AMD Radeon HD 5870 1 GB GDDR5 Review

Architecture »


AMD Logo

AMD's new Radeon HD 5800 Series has been surrounded by a lot of secrecy in the last months because AMD was very careful with providing information to anyone. Once the press had been briefed however this turned to the exact opposite. In the last few weeks not a single day has passed where no new leaked information turned up in some Internet forum. As you probably remember, we had an article collecting all the leaked images, which offered a huge amount of speculative information. But now the NDA is expired and we can provide you with our own pictures and performance data.

Today AMD introduces two new cards: the ATI Radeon HD 5850 and the ATI Radeon HD 5870. A third product, called "ATI Radeon HD 5870 Eyefinity6 Edition" has also been announced but it is simply a HD 5870 with six DisplayPort outputs. If you were drooling to see the HD 5870 X2 launched today, then you'll have to wait a few more months.
All the new cards are based on AMD's "Cypress" graphics processor, which could be described as RV870 equivalent. But (at least for now) AMD has done away with calling their GPUs by the Ryxxx codenames and uses the engineering codenames and the graphics card product names only.

Also check out our other HD 5800 related reviews: AMD Radeon HD 5870 PCI-Express Scaling and AMD Radeon HD 5870 CrossFire

HD 4890
GTX 275
GTX 280
HD 4870 X2
GTX 285
HD 5850
HD 5870
GTX 295
Shader units 8002402402x 800240144016002x 240
ROPs1632322x 163232322x 28
GPURV790GT200GT2002x RV770GT200bCypressCypress2x GT200b
Transistors959M1400M 1400M 2x 956M1400M2154M2154M2x 1400M
Memory Size1024 MB 896 MB1024 MB2x 1024 MB 1024 MB1024 MB1024 MB2x 896 MB
Memory Bus Width 256 bit 448 bit 512 bit 2x 256 bit 512 bit 256 bit 256 bit 2x 448 bit
Core Clock850 MHz 633 MHz 602 MHz 750 MHz 648 MHz 725 MHz 850 MHz 576 MHz
Memory Clock975 MHz 1134 MHz 1107 MHz 900 MHz 1242 MHz 1000 MHz 1200 MHz 999 MHz

Packaging & Contents

We received a card only, without retail packaging or other accessories.
