer :confused:
Well the same, a silicon interposer is not that different from a pcb, it's going to have quite a few layers though.
I said it for years interposers appeared with sockets as an abstraction layer to connect the beol to a socket and as such has Always been a multi leyer(phones tut it got it right seconds before) circuited PCB not just a interlink.
Am4 could be one of the best sockets ever made and shows intel why people like me aren't spending cash with them.

Joined
Jan 13, 2018
Messages
154 (0.22/day)
System Name N/A
Processor Intel Core i5 3570
Motherboard Gigabyte B75
Cooling Coolermaster Hyper TX3
Memory 12 GB DDR3 1600
Video Card(s) MSI Gaming Z RTX 2060
Storage SSD
Display(s) Samsung 4K HDR 60 Hz TV
Case Eagle Warrior Gaming
Audio Device(s) N/A
Power Supply Coolermaster Elite 460W
Mouse Vorago KM500
Keyboard Vorago KM500
Software Windows 10
Benchmark Scores N/A

So a single PCB & 9 chiplets spread out, I wonder how they're connected without the interposer :confused:
Perhaps is not functional, who knows?
So the chiplets were true, now let's wait the reviews.
Will these Rome be compatibles with the same motherboards as current EPYC?

Last edited:
Joined
Mar 23, 2016
Messages
3,123 (2.29/day)
Processor Ryzen 5 3600
Motherboard MSI B450 Tomahawk ATX
Cooling Scythe Kotetsu with AM4 bracket
Memory PNY Anarchy-X XLR8 Red DDR4 3200 MHz C15-17-17-17-35
Video Card(s) MSI GeForce RTX 2060 GAMING Z 6G
Storage Samsung 970 EVO NVMe M.2 500 GB, SanDisk Ultra II 480 GB
Display(s) Samsung SyncMaster C27H711 OC refresh rate 110Hz
Case Phantek Eclipse P400S (PH-EC416PS)
Audio Device(s) EVGA NU Audio
Power Supply EVGA 850 BQ
Mouse SteelSeries Rival 310
Keyboard Logitech G G413 Silver
Software Windows 10 Professional 64-bit v1903
Joined
Apr 12, 2013
Messages
2,684 (1.10/day)
Well the same, a silicon interposer is not that different from a pcb, it's going to have quite a few layers though.
I said it for years interposers appeared with sockets as an abstraction layer to connect the beol to a socket and as such has Always been a multi leyer circuited PCB not just a interlink.
Am4 could be one of the best sockets ever made and shows intel why people like me aren't spending cash with them.
Yes but some of the previous assumptions dealt with a possibility of active(?) interposer IIRC, in this case the distance between the (core) chiplets & the I/O chiplet might produce more interesting results. I have a feeling that the 2 chiplets near each other might act as the current desktop ryzen, with 8 cores per CCX & chiplet, or something like that.
Perhaps is not functional, who knows?
So the chiplets where true, now let's wait the reviews.
Will these Rome be compatibles with the same motherboards as current EPYC?
Possibly, they're still fine tuning the chips that's for sure. The clocks weren't final & so we didn't see too many hard numbers, except a couple of demos. Yes, socket compatible.
Infinity Fabric (2nd Gen IF) ;)
Yeah but would be nice to see some more details.

Last edited:
Joined
Nov 4, 2005
Messages
10,451 (2.03/day)
System Name MoFo 2
Processor AMD PhenomII 1100T @ 4.2Ghz
Motherboard Asus Crosshair IV
Cooling Swiftec 655 pump, Apogee GT,, MCR360mm Rad, 1/2 loop.
Memory 8GB DDR3-2133 @ 1900 8.9.9.24 1T
Video Card(s) HD7970 1250/1750
Storage Agility 3 SSD 6TB RAID 0 on RAID Card
Display(s) 46" 1080P Toshiba LCD
Case Rosewill R6A34-BK modded (thanks to MKmods)
Audio Device(s) ATI HDMI
Power Supply 750W PC Power & Cooling modded (thanks to MKmods)
Software A lot.
Benchmark Scores Its fast. Enough.
Numbers, I want numbers, they mean something. Their cache latency has been their biggest issue, that and memory controller issues.


bug

Joined
May 22, 2015
Messages
6,805 (4.08/day)
Processor Intel i5-6600k (AMD Ryzen5 3600 in a box, waiting for a mobo)
Motherboard ASRock Z170 Extreme7+
Cooling Arctic Cooling Freezer i11
Memory 2x16GB DDR4 3600 G.Skill Ripjaws V (@3200)
Video Card(s) EVGA GTX 1060 SC
Storage 500GB Samsung 970 EVO, 500GB Samsung 850 EVO, 1TB Crucial MX300 and 3TB Seagate
Display(s) HP ZR24w
Case Raijintek Thetis
Audio Device(s) Audioquest Dragonfly Red :D
Power Supply Seasonic 620W M12
Mouse Logitech G502 Proteus Core
Keyboard G.Skill KM780R
Software Arch Linux + Win10
Idk, I'm rather disappointed. This wasn't aimed at the consumers at all :(

Joined
Dec 16, 2017
Messages
547 (0.75/day)
Location
Argentina
System Name Desktop5
Processor AMD Ryzen 5 3600
Motherboard Asus Prime X570-P
Cooling AMD Wraith Stealth
Memory 2x8GB Ballistix Sport LT 3200 MHz (BLS8G4D32AESCK.M8FE) (CL16-18-18-36)
Video Card(s) Gigabyte AORUS Radeon RX 580 8 GB
Storage Kingston HyperX Fury 240 GB // Toshiba 2 TB HDD // WD 2 TB HDD // Mushkin Triactor 3DL 256 GB
Display(s) LG 22MP55 IPS Display
Case Corsair Carbide 100R
Audio Device(s) Logitech G430 Headset
Power Supply Corsair CX650M
Mouse Logitech Wireless Mouse M280 // Microsoft Trackball Optical 1.0
Keyboard HP Vectra VE keyboard (Part # D4950-63004)
Software Windows 10
Idk, I'm rather disappointed. This wasn't aimed at the consumers at all :(
It was already announced that EPYC would come first. Mostly, this is important because all or most of the architecture changes and enhancements will carry over Ryzen's next launch, which I think could happen somewhere around Q1 or Q2 2019 (maybe)

EDIT: Yeah, maybe that's too hopeful...

Last edited:

bug

Joined
May 22, 2015
Messages
6,805 (4.08/day)
Processor Intel i5-6600k (AMD Ryzen5 3600 in a box, waiting for a mobo)
Motherboard ASRock Z170 Extreme7+
Cooling Arctic Cooling Freezer i11
Memory 2x16GB DDR4 3600 G.Skill Ripjaws V (@3200)
Video Card(s) EVGA GTX 1060 SC
Storage 500GB Samsung 970 EVO, 500GB Samsung 850 EVO, 1TB Crucial MX300 and 3TB Seagate
Display(s) HP ZR24w
Case Raijintek Thetis
Audio Device(s) Audioquest Dragonfly Red :D
Power Supply Seasonic 620W M12
Mouse Logitech G502 Proteus Core
Keyboard G.Skill KM780R
Software Arch Linux + Win10
It was already announced that EPYC would come first. Mostly, this is important because all or most of the architecture changes and enhancements will carry over Ryzen's next launch, which I think could happen somewhere around Q1 or Q2 2019 (maybe)
Except nothing that will carry over to Ryzen has been announced. Because I highly doubt we'll get 8 channel RAM on consumer parts. It's AMD's show, I'm not faulting them. I was just saying, I had other expectations.

Edit: I also don't see anything about Zen2 availability in the server space, so good luck with that "Q1 or Q2 2019" prediction.

Joined
Mar 16, 2017
Messages
710 (0.71/day)
Location
Tanagra
Processor AMD 2700X
Motherboard Gigabyte B450M DS3H
Cooling Wraith Prism
Memory 16GB DDR4 3000
Video Card(s) Sapphire Pulse RX 570 4GB
Storage Inland 512GB NVMe
Display(s) LG 27UL500-W
Case NZXT H510
Audio Device(s) My ears
Power Supply EVGA 500W
Software Windows 10
Certainly an exciting set of announcements on the CPU side. Hard to tell what the GPU side will look like though. I do applaud AMDs approach if they have truly pulled it off. As transistor count skyrockets, it makes sense to going back to separate dies to improve production. It allows AMD to properly harvest and leverage certain uniform blocks (CPU modules), while customizing the IO and MC based on the application. An 8C desktop machine won’t need 8 memory channels, and the consumer won’t have to pay for some sort of cut-down “one size fits all” solution. I wonder if we’ll see a similar approach to APUs? Zen2 + GPU fed off HMB2? Can’t wait to see what they put out into the market.

Top
