GeForce GTX 480 PCB and Cooling Assembly Pictured

btarunr

Editor & Senior Moderator
Staff member
Joined
Oct 9, 2007
Messages
41,085 (8.27/day)
Location
Hyderabad, India
Processor AMD Ryzen 7 2700X
Motherboard ASUS ROG Strix B450-E Gaming
Cooling AMD Wraith Prism
Memory 2x 16GB Corsair Vengeance LPX DDR4-3000
Video Card(s) Palit GeForce RTX 2080 SUPER GameRock
Storage Western Digital Black NVMe 512GB
Display(s) BenQ 1440p 60 Hz 27-inch
Case Corsair Carbide 100R
Audio Device(s) Creative Sound Blaster Recon3D PCIe
Power Supply Cooler Master MWE Gold 650W
Mouse ASUS ROG Strix Impact
Keyboard Microsoft Sidewinder X4
Software Windows 10 Pro
Sources wanting anonymity sent these pictures of PCB and cooling assembly to sections of the media. The PCB is that of the GeForce GTX 480, and is NVIDIA's reference design. It gives away a fair amount of information about the card that has created quite some hype over the months, which is slated for release on March 26. To begin with, the GF100 GPU on which GTX 480 is based, uses essentially the same type of package as the GT200 and G80. To help cool the large die (with a 3 billion-strong transistor count), an integrated heatspreader (IHS) is used. However, unlike with the G80 and GT200 (past two generations of extreme performance GPUs from NVIDIA), the display logic is integrated into the GPU package, instead of being spun off into NVIO processors.

With 12 memory chips on board, the GPU connects to them over a 384-bit wide memory interface. The reference design board is expected to have 1536 MB (1.5 GB) of memory on it. There's also an unusual amount of simplicity to the board design and choice of components. The GPU is powered by a 6-phase vGPU circuit using more standard DPAK MOSFETs. There is a 2-phase vMem circuit. With wide open spaces in the PCB, NVIDIA actually made two cutouts to help the blower's air intake.



Power is drawn from an 8-pin and a 6-pin power connector. Fan connects over a standard 4-pin PWM controlled line, while the white 2-pin connector in the picture powers an illuminated GeForce logo on the top of the card (next to the power inputs). Connectivity includes two DVI-D, and a mini HDMI connector. The PCB itself seems to be about as long as reference GeForce GTX 280 boards. The cooling assembly doesn't show off lavish use of copper, but looks equally complex as older cooling assemblies by the company for such GPUs.



View at TechPowerUp Main Site
