why is my lenovo ideapad s340 15iml 81na i7 10th gen throttling to 2 ghz when throwing a multicore workload?

Joined
Jun 22, 2021
Messages
59 (0.37/day)
System Name Lenovo Ideapad S340 15iml 81NA
Processor i7 10510U
Motherboard -
Cooling single fan cooling system
Memory 20 GB DDR4 2666
Video Card(s) Nvidia Geforce MX230
Storage 1TB samsung MZLVB1T0HBLR-000L2
Display(s) 1080p display 60HZ
Case -
Audio Device(s) dual 2 watt speakers with dolby atmos
Power Supply 65 watt
Mouse Hp omen gaming mouse
Keyboard -
VR HMD -
Software Windows 11
Benchmark Scores Geekbench 5: single core: 1189 multicore : 4001 compute(OpenCL):10976
specs: i7 10510U
20GB RAM
Nvidia MX230 GPU
Benchmark: Cinebench r23 and geekbench 5

specs: i7 10510U
20GB RAM
Nvidia MX230 GPU
Benchmark: Cinebench r23 and geekbench 5


Attachments

  • Screenshot (97).png
    Screenshot (97).png
    159 KB · Views: 20
  • Screenshot (100).png
    Screenshot (100).png
    91.4 KB · Views: 19
  • Screenshot (102).png
    Screenshot (102).png
    276.2 KB · Views: 19
Joined
Jan 5, 2006
Messages
12,293 (2.12/day)
System Name Desktop / Laptop
Processor Intel i7 6700K @ 4.5GHz (1.270 V) / Intel i3 7100U
Motherboard Asus Z170 Pro Gaming / HP 83A3 (U3E1)
Cooling Noctua NH-U12A 2 fans + Thermal Grizzly Kryonaut + 5 case fans / Fan
Memory 16GB DDR4 Corsair Vengeance LPX 3000MHz CL15 / 8GB DDR4 HyperX CL13
Video Card(s) MSI RTX 2070 Super Gaming X Trio / Intel HD620
Storage Samsung 970 Evo 500GB + Samsung 850 Pro 512GB + Samsung 860 Evo 1TB x2 / Samsung 256GB M.2 SSD
Display(s) 23.8" Dell S2417DG 165Hz G-Sync 1440p / 14" 1080p IPS Glossy
Case Be quiet! Silent Base 600 - Window / HP Pavilion
Audio Device(s) SupremeFX Onboard / Realtek onboard + B&O speaker system
Power Supply Seasonic Focus Plus Gold 750W / Powerbrick
Mouse Logitech MX Anywhere 2 Laser wireless / Logitech M330 wireless
Keyboard RAPOO E9270P Black 5GHz wireless / HP backlit
Software Windows 10 / Windows 10
Is that better? Quoting yourself? :D

How hot does the CPU/GPU get?

Last edited:
Joined
Aug 25, 2021
Messages
787 (8.20/day)
Location
Thailand
System Name Shoebox
Processor 3600x
Motherboard Msi b550m Mortar +WiFi
Cooling Cryorig m9
Memory Hyperx c16 3200 2x8gb
Video Card(s) Powercolor rx570 4gb
Storage WD black sn750 256gb (OS), crucial mx500 1tb(storage),Hitatchi ?? 7200rpm 500gb(Temp files)
Display(s) Samsung 65" TU7100
Case Zzaw b3
Audio Device(s) Yamaha rx-v363
Power Supply Corsair sf750
Mouse Logitech g300s
Keyboard Custom Skyloong sk64s
Software Windows 10 Pro
Heat or power limitations?

Joined
Jun 22, 2021
Messages
59 (0.37/day)
System Name Lenovo Ideapad S340 15iml 81NA
Processor i7 10510U
Motherboard -
Cooling single fan cooling system
Memory 20 GB DDR4 2666
Video Card(s) Nvidia Geforce MX230
Storage 1TB samsung MZLVB1T0HBLR-000L2
Display(s) 1080p display 60HZ
Case -
Audio Device(s) dual 2 watt speakers with dolby atmos
Power Supply 65 watt
Mouse Hp omen gaming mouse
Keyboard -
VR HMD -
Software Windows 11
Benchmark Scores Geekbench 5: single core: 1189 multicore : 4001 compute(OpenCL):10976
Joined
Nov 25, 2019
Messages
408 (0.56/day)
Location
Taiwan
Processor i5-9600K
Motherboard Gigabyte Z390 Gaming X
Cooling Scythe Mugen 5 S
Memory Micron Ballistix Sports LT 3000 8G*4
Video Card(s) MSI 2070 Ventus
Storage Adata SX6000 Pro 512G, Kingston A2000 1T
Display(s) Gigabyte M32Q
Case Phanteks Eclipse P350X
Audio Device(s) Edifier C3X
Power Supply Super Flower Leadex Gold 650W
Mouse Razer Basilisk V2
Keyboard Ducky ONE 2 Horizon
Isn't this maximum temperature of 94 degrees the problem?

Joined
Jun 22, 2021
Messages
59 (0.37/day)
System Name Lenovo Ideapad S340 15iml 81NA
Processor i7 10510U
Motherboard -
Cooling single fan cooling system
Memory 20 GB DDR4 2666
Video Card(s) Nvidia Geforce MX230
Storage 1TB samsung MZLVB1T0HBLR-000L2
Display(s) 1080p display 60HZ
Case -
Audio Device(s) dual 2 watt speakers with dolby atmos
Power Supply 65 watt
Mouse Hp omen gaming mouse
Keyboard -
VR HMD -
Software Windows 11
Benchmark Scores Geekbench 5: single core: 1189 multicore : 4001 compute(OpenCL):10976

newtekie1

Semi-Retired Folder
Joined
Nov 22, 2005
Messages
28,314 (4.84/day)
Location
Indiana, USA
Processor Intel Core i7 10850K@5.2GHz
Motherboard AsRock Z470 Taichi
Cooling Corsair H115i Pro w/ Noctua NF-A14 Fans
Memory 32GB DDR4-3600
Video Card(s) RTX 2070 Super
Storage 500GB SX8200 Pro + 8TB with 1TB SSD Cache
Display(s) Acer Nitro VG280K 4K 28"
Case Fractal Design Define S
Audio Device(s) Onboard is good enough for me
Power Supply eVGA SuperNOVA 1000w G3
Software Windows 10 Pro x64
when im running the worlkoad its oly drawing 15 watts.....
And that's your answer. It's power limiting to 15w after a very short burst duration. It can't boost higher than 2.0GHz and stay under 15w.


eidairaman1

The Exiled Airman
Joined
Jul 2, 2007
Messages
33,200 (6.31/day)
Location
Republic of Texas (True Patriot)
System Name PCGOD
Processor AMD FX 8350@ 5.0GHz
Motherboard Asus TUF 990FX Sabertooth R2 2901 Bios
Cooling Scythe Ashura, 2×BitFenix 230mm Spectre Pro LED (Blue,Green), 2x BitFenix 140mm Spectre Pro LED
Memory 16 GB Gskill Ripjaws X 2133 (2400 OC, 10-10-12-20-20, 1T, 1.65V)
Video Card(s) AMD Radeon 290 Sapphire Vapor-X
Storage Samsung 840 Pro 256GB, WD Velociraptor 1TB
Display(s) NEC Multisync LCD 1700V (Display Port Adapter)
Case AeroCool Xpredator Evil Blue Edition
Audio Device(s) Creative Labs Sound Blaster ZxR
Power Supply Seasonic 1250 XM2 Series (XP3)
Mouse Roccat Kone XTD
Keyboard Roccat Ryos MK Pro
Software Windows 7 Pro 64
And that's your answer. It's power limiting to 15w after a very short burst duration. It can't boost higher than 2.0GHz and stay under 15w.
Yup all notebooks throttle back to conserve power...

Joined
Sep 2, 2020
Messages
1,279 (2.82/day)
System Name Whonock
Processor Amd 3200g
Motherboard A320m-h
Cooling Wraith Stealth
Memory 2x 8g ddr4 2666mz
Video Card(s) Msi Gaming x 1060 6g
Storage 5.5 tb hd 220 g ssd
Display(s) Normal moniter
Case Deepcool smater
Intel turbo boosty stuff means that it can draw 40 watts temporarily for short periods of time
but for longer drawn out performance it has to run at 15w
that happens when i boot the machine....it boost to 40 watts
when im running the worlkoad its oly drawing 15 watts....
