InWin 309 Review 12

InWin 309 Review

(12 Comments) »

Introduction

InWin Logo

I would like to thank InWin for supplying the review sample.


InWin is known for pushing very specific designs with their cases and in recent years has always tried to up itself at trade shows like CES and Computex with the next wildest concept case out there, which is actually also brought to market in a limited edition. Today, we get to take a look at the InWin 309. This case offers basic internal functionality to allow for modern hardware installation. However, InWin has designed a 144 aRGB LED-equipped front panel which is the clear focus of this case.

Specifications

InWin 309
Case Type:Mid-Tower
Material:SECC, Tempered Glass, ABS
Weight:13.65 kg
Slots:7
Drive Bays:2x Internal 2.5/3.5"
2x Internal 2.5"
Motherboard
Form Factors:
Mini-ITX, Micro-ATX, ATX
Dimensions:500 x 238 x 553 mm
Front Door/Cover:144 addressable RGB panel
Front Fans:N/A
Rear Fans:1 x 120 mm (1x InWin EGO 120 mm pre-installed)
Top Fans:3 x 120 mm (3x InWin EGO 120 mm pre-installed)
Bottom Fans:3 x 120 mm (optional)
Side Fans:N/A
I/O:1x USB 3.1 Gen2 Type C
2x USB 3.0
1x Headphone
1x Microphone
Fan/LED Controller:Fan & LED controller PCB embedded for InWin GLOW2 Software
Compatibility:CPU Cooler: 160 mm
GPU: 350 mm
PSU: 200 mm

Packaging


The case ships in a really big box, which is unusual for a unit that can be considered traditional when it comes to its overall dimensions. Two sides only hold some logos, while the others go into details about the InWin 309.


Foam spacers and a cloth bag protect the chassis during shipping and while it is being handled at the factory.
