Friday, February 27th 2015

Fractal Design Announces Venturi Series Fans

The Venturi Series of fans delivers high quality design and construction bringing forth a leading performance fan series with built-in rubber vibration dampening corners coupled with top quality electronics and materials. Venturi fans are ideal for high pressure or high airflow usage scenarios featuring detailed engineered elements that contribute to a low-noise yet a maximum performing solid fan.

The Venturi High Flow Series fans, HF-12 and HF-14, are optimized for low-restriction airflow environments, making them an excellent choice for computer case fans, or other low-restriction usage scenarios. Designed with a variety of performance-increasing and noise-reducing features, these fans can move an amazing amount of air compared to other fans at the same, minimal noise level.
The HF-14 comes with two sets of solid vibration-dampening rubber corners: one for standard 140mm fan hole spacing (125mm) and one compatible with the standard 120mm hole spacing (105 mm). The Venturi High Flow Series fans are ideal for those looking for a perfect balance between high performance and low noise built from sturdy, high quality materials.

Venturi High Flow Key Features
  • Featuring true FDB-bearings, providing silent operation coupled with a long lifespan
  • Equipped with a counter-balancing magnet in the hub that reduces the axial tension on the bearing, further protecting the longevity of the bearing
  • Dense, sturdy construction, made from high-grade glass fiber reinforced thermoplastic polymer with fan geometry that is optimized for a good balance between static pressure and maximum airflow, resulting in good performance in all usage scenarios
  • Aerodynamically shaped thin stator struts (including wire strut), mimicking the design commonly found on airplane wings, delivering correct angles allowing for air to easily pass through reducing noise and unwanted turbulence.
  • Stator struts are angled perpendicular to the blades, helping to reduce noise commonly emitted when the blades pass the struts. In effect, minimal noise that may be emitted will be constant and therefore almost inaudible to the ear.
  • Strategically placed notches near the fan hub on the trailing edge of the blades, further reducing and diffusing humming noise produced when the blades pass the stator struts
  • Includes a "trip wire" on the rear side of the blades, near the leading edge. The trip wire technology, also commonly found in airplane wing designs, introduces a micro-turbulent layer that helps to combat the elements that negatively affect performance. The presence of the trip wire overall provides a more efficient and quiet fan environment.
  • Delivers high precision due to high grade materials used, permitting the distance between the blades and frame to be as small as 1.2mm, contributing to a higher performance fan
  • Featuring a powerful motor to maintain a reliable speed
  • Comes with a low-speed adapter, for reducing the speed without the use of a fan controller
  • Includes vibration-dampening corners, from solid high-quality synthetic rubber on the fans
  • 140mm fans come with an additional set of vibration-dampening corners are included that lends compatibility with 120mm fan mounts (105mm screw spacing). This enables the use of 140mm fans on many CPU coolers.
  • Screws pass through the rubber only, not through plastic, therefore eliminating the chance of noise derived from rattling when in use
  • Available in 120mm and 140mm fan sizes
For more information, visit this page.

Venturi High Pressure PWM Fans
The Venturi High Pressure Series PWM fans, HP-12 and HP-14, are optimized for high-restriction airflow scenarios, making them an excellent choice for usage on large heatsinks, on radiators, or in other highly restrictive scenarios.

Designed with a variety of performance-increasing and noise-reducing features, these fans can move an amazing amount of air through restricted environments compared to other fans at the same, minimal noise level.

The HP-14 comes with two sets of solid vibration-dampening rubber corners: one for standard 140mm fan hole spacing (125mm) and one compatible with the standard 120mm hole spacing (105mm). The Venturi High Pressure Series PWM fans are ideal for those looking for a perfect balance between high performance and low noise built from sturdy, high quality materials.

Venturi High Pressure PWM Key Features
  • Featuring true FDB-bearings, providing silent operation coupled with a long lifespan
  • Equipped with a counter-pull magnet, that reduces the axial tension on the bearing
  • Optimized fan geometry as a high pressure fan, delivering high performance results in high restriction usage scenarios, such as in use with large heatsinks or water cooling radiators.
  • Dense, sturdy construction, made from high-grade glass fiber reinforced thermoplastic polymer
  • Featuring PWM control with a very wide speed range, starting at only 400RPM (400 +/- 100 RPM), ideal for CPU heatsinks or radiators, where the motherboard can control the fan speed based on the CPU temperature.
  • Aerodynamically shaped thin stator struts (including wire strut), mimicking the design commonly found on airplane wings, delivering correct angles allowing for air to easily pass through reducing noise and unwanted turbulence.
  • Stator struts are angled perpendicular to the blades, helping to reduce noise commonly emitted when the blades pass the struts. In effect, minimal noise that may be emitted will be constant and therefore almost inaudible to the ear.
  • Strategically placed notches near the fan hub on the trailing edge of the blades, further reducing and diffusing humming noise produced when the blades pass the stator struts
  • Includes a "trip wire" on the rear side of the blades, near the leading edge. The trip wire technology, also commonly found in airplane wing designs, introduces a micro-turbulent layer that helps to combat the elements that negatively affect performance. The presence of the trip wire overall provides a more efficient and quiet fan environment.
  • Delivers high precision due to high grade materials used, permitting the distance between the blades and frame to be as small as 1.2mm, contributing to a higher performance fan
  • Featuring a powerful motor to maintain a reliable speed
  • Comes with a 1->2 PWM signal splitter wire, for connecting additional fans to a single PWM header on your motherboard or PWM fan controller
  • Including vibration-dampening corners, from solid high-quality synthetic rubber on the fans
  • 140mm fans come with an additional set of vibration-dampening corners are included that lends compatibility with 120mm fan mounts (105mm screw spacing). This enables the use of 140mm fans on many CPU coolers.
  • Screws pass through the rubber only, not through plastic, therefore eliminating the chance of noise derived from rattling when in use
  • Available in 120mm and 140mm fan sizes
Add your own comment

10 Comments on Fractal Design Announces Venturi Series Fans

#1
RejZoR
They look quite decent. I wonder why no one makes double the thickness fans with really big blades. So they could rotate at very low speeds and still produce tons of airflow. I know I could find use for them...
Posted on Reply
#2
Chaitanya
RejZoR, post: 3246309, member: 1515"
They look quite decent. I wonder why no one makes double the thickness fans with really big blades. So they could rotate at very low speeds and still produce tons of airflow. I know I could find use for them...
there some manufacturers who do offer double thickness fans. check performance-pcs or frozencpu . I think those fans are often used for industrial applications though some pc users do like to use them for pc cooling.
Posted on Reply
#3
Caring1
That would be the Frozen CPU that recently closed!
Posted on Reply
#4
ZeDestructor
RejZoR, post: 3246309, member: 1515"
They look quite decent. I wonder why no one makes double the thickness fans with really big blades. So they could rotate at very low speeds and still produce tons of airflow. I know I could find use for them...
Look for 38mm thick fans, and make sure you get PWM-enabled ones. True high-end manufacturers like Delta, San Ace and the like make em, and you can find 700-3500rpm fans easily enough if you know where to look.

Or go all out and get something like a San Ace 9LG1212P1G001 - 6550rpm, 7m³/min (420m³/hr, 247.1CFM), 37.6mmH2O, aluminium framed. The downside? $60 each, 40W power consumption, and 62dBA noise at peak. Luckily, it can be toned down to 2000rpm (2.9W, 36dBA), or even completely turned off (0% PWM duty cycle = full off). They'll also happily run down to 8V instead of the 12V they're rated at, or up to 13.8V if you feel you need em spinning faster...

There's even more powerful versions out there, like the 9SX series (7.3m³/min, 49.0mmH2O), but they have lower lifetime ratings.
Posted on Reply
#5
Jorge
ZeDestructor, post: 3246387, member: 151464"
Look for 38mm thick fans, and make sure you get PWM-enabled ones. True high-end manufacturers like Delta, San Ace and the like make em, and you can find 700-3500rpm fans easily enough if you know where to look.

Or go all out and get something like a San Ace 9LG1212P1G001 - 6550rpm, 7m³/min (420m³/hr, 247.1CFM), 37.6mmH2O, aluminium framed. The downside? $60 each, 40W power consumption, and 62dBA noise at peak. Luckily, it can be toned down to 2000rpm (2.9W, 36dBA), or even completely turned off (0% PWM duty cycle = full off). They'll also happily run down to 8V instead of the 12V they're rated at, or up to 13.8V if you feel you need em spinning faster...

There's even more powerful versions out there, like the 9SX series (7.3m³/min, 49.0mmH2O), but they have lower lifetime ratings.
The ideal situation is buying a fan that delivers the airflow/pressure necessary without excessive fan speed or noise. The two fan designs that are being offered above address the two common situations where you need either high flow or high pressure - without excessive noise. There are certainly fans available that offer both high flow and relatively high pressure but they are not usually required for PC apps. While some folks are happy with a tornado for a fan most PC users prefer quiet cooling when possible.

Applications that unfortunately require high fan pressure are many radiators used for liquid cooling. Having to purchase another fan than the one included with a CLC/AIO just increases the cost unnecessarily, but it's often required to have reasonable noise levels. That's one more reason not to buy a CLC/AIO when a quality tower HSF will provide all the cooling required.

BTW, be advised that fan pressure/airflow rating procedures are not standardized so the data can not often be used to compare fans. In addition without knowing what pressure restriction exists in your application, even having a pressure/airflow curve for a fan offers little information as to what will be ideal for your application.
Posted on Reply
#6
Ferrum Master
For me there is a problem finding proper pull fans, they tend to be loud and interfere with air sucking whirlpool in the fins, most of them are not designed for such task...
Posted on Reply
#7
micropage7
i prefer wide blades, it looks pretty promising
Posted on Reply
#8
AsRock
TPU addict
RejZoR, post: 3246309, member: 1515"
They look quite decent. I wonder why no one makes double the thickness fans with really big blades. So they could rotate at very low speeds and still produce tons of airflow. I know I could find use for them...
Try a Pana 38mm fan high powered and thicker, how ever main issue is that you need a fan controller with high powered one and a good one to deal with the amps.

Or even http://www.newegg.com/Product/Product.aspx?Item=N82E16835226013&ignorebbr=1&cm_re=fan-_-35-226-013-_-Product

I like the pana fans but if you have a accident with one you will surely know about it when at high speed, mine ripped 3 blades off before it stopped turning and was just happy it was not my finger.

although by looking again the pana fan i had had smaller fins but a much stronger motor. Had it in the rear of the case for those hot summer days.
http://www.techpowerup.org/uploaded.php?file=150301/IGP5789.jpg
Posted on Reply
#9
natr0n
I like the bearing shown like that with partial sticker. Guess these cant be re-greased.
Posted on Reply
#10
AsRock
TPU addict
natr0n, post: 3247190, member: 102496"
I like the bearing shown like that with partial sticker. Guess these cant be re-greased.
Looks to me like there is just a clip on it which would mean it would be possible. Just gotta make sure it don't fly across the room :P.
Posted on Reply
