AMD Readies Z490 Chipset with More (and Faster) PCIe Lanes

AMD is reportedly readying a new high-end motherboard chipset positioned higher than even its upcoming X470 chipset, which makes its market debut on April 19. The new Z490 chipset, as it's called, is emerging to be significantly different from X470, and could finally overcome its biggest limitation - downstream PCIe connectivity. While the X470, like its predecessor, puts out just 8 downstream PCIe lanes, which are PCI-Express gen 2.0 at that, the new Z490 will put out a total of 12 PCI-Express gen 3.0 downstream lanes, which will power additional bandwidth-hungry devices, such as additional M.2 slots, external USB 3.1 controllers, 10 GbE controllers, etc. The Z490 was first leaked through a GIGABYTE Aorus internal presentation.

In its current implementation, socket AM4 motherboards have a total of 24 PCI-Express gen 3.0 lanes from the AM4 SoC, besides 6-8 gen 2.0 lanes from the chipset. From this SoC budget, 16 lanes are allocated for PEG (PCI-Express Graphics), 4 lanes as chipset-bus (connecting the SoC with the chipset), and the remaining 4 lanes powering one 32 Gbps M.2 slot. Additional M.2 slots are either gen 2.0, from the chipset's downstream lane budget, or split from the PEG budget. The Z490 overcomes this with a downstream PCIe root complex that's not just 50% broader, but also twice as fast, with PCI-Express gen 3.0. The rest of its feature-set appears to be identical to the X470. There's no timeline on when we can expect Z490 to launch.
Source: VideoCardz
Add your own comment

27 Comments on AMD Readies Z490 Chipset with More (and Faster) PCIe Lanes

#1
dj-electric
That's 1 extra chipset that nobody asked for. The childish "HAHA WE GOT Z490 BEFORE INTEL" move doesn't make it better.
Posted on Reply
#2
btarunr
Editor & Senior Moderator
dj-electric said:
That's 1 extra chipset that nobody asked for. The childish "HAHA WE GOT Z470 BEFORE INTEL" move doesn't make it better.
Zee four ninety.

They'll probably time this with Intel Z390 launch. "We too have a new chipset, and it's 100 numbers more advanced."

This also explains why there's no Crosshair VII Extreme yet.
Posted on Reply
#3
ppn
Yeah but the CPU is still 6000 numbers behind even if they skip zen 4 for being unlucky. Intel should just fully integrate the chipset. That way the mother board will be chipsetless.
Posted on Reply
#4
_JP_
EDIT: If this means more M.2 rooted to x4, I'm all for it.

dj-electric said:
That's 1 extra chipset that nobody asked for. The childish "HAHA WE GOT Z490 BEFORE INTEL" move doesn't make it better.
Joe Average still thinks the BMW 740i has a 4.0L V8...despite looking childish to us, it's a marketing move.
Posted on Reply
#5
TheLostSwede
ppn said:
Yeah but the CPU is still 6000 numbers behind even if they skip zen 4 for being unlucky. Intel should just fully integrate the chipset. That way the mother board will be chipsetless.
It doesn't make sense to integrate all the chipset features into the CPU from a cost perspective. You also have a basic LPC Super I/O controller on all motherboards that's deemed too basic to integrate into the chipset. That doesn't even include all the third party chipsets that are added for things like USB 3.1, Thunderbolt etc. so you'll never have a chipset-less motherboard in that sense.
Posted on Reply
#6
Gasaraki
WTF, AMD. Z490? You couldn't name it something else?
Posted on Reply
#7
iO
@OP: 8 + Gen3*4 doesnt make 12 Gen3.0 lanes...
Posted on Reply
#8
newtekie1
Semi-Retired Folder
Wait, I thought X470 was supposed to have PCI-E 3.0, but it is still just 8 PCI-E 2.0. AMD's chipsets are a mess...
Posted on Reply
#9
Fatalfury
Z490 ???

why not X490??? man....
cant they create their own names than copying...this is getting ridiculous...making it more confusing for the consumer.

i guess thats what u expect from a low-tier company like (AMD) $10 Billion vs the tech giants & market leader Intel($240 Billion) or Nvidia ($130 Billion)....

or maybe AMD should have named it X470X Series...that sounds familiar.. ( ͡° ͜ʖ ͡°)
Posted on Reply
#10
R0H1T
Hmm (thinks harder!) yup looks fake :ohwell:
Fatalfury said:
Z490 ???

why not X490??? man....
cant they create their own names than copying...this is getting ridiculous...making it more confusing for the consumer.

i guess thats what u expect from a low-tier company like (AMD) $10 Billion vs the tech giants & market leader Intel($240 Billion) or Nvidia ($130 Billion)....

or maybe AMD should have named it X470X Series...that sounds familiar.. ( ͡° ͜ʖ ͡°)
So what does that make Intel, who poured literally tens of billions of $ into the mobile sector only to fail year after year, or Nvidia, who aren't profitable in selling anything other than a GPU :rolleyes:
Posted on Reply
#11
Tomorrow
Yeah it's pretty pointless to make a new chipset just to add a few more lanes but being identical otherwise. Why didn't they add this to X470 in the first place?
Z490 naming is obviously to one-up Intel's Z390. Not all Intel does is worth copying tho. This is the prime example.

I also partially blame ASMedia for this a they are the one making these chipsets.
Posted on Reply
#12
Fatalfury
R0H1T said:
Hmm (thinks harder!) yup looks fake :ohwell:
So what does that make Intel, who poured literally tens of billions of $ into the mobile sector only to fail year after year, or Nvidia, who aren't profitable in selling anything other than a GPU :rolleyes:
Intel's got plenty of cash..they can do whatever they want ..even if they lose billions..it dont think it matters much to them..unlike AMD who are in verge in bankruptcy..
Intel said in an interview...they dont mind taking risks..like now they are investing billions in Driver-less AI solutions..

on the other hand Nvidia..they are profitable in server business & AI & other data center -technologies..
well isnt it enough to be making billions in just sellin GPU??? well they are a GPU tech company afterall controlling 85% of the entire market in the entire world.
Posted on Reply
#13
R0H1T
Fatalfury said:
Intel's got plenty of cash..they can do whatever they want ..even if they lose billions..it dont think it matters much to them..unlike AMD who are in verge in bankruptcy..
Intel said in an interview...they dont mind taking risks..like now they are investing billions in Driver-less AI solutions..

on the other hand Nvidia..they are profitable in server business & AI & other data center -technologies..
well isnt it enough to be making billions in just sellin GPU??? well they are a GPU tech company afterall controlling 85% of the entire market in the entire world.
So how much did that pile of cash help Intel? As for risks ~ outside of x86 chips, plus a (former) JV with Micron, can you name any other venture that they succeeded in, no to mention the Itanic?

Your source? AFAIK Intel have them beat in PC while QC/Apple/PowerVR/ARM beat them in the mobile space, AMD has a big lead in consoles.
Posted on Reply
#14
Shamalamadingdong
newtekie1 said:
Wait, I thought X470 was supposed to have PCI-E 3.0, but it is still just 8 PCI-E 2.0. AMD's chipsets are a mess...
That was just a rumor. You can't pull lanes out of thin air. It uses 4 3.0 lanes to the chipset and it makes more sense to split that into 8 lanes which of course halves bandwidth to 2.0.
They'd have to unlock more lanes on the CPU itself which I think they won't do for compatibility and validation reasons.
I won't put too much stock into what's probably a fake leaked slide but if so there's probably quite a few limitations that causes them to launch a new chipset.
Posted on Reply
#15
Parn
newtekie1 said:
Wait, I thought X470 was supposed to have PCI-E 3.0, but it is still just 8 PCI-E 2.0. AMD's chipsets are a mess...
That's what I thought too. So now what are the exact differences between X470 and X370 then?
Posted on Reply
#16
Fatalfury
R0H1T said:
So how much did that pile of cash help Intel? As for risks ~ outside of x86 chips, plus a (former) JV with Micron, can you name any other venture that they succeeded in, no to mention the Itanic?

Your source? AFAIK Intel have them beat in PC while QC/Apple/PowerVR/ARM beat them in the mobile space, AMD has a big lead in consoles.
if Intel losing in mobile space..makes you happy, then be happy.
AMD doesnt even have a mobile space..All that can save them are a CryptoMiners & that homerun is going to end soon..

"AMD has a big lead in consoles.."

Then why were they having 5+years of consective loss in thier balance sheet
Nvidia didnt want to make for PS4 or Xbox because it was not too profitable..& was not worth it & they got hardware 2X times powerful selling like hotcakes..

"i dont want to go offtopic anymore.."
Posted on Reply
#17
TheLostSwede
Shamalamadingdong said:
That was just a rumor. You can't pull lanes out of thin air. It uses 4 3.0 lanes to the chipset and it makes more sense to split that into 8 lanes which of course halves bandwidth to 2.0.
They'd have to unlock more lanes on the CPU itself which I think they won't do for compatibility and validation reasons.
I won't put too much stock into what's probably a fake leaked slide but if so there's probably quite a few limitations that causes them to launch a new chipset.
That's not how it works. Especially as the chipset also has things like SATA, USB 3.0 etc. that uses the PCIe bandwidth to/from the CPU.
Now that bandwidth is just going to be even more restricted, but then again, it hasn't stopped Intel, as they have a 4x PCIe 3.0 interconnect between the CPU and the chipset as well, they just called it a fancy name (DMI) to make it sound like it was something special.

When it comes to these chipsets, a PCIe switch would be used to "make" more PCIe lanes, but the bandwidth between the chipset and the CPU is still limited, both for AMD and Intel.
It doesn't appear to limit performance in most cases though, as otherwise Intel boards with NVMe drives connected via the chipset in the case of Intel boards, wouldn't perform as well as they do.
Posted on Reply
#18
newtekie1
Semi-Retired Folder
Shamalamadingdong said:
That was just a rumor. You can't pull lanes out of thin air. It uses 4 3.0 lanes to the chipset and it makes more sense to split that into 8 lanes which of course halves bandwidth to 2.0.
They'd have to unlock more lanes on the CPU itself which I think they won't do for compatibility and validation reasons.
I won't put too much stock into what's probably a fake leaked slide but if so there's probably quite a few limitations that causes them to launch a new chipset.
Look up how PCI-E switching works. Intel's chipset provides 24 PCI-E 3.0 lanes with the same 4 lane link to the processor. There are other manufacturers that push it even further, broadcom has a chip that will give 60 PCI-E 3.0 lanes from a single 4 lane uplink.
Posted on Reply
#19
kastriot
Prolly they will phase out 470 chipset in favor of 490 because it has no purpose anymore.
Posted on Reply
#20
Captain_Tom
We can expect this to launch whenever AMD decides to announce the 8-core/4.6GHz 2800X is indeed real...
Posted on Reply
#21
evernessince
dj-electric said:
That's 1 extra chipset that nobody asked for. The childish "HAHA WE GOT Z490 BEFORE INTEL" move doesn't make it better.
lol, this is funny because Nvidia and Intel do this all the time. That's essentially what the xx80 Ti is reserved for from Nvidia.

Tomorrow said:
Yeah it's pretty pointless to make a new chipset just to add a few more lanes but being identical otherwise. Why didn't they add this to X470 in the first place?
Z490 naming is obviously to one-up Intel's Z390. Not all Intel does is worth copying tho. This is the prime example.

I also partially blame ASMedia for this a they are the one making these chipsets.
Because it would have increased the cost to produce X470. Didn't AMD just get bashed the other day for not changing the name of some lower spec'd RX 550's? Jesus people you can't have to both ways. If it has different specs then it's name should be changed.
Posted on Reply
#22
Shamalamadingdong
TheLostSwede said:
That's not how it works. Especially as the chipset also has things like SATA, USB 3.0 etc. that uses the PCIe bandwidth to/from the CPU.
Now that bandwidth is just going to be even more restricted, but then again, it hasn't stopped Intel, as they have a 4x PCIe 3.0 interconnect between the CPU and the chipset as well, they just called it a fancy name (DMI) to make it sound like it was something special.

When it comes to these chipsets, a PCIe switch would be used to "make" more PCIe lanes, but the bandwidth between the chipset and the CPU is still limited, both for AMD and Intel.
It doesn't appear to limit performance in most cases though, as otherwise Intel boards with NVMe drives connected via the chipset in the case of Intel boards, wouldn't perform as well as they do.
Uh what? What is more restricted?
16/4/4 is what we have now. That's PCI-E slots, m.2 slot and chipset. Using a switch is a neat way to split lanes but you don't get anymore bandwidth. If you hook up a bunch of NVMe drives to the Intel chipset and hammer them, you'll be bottlenecked pretty quickly. AMD took the simple approach of saying you'll need more than 4 lanes for peripherals so you'll only get gen 2 speeds but you'll be guaranteed the full speed at all times. It's two different approaches. There's a trade-off either way. Considering the lanes we see in higher end AMD chips there should be untapped potential for mainstream chips.
newtekie1 said:
Look up how PCI-E switching works. Intel's chipset provides 24 PCI-E 3.0 lanes with the same 4 lane link to the processor. There are other manufacturers that push it even further, broadcom has a chip that will give 60 PCI-E 3.0 lanes from a single 4 lane uplink.
Yes but are you getting Threadripper levels of bandwidth from your Broadcom chip that splits that x4 link or will that triple SLI setup get choked? Or will your 4 NVMe drive RAID array be able to run full tilt on your DMI link?

Don't get me wrong. We need more lanes and sometimes (or even most of the time) a switch is a great solution but it would be disingenuous to call it 24 lanes of PCI-E 3.0 because if you're going to use all those lanes simultaneously then you have a bandwidth problem so it relies on peripherals not needing full bandwidth all the time. It gives you a whole lot of freedom but it isn't perfect and I don't find AMD's approach to be bad either. It's more straight forward in a wysiwyg kind of way. I'm sure the choice to go that route was a combination of cost and outsourcing chipset design but it works though.
Posted on Reply
#23
newtekie1
Semi-Retired Folder
Shamalamadingdong said:
Uh what? What is more restricted?
16/4/4 is what we have now. That's PCI-E slots, m.2 slot and chipset. Using a switch is a neat way to split lanes but you don't get anymore bandwidth. If you hook up a bunch of NVMe drives to the Intel chipset and hammer them, you'll be bottlenecked pretty quickly. AMD took the simple approach of saying you'll need more than 4 lanes for peripherals so you'll only get gen 2 speeds but you'll be guaranteed the full speed at all times. It's two different approaches. There's a trade-off either way. Considering the lanes we see in higher end AMD chips there should be untapped potential for mainstream chips.

Yes but are you getting Threadripper levels of bandwidth from your Broadcom chip that splits that x4 link or will that triple SLI setup get choked? Or will your 4 NVMe drive RAID array be able to run full tilt on your DMI link?

Don't get me wrong. We need more lanes and sometimes (or even most of the time) a switch is a great solution but it would be disingenuous to call it 24 lanes of PCI-E 3.0 because if you're going to use all those lanes simultaneously then you have a bandwidth problem so it relies on peripherals not needing full bandwidth all the time. It gives you a whole lot of freedom but it isn't perfect and I don't find AMD's approach to be bad either. It's more straight forward in a wysiwyg kind of way. I'm sure the choice to go that route was a combination of cost and outsourcing chipset design but it works though.
The x4 link back to the CPU is enough because not all the traffic flows back to the CPU. That is why Intel is able to get 24 lanes with only a 4 lane link back to CPU.
Posted on Reply
#24
Shamalamadingdong
newtekie1 said:
The x4 link back to the CPU is enough because not all the traffic flows back to the CPU. That is why Intel is able to get 24 lanes with only a 4 lane link back to CPU.
Or in other words:
it relies on peripherals not needing full bandwidth all the time
Posted on Reply
#25
Tomorrow
evernessince said:
Because it would have increased the cost to produce X470. Didn't AMD just get bashed the other day for not changing the name of some lower spec'd RX 550's? Jesus people you can't have to both ways. If it has different specs then it's name should be changed.
X470 is an upper end chipset. I hardly think cost is much of a concern on a chpset that has boards starting at 130$+ going to $330. Yes it is less than ideal when you have two X470 boards where one has x8 3.0 lanes and other has x8 2.0 lanes but unlike graphics cards this does not affect performance so heavily.
Posted on Reply
