AMD Confirms Zen 4 Dragon Range, Phoenix APUs for 2023

AMD has confirmed its revamped APU strategy will be delivered throughout three different APU line-ups come 2023. While Raphael will take care of AMD's hopes in the desktop space, the company is readying a new, "Dragon Range" lineup of "pinnacle gaming"-oriented APUs, leveraging the company's upcoming Zen 4 architecture, DDR5, and PCIe 5. Dragon Range APUs will feature the "highest core, thread, and cache ever for a mobile gaming CPU" - although AMD stopped just short of confirming exactly what "highest" translates to. To aid in its extreme gaming aspirations, TDP for Dragon Range is set at 55 W - they thus "largely exist in the space where gaming laptops are plugged in the majority of the time," according to AMD director of technical marketing Robert Hallock.

Another APU family, Phoenix, will be aimed at thin and lights with a penchant for gaming. Phoenix too will leverage AMD's Zen 4 core, DDR5 memory subsystem, and PCIe 5 interfaces. Being aimed at thin and lights, Phoenix APUs are set for a 35 W - 45 W operating range. Interestingly, AMD didn't share any other details - more crucially, the graphics architecture that's to be employed in these high-performance APUs.

AMD Ryzen 7000 "Raphael" to Ship with DDR5-5200 Native Support

AMD's upcoming Socket AM5 Ryzen 7000-series "Raphael" desktop processors will ship with native support for DDR5-5200 memory speed, according to a marketing slide by memory maker Apacer (which also owns the overclocking memory brand ZADAK). The "Zen 4" based desktop processors will feature a dual-channel DDR5 (4 sub-channel) interface, just like the 12th Gen Core "Alder Lake," but with no backwards compatibility with DDR4.

AMD already stated that Ryzen 7000 processors have a design focus on memory overclocking capabilities, including AMD EXPO, a custom memory module SPD extension standard rivaling Intel XMP 3.0, which will come with fine-grained settings specific to the AMD memory controller architecture. Until now, AMD relied on A-XMP, a motherboard vendor-enabled feature based in the UEFI firmware setup program, which translates Intel XMP SPD profiles of memory modules into AMD-approximate settings.

AMD Ryzen 7000 Series Processor Spotted Running on MSI MAG B650 Motherboard at 1.5 Volts

AMD is slowly gearing up to launch the latest 7000 series Ryzen processors codenamed "Raphael." Thanks to the famous hardware leaker @9550pro on Twitter, we have evidence of B650 motherboards for the next-generation hardware. According to the image posted by the leaker, it appears like AMD's Ryzen 7000 series Raphael processor is running on MSI's MAG B650 motherboard at a very high voltage of 1.5 Volts VCore. While we don't know the exact SKU running here, we see a note referring to it as an Engineering Sample, meaning that this is not a final product. It is expected to see the new AM5 platform make a debut alongside DDR5 and PCIe 5.0 technology, so we have to wonder what the B650 chipset can support.

CPU-Z Adds Support for AMD Rembrandt/Raphael APUs and Preliminary Intel Arc and Raptor Lake Support

CPU-Z is one of the most widespread tools for profiling and monitoring, gathering information from the system, and presenting it in a user-readable UI. Today, the application has reached another milestone with the release of the CPU-Z 2.01 version, which brings support for additional upcoming processors from AMD and Intel. One of the software highlights is the inclusion of AMD's forthcoming processor designs, codenamed Rembrandt and Raphael. These processors are what AMD is bringing to the market now and in the near future, meaning that the software ecosystem has to prepare. Additionally, CPU-Z has been updated with preliminary support for Intel's upcoming 13th Generation Raptor Lake processors, alongside Intel ARC 3/5/7 DG2 designs. CPU-Z developers also improved validation process for high-frequency overclocking submissions of over 6 GHz. The full changelog is listed below.

Download CPU-Z 2.01 here.

AMD Ryzen 7000 "Zen 4" Processors Have DDR5 Memory Overclocking Design-Focus

AMD's first desktop processor with DDR5 memory support, the Ryzen 7000 series "Raphael," based on the "Zen 4" microarchitecture, will come with a design focus on DDR5 memory overclocking capabilities, with the company claiming that the processors will be capable of handling DDR5 memory clock speeds "you maybe thought couldn't be possible," according to Joseph Tao who is a Memory Enabling Manager at AMD.

Tao stated: "Our first DDR5 platform for gaming is our Raphael platform and one of the awesome things about Raphael is that we are really gonna try to make a big splash with overclocking and I'll just kinda leave it there but speeds that you maybe thought couldn't be possible, may be possible with this overclocking spec." We are hearing reports of AMD innovating a new overclocking standard for DDR5 memory, which it calls RAMP (Ryzen Accelerated Memory Profile), which it is positioning as a competing standard to Intel's XMP 3.0 spec.

AMD Ryzen 7000 "Raphael" Zen 4 Processors Enter Mass-Production by April-May?

The next-generation AMD Ryzen 7000 "Raphael" desktop processors in the Socket AM5 package are rumored to enter mass-production soon, according to Greymon55 on Twitter, a reliable source with AMD leaks. Silicon fabrication of the chips may already be underway, as the source claims that packaging (placing the dies on the fiberglass substrate or package), will commence by late-April or early-May. "Raphael" is a multi-chip module of "Zen 4" CCDs fabricated on the TSMC N5 (5 nm) node, combined with a cIOD built on a yet-unknown node. A plant in China performs packaging.

It's hard to predict retail availability, but for the Ryzen 5000 "Vermeer" processors, this development milestone was reached in June 2020, with the first products hitting shelves 4 months later, in November. This was, however, in the thick of the pre-vaccine COVID-19 pandemic. The "Zen 4" CPU cores are expected to introduce an IPC increase, as well as higher clock speeds. Also on offer will be next-gen connectivity, including PCI-Express Gen 5 (including CPU-attached Gen 5 NVMe), and DDR5 memory. These processors will launch alongside Socket AM5 motherboards based on the new AMD 600 series chipsets.

AMD Ryzen 7000 Series "Raphael" Processors to Come with up to 170 Watt TDP for 16-Core SKUs

AMD is slowly preparing to transition its consumer base into a new platform and processor architecture with the launch of Ryzen 7000 series processors codenamed Raphael. Based on the new AM5 LGA socket, these processors will come with up to 16 cores and 32 threads at the top-end configurations. Thanks to the latest round of rumors, we managed to find out just what TDP rating two SKUs will carry. According to a well-known leaker @graymon55, AMD is rating the 12-core SKU with a TDP of 105 Watts. On the other hand, the top-end 16-core 7000 series SKU replacing the current Ryzen 9 5950X will carry a large TDP of 170 Watts.

The 170 Watt TDP configuration will likely require better cooling efforts. AMD will probably advise users to invest in better cooling solutions, such as AIO liquid coolers or giant air coolers.

AMD Socket AM5 "Raphael" Ryzen Processor Confirmed for H2-2022 Launch

AMD's next-generation Ryzen "Raphael" processor could launch only in the second half of 2022, confirms a leaked company slide scored by VideoCardz. The slide points to a Ryzen 5000X3D series product-stack update within the 1H-2022. These are Socket AM4 processors that leverage the company's updated "Zen 3(+)" CPU core die (CCD), which features 64 MB of 3D Vertical cache memory in addition to 32 MB of L3. AMD claims that 3DV Cache technology significantly improves performance akin to a generational update (anywhere between 5% to 25% depending on the application). The company is targeting "Spring" 2022 for launch, which would put this around early-Q2.

The "Raphael" Socket AM5 processor is sure to catch much of the attention, as it's the company's true next-gen desktop product. It heralds Socket AM5, a new LGA-based socket; and next-generation connectivity that includes DDR5 memory and PCI-Express Gen 5. The CCDs of these processors are built on the TSMC N5 (5 nm) silicon fabrication node, and are based on the "Zen 4" microarchitecture. The leaked slide shows the first grainy picture of Socket AM5, with a retention mechanism not unlike what we're used to, on the Intel platform. We're hearing rumors that AM5 will somehow manage cooler-compatibility with AM4 despite the radical redesign to the socket. An H2-2022 launch would put "Raphael" close to Intel's 13th Gen Core "Raptor Lake" launch, as team blue hopes to return to an annual IPC-uplift cadence, with up to 8 "Raptor Cove" P-cores, and 16 "Gracemont" E-cores.

Possible AMD Prototype Processor with DDR5 Memory Hits BAPCo CrossMark Database

Quite possibly the first sighting of a next-generation AMD processor with DDR5 memory surfaced on the web. A BAPCo CrossMark Database entry references a prototype processor with the name-string "AMD Eng Sample: 100-000000560-40_Y," running on a platform titled "ASUSTeK COMPUTER INC. M3402RA." The chip has 16 GB of memory across 2 memory channels, and a memory frequency of 4800 MHz DDR. The platform here could be either a desktop motherboard, or a notebook. 4800 MHz is an unusual memory speed for a mobile platform, unless it's a single stick of DDR5-4800 SO-DIMM, with two 40-bit channels.

The first notebooks with DDR5 memory make landfall early next year, when Intel launches mobile variants of its 12th Gen Core "Alder Lake" processors. This would mean that DDR5 SO-DIMMs are already in circulation with OEMs. If the theory of this being a mobile chip holds true, it could very well be the "Rembrandt" APU that combines "Zen 3+" CPU cores with an iGPU based on the RDNA2 graphics architecture. If however the platform is a prototype Socket AM5 motherboard, it could be one of the first sightings of a next-generation "Raphael" desktop processor with "Zen 4" CPU cores, and a combination of DDR5 memory and PCI-Express Gen 5.

AMD Ryzen Mobile "Raphael-H" Series Could Pack 16 Cores Based on Zen 4 Architecture

As we await the update of AMD's highly anticipated 6000 series Rembrandt APUs based on Zen 3 cores and RDNA2 graphics, we are in for a surprise with information about the next generation, more than a year away, of Ryzen 7000 series mobile processors based on Zen 4 architecture. Codenamed Raphael-H, it co-exists with the upcoming lineup of Phoenix APUs, which come after the 6000 series Rembrandt APU lineup. This mobile variant of the forthcoming desktop Raphael processors features as many as 16 cores based on Zen 4 architecture. What is so special about the Raphael-H is that it represents a mobile adaptation of desktop processors, and we are not sure how it will be different from the Phoenix APUs. However, we assume that Phoenix is going to feature a more powerful graphics solution.

The confusing thing is the timeline of these processors. First comes the Rembrandt APUs (6000 series) and then both the Raphael-H and Phoenix mobile processors. AMD could disable iGPU on mobile Raphael-H designs. However, that is just a guess. We have to wait to find out more in the upcoming months.

AMD Zen 4 "Raphael" Processors Feature Improved Thermal Sensors and Power Management

AMD is slowly preparing the launch of the latest and greatest Ryzen processor family based on the Zen 4 CPU core design. Among various things that are getting an overhaul, the Raphael processor generation is now getting revamped temperature reading and better power management circuitry. According to an Igor's Lab report, AMD has prepared a few new improvements that will make temperature reading and power management easier for PC enthusiasts. Currently, the reported CPU temperature is called Tcontrol (Tctl), which is what the cooling solution sees. If Tctl is high, the fans spin up and cool the system. If Tctl is low, the fans slow down to reduce noise.

With Raphael, the CUR_TEMP (current temperature) output part of Tctl has been upgraded to reflect a much smoother curve, and avoid jittering with fans as they are not spiking so suddenly anymore. This is helping contribute to the noise output and has made it run at a consistent fan speed in the system. Another note about Raphael is a new power management technique. AMD has designed the AM5 platform to avoid sudden power spikes, to maintain maximum efficiency over time. It is a design decision made from the very start, and the CPU will try to constrain itself in the TDP range that it is configured for. For more details about the circuitry, please head over to the Igor's Lab article.

Alleged AMD AM5 Socket for Zen 4 Raphael Processors Leaks

AMD is slowly preparing to launch its next-generation processors based on the new AM5 socket. The new lineup of processors will be based on the upgraded Zen 4 architecture that is said to bring multiple microarchitecture improvements and enhancements, equaling to a possible high-performance increase. Today, according to ExecutableFix, the person who provided us with renders of AMD's upcoming AM5 socket designed for next-generation Raphael processors. As we previously reported, AM5 is doing away from PGA and switching to LGA type instead, where pins are delivered on the socket, not the CPU like we used to see with AMD processors.

The LGA-1718 socket, pictured in the renders below, looks like a simple retention mechanism, where there is one metal arm to hold the lid down under pressure. If it turns out to be true, this implementation will be a very positive upgrade over the past PGA socket found on AM4 and before. We can look forward to seeing what AMD will deliver once the launch of Raphael processors gets closer.

AMD Zen 4 Desktop Processors Likely Limited to 16 Cores, 170 W TDP

We have recently seen several reputable rumors confirming that AMD's Zen 4 Raphael desktop processors will be limited to 16 cores with 2 compute units. There were previous rumors of a 24 core model with 3 compute units however that now seems unlikely. While the core counts won't increase some skews may see a TDP increase up to 170 W which should offer some performance uplift. AMD is expected to debut their 5 nm Zen 4 Raphael desktop processors in 2022 which will come with support for PCIe 5.0 and DDR5. The processors will switch to a new AM5 LGA1718 socket and will compete with Intel's Alder Lake-S successor Raptor Lake which could feature 24 cores.

AMD Raphael CPU IHS Features Cutouts for Capacitors

Last week,we have covered the leak of AMD's upcoming Raphael processor integrated heat spreader (IHS), which featured a rather unique design. While we have made speculations as to why the design was made like that, it seems that we now have an answer to the question. It was previously believed that the unique IHS design was there to protect a double-substrate design, like Intel designed with Skylake-X. However, thanks to the updated design by ExecutableFix, we now know that AMD's design choice for Raphael is based on the simple fact that the IHS needs those cutouts for capacitors, as this seems to be the only place to have them.

As you can see below, there was no room on the LGA side, where the LGA pads are placed, and a lot of speculation suggested that capacitors were placed under the IHS or in IHS cutouts. The latter has proven to be the case according to this leak. You can check out some of the updated renderings in the images below.

AMD Ryzen 7000 Series "Raphael" Zen 4 Processor IHS Design Gets Leaked

AMD is preparing to switch things up a bit with its upcoming AM5 platform. The new platform is said to bring significant changes to the design of the socket and the CPU package, where we will see some new design choices and decisions. For starters, all of the processors made for the AM5 platform will come in a land grid array (LGA) configuration, very similar to that of Intel. Thanks to the rendering of ExecutableFix, we got to see exactly how will the new LGA design look like. And today, we get to see more details of the AMD's upcoming Raphael processor's integrated heat spreader (IHS) design.

The IHS serves the purpose of spreading the heat away from the die and dissipating it efficiently. However, IHS designs can sometimes be very interesting. According to this rendering from ExecutableFix, AMD's upcoming Raphael design, based on Zen 4 core, will feature a unique IHS design, which can be seen below.

AMD Ryzen 8000 Series Processors Based on Zen 5 Architecture Reportedly Codenamed "Granite Ridge"

Today, we have talked about AMD's upcoming Raphael lineup of processors in the article you can find here. However, it seems like the number of leaks on AMD's plans just keeps getting greater. Thanks to the "itacg" on Weibo, we have learned that AMD's Ryzen 8000 desktop series of processors are reportedly codenamed as Granite Ridge. This new codename denotes the Zen 5 based processors, manufactured on TSMC's 3 nm (N3) node. Another piece of information is that AMD's Ryzen 8000 series APUs are allegedly called Strix Point, and they also use the 3 nm technology, along with a combination of Zen 5 and Zen 4 core design IPs. We are not sure how this exactly works out, so we have to wait to find out more.

Rumor: AMD Ryzen 7000 (Raphael) to Introduce Integrated GPU in Full Processor Lineup

The rumor mill keeps crushing away; in this case, regarding AMD's plans for their next-generation Zen designs. Various users have shared pieces of the same AMD roadmap, which apparently places AMD in an APU-focused landscape come their Ryzen 7000 series. we are currently on AMD's Ryzen 5000-series; Ryzen 6000 is supposed to materialize via a Zen 3+ design, with improved performance per watt obtained from improvements to its current Zen 3 family. However, Ryzen 7000-series is expected to debut on AMD's next-gen platform (let's call it AM5), which is also expected to introduce DDR5 support for AMD's mainstream computing platform. And now, the leaked, alleged roadmaps paint a Zen 4 + Navi 2 APU series in the works for AMD's Zen 4 debut with Raphael - roadmapped for manufacturing at the 5 nm process.

The inclusion of an iGPU chip with AMD's mainstream processors may signal a move by AMD to produce chiplets for all of its products, and then integrating them in the final product. You just have to think about it in the sense that AMD could "easily" pair one of the eight-core chiplets from the current Ryzen 5800X, for example, with an I/O die (which would likely still be fabricated with Global Foundries) an an additional Navi 2 GPU chiplet. It makes sense for AMD to start fabricating GPUs as chiplets as well - AMD's research on MCM (Multi-Chip Module) GPUs is pretty well-known at this point, and is a given for future development. It means that AMD needed only to develop one CPU chiplet and one GPU chiplet which they can then scale on-package by adding in more of the svelte pieces of silicon - something that Intel still doesn't do, and which results in the company's monolithic dies.
