All-New MSI X870(E) Motherboards - Built to Dominate Next-Gen AI Computing

MSI unveils the X870E and X870 motherboards, designed to harness the full power of AMD's Ryzen 9000 Series desktop processors. The lineup includes four models: MEG X870E GODLIKE, MPG X870E CARBON WIFI, MAG X870 TOMAHAWK WIFI, and PRO X870-P WIFI. These motherboards deliver exceptional value and performance with cutting-edge features and exclusive MSI innovations. Offering top components, innovative features, and easy DIY options, MSI's X870E and X870 motherboards make building and using your PC seamless.

Introducing MSI's Ultra Connect feature in the X870E and X870 motherboards, offering next-gen networking, storage, and expansion. With built-in 5G LAN and Wi-Fi 7, users can enjoy lightning-fast speeds, reaching up to 5.8 Gbps. As well as TriLink Connectivity, Expansion is made to future-proof with PCIe Gen 5.0 for next-gen graphics cards and SSDs. The USB4 ports, which are Thunderbolt compatible, enable fast data transfers and support a wide range of next-gen devices, including display output through USB-C.

ATP Unveils N751Pi PCIe Gen4 NVMe M.2 2280 SSD with 125°C Operating Temperature Range

ATP Electronics, a global leader in specialized storage and memory solutions, proudly announces the launch of the N751Pi PCIe Gen 4 NVMe M.2 2280 SSDs, which set a new industry standard with unmatched endurance among industrial solid state drives (SSDs) configured with pseudo single-level cell (pSLC) NAND.

The groundbreaking 150K P/E cycling configuration of NAND was achieved, thanks to a combination of ATP's exceptional strengths — from the use of prime NAND package, stringent NAND integrated circuits (IC) characterization and 100% NAND screening and validation capabilities, to ATP's own-developed firmware, specialized hardware configurations, and technologies.

Six Mod Artists Compete to Redesign Thermaltake TOUGHRAM XG RGB D5

Thermaltake, a leading PC DIY brand for premium hardware solutions, kicked off the "2024 Thermaltake RAM MOD Invitational" an annual competition that gathers modders from all corners of the world to mod the designated Thermaltake ram into their own masterpiece. This year we invited six modders from Austria, Italy, Japan, Thailand, and the United Kingdom to modify the TOUGHRAM XG RGB D5 Memory DDR5.

Participating modders are given a specific time frame to modify the RAM heatsinks, without changing the overall appearance and layout of the RAM itself. Contestants must only use our TOUGHRAM XG RGB D5 modules and cannot add the ram to a motherboard or a PC build. However, they can create a stand or platform for the modules but the overall modules must remain intact with the original design as the main focus.

Team Group T-Force and T-Create NVMe SSDs at Computex 2024: Magnetic Stacked Heatsinks

M.2-2280 SSDs are always smaller than they look in pictures, a quarter of the size of a DIMM, but we've come across some huge cooling solutions. One of the most interesting of these is the T-Force Dark Airflow 06 magnetic-stacked cooling solution. An extruded aluminium heatsink with its fins positioned sideways, has two flattened surfaces, one of which makes contact with the SSD, the other is equally flat, and can make contact with another such heatsink.

A 20 mm fan pushes airflow sideways through the heatsink. The heatsink is magnetized to help with the stacking. The Dark Airflow 05 is a more conventional fin-stack heatsink that isn't expandable, it uses a simple aluminium fin-stack to which heat is fed by two copper heatpipes. The T-Force GE Pro Gen 5 is an M.2-2280 drive that leads Team Group's gaming SSD lineup. It comes in capacities of up to 4 TB, with transfer speeds of 14 GB/s reads, with up to 11 GB/s writes. The T-Create I54 Ai Gen 5 is not far behind, with a 4 TB, and up to 14 GB/s sequential speeds on tap, with a large amount of SLC caching that should benefit AI workloads.

Lexar Announces New NM790 M.2 SSD With Heatsink for PlayStation 5

Lexar, a leading global brand of flash memory solutions, s excited to announce the NM790 with Heatsink M.2 2280 PCIe Gen 4×4 NVMe SSD. This product release builds upon the success of its predecessor, the NM790 (without heatsink) which claimed several awards, including Best High-Capacity SSD from PC Gamer, Best High-Capacity PCI Express 4.0 SSD from PC Mag, Best Dram-less SSD 2023 from Tom's Hardware, and more.

This new version of the NM790 is designed for PS5 and PC gaming rigs and delivers even more performance - 7400 MB/s sequential read, 6500 MB/s sequential write, with random read and write speeds of up to 1,100K IOPS. The addition of an integrated heatsink keeps things running smoothly even at full throttle, ensuring that systems stay cool and maintain speed, power efficiency, and thermal control for sustained high-performance on both PlayStation 5 and PCs.

Lexar Unveils a New microSD Card and New Gaming Products at IFA 2023

Lexar, a leading global brand of flash memory solutions, is unveiling a variety of new products that are estimated to be launched in Q4 2023. Designed for photography professionals and PC enthusiasts to accelerate their workflow, the expanded portfolio includes a new microSD card, internal SSDs, DRAM, and portable SSDs.

The new Professional GOLD micro SDXC UHS-II card, available in 128 GB and 256 GB, leverages the high-speed performance and a Video Speed Class 60 (V60) rating, allowing users to quickly capture, play back, and transfer high-definition multimedia files, including 4K video, with a read transfer speed up to 280 MB/s. This card is also great for use with gaming devices, sports camcorders, tablets, or smartphones, and drones.

PNY Shows Off M.2 SSD Heatsink with Two Fans and RGB Bling

PNY at the 2023 Computex, showed off an M.2-2280 SSD cooling solution with nor one, but two fans, in what is a sign of things to come with upcoming PCIe Gen 5 NVMe SSDs. The cooler features an extruded aluminium monoblock heatsink with a pair of 20 mm fans at its two ends. The central portion of the cooler has the bulk of its aluminium fins. A top-plate has an RGB illuminated, stylized PNY logo, which can be synchronized with the lighting of your PNY XLR8 Verto EPIC-X graphics cards. It's smarter on PNY's part to market the cooler as a separate product, than part of any upcoming PCIe Gen 5 SSD.

DeepCool Readying Assassin IV Premium CPU Air Cooler For Launch

DeepCool debuted its Assassin IV Dual Tower CPU cooler earlier this year at the CES 2023 trade show - as covered by TPU at the time - its very eye-catching design was described as looking: "like (a) big dark cube inside your case, with a shroud covering all its sheet-metal." The flagship high-performance CPU cooler seems to ready for an imminent launch, with press material and product images being released today for the Chinese market. Early impressions indicate that hardware enthusiasts are appreciative of the almost all-black monolithic aesthetic, with some folks predicting that DeepCool is going to win computer hardware product design awards.

DeepCool press material states (via translation) that its Assassin IV CPU cooler provides super silent operation while dealing with up to 280 W of heat - Intel's latest high-end Core i9 CPUs could be tamed with relative ease. The heatsink is comprised of 7 heat pipes with a dual fan attachment that includes 120 and 140 mm FDB fans - said to operate silently at high RPMs. The fans are rated at 500 - 1700 RPM, with an airflow delivery of 79.1 / 58.06 CFM in performance mode, and 63.76 / 46.75 CFM airflow for the gentler quiet mode. Deepcool's specifications indicate that these cooling fans produce less than or equal to 29.3 dB(A) noise at peak performance, and less than or equal to 22.6 dB(A) noise in quiet mode. The entire cooling solution consumes 2.88 W in performance mode.

Nextorage Readying NE5N Gen 5 SSD Range With Bulky Heatsink

Nextorage Japan is preparing its NE5N range of PCIe Gen 5 NVMe SSDs for launch in early June - listings have emerged on Newegg for 2 TB and 1 TB models - with a product page appearing recently on the company's (Japanese language) website. These units boast read and write speeds rated for operation up to 10 GB/s, and are based on Phison's E26 PCIe Gen 5 controller. Nextorage started off as a provider of PlayStation 5-oriented PCIe Gen 4 SSD products, due to company ties to Sony Corporation, but its upcoming NE5N range indicates that it intends to target buyers within the enthusiast PC market.

The initial batch of cutting edge SSDs are unlikely to end up in any PS5 consoles, thanks to a sizable dual formation heatsink - the Japanese company has filed a patent for the bulky two-level structure and heatpipe combination design. Gen 5 SSDs are said to be difficult to tame in terms of heat output, and manufacturers are going to great lengths (and sizes) to provide adequate cooling solutions in advance. Future versions of Nextorage Japan's NE5N NVMe M.2 2280 PCIe Gen 5 SSDs are being refined for compact PCs and laptops, so it will be interesting to find out about the intended thermal tempering for more cramped environments.

Thermalright HR-10 PRO Heatsink Prepared for Gen5 SSDs

Thermalright has quietly updated its product page this week, and has rolled out another SSD cooler that looks quite familiar. The HR-10 2280 PRO M.2 SSD heatsink is now featured on their website, where it sits close to a similar looking model - the now standard HR-10 2280. This non-PRO version was revealed late last month as a step up from the older HR-09 SSD heatsink. The brand new HR-10 2280 PRO sports a key upgrade over its passively cooled older siblings - a 30 mm 12 V cooling PWM fan has been integrated into the middle of the fin stack's body. Thermalright's latest M.2 heatsink also fully prepared for and compatible with the next generation of SSDs - its revised design will accommodate Gen 5 solid-state drive standards.

The HR-10 Pro is consists of four 5 mm-thick nickel-plated copper heatpipes that make contact with a user appointed M.2-2280 SSD, over a mirror-finish nickel-plated copper base-plate. The heatpipes loop through a dense aluminium fin-stack with slats designed to maximize surface area for highly effective heat dissipation. A die-cast metal top-plate with company branding completes the package. The HR-10 PRO weighs in at 95 g (so 10 g more than the standard HR-10). The heatsink measures 23.7 mm x 90.3 mm x 43.8 mm (WxDxH). Thermalright has not revealed any pricing or stock availability at the time of writing.

GELID Solutions IceROCK DDR Cooling Kit Available Now

GELID Solutions has introduced its brand new IceROCK DDR Cooling Kit to the world. This aftermarket heatsink radiator is constructed from high-grade aluminium and available to order in two finishes - black or silver. These kits offers primary support for DDR5 memory modules, but Gelid has made sure to provide full compatibility for older DDR3 and DDR4 RAM sticks. The optimized heatsink is light in weight and easy to install, and offers professional level cooling - ideal for overclocking and boosting enthusiasts.

The minimalist and sleek design only weighs in at 60 g, and the pure and high-grade aluminium heatsink guarantees excellent heat conductivity. The kit can be installed onto a wide variety of memory module shapes - be it low or high profile, plus single or double sided RAM arrangements.

Bitspower Intros Low-Profile M.2 SSD Armor

Bitspower today introduced the Low-Profile M.2 SSD Armor, an M.2 SSD heatsink which, as its name suggests, is designed to be compact. This should come in handy for cooling mid-thru-performance segment drives that lack heatsinks, or for making them fit for use with PlayStation 5. The Bitspower heatsink is a simple hunk of extruded anodized aluminium, along with a thermal pad, and elastic bands that hold the heatsink in place. The heatsink is 22.2 mm in width, 70 mm in length, and 5 mm in height (thickness). The company didn't reveal pricing information.

Thermalright Rolls Out HR-10 2280, an M.2 SSD Heatsink

Thermalright today rolled out the HR-10 2280, a step up from the company's HR-09 2280 M.2 SSD heatsink from 2022. Like its predecessor, the HR-10 uses two 5 mm-thick nickel-plated copper heatpipes that make contact with an M.2-2280 SSD over a mirror-finish nickel-plated copper base-plate, but the heatpipes loop through a denser aluminium fin-stack with slats that maximize surface area for heat dissipation. There's also a die-cast metal top-plate. The HR-10 is a tiny bit heavier than the HR-09, weighing in at 85 g (versus 80 g, but with a more optimized design). The heatsink measures 23.7 mm x 90.3 mm x 43.8 mm (WxDxH). The company didn't reveal pricing.

ASRock Intros Blazing M.2 Gen 5 Fan-Heatsink

ASRock today introduced the Blazing M.2 Gen 5 Fan-Heatsink, an active cooling solution for M.2 Gen 5 SSDs, and meant to be paired with the company's Socket AM5 and LGA1700 motherboards that have Gen 5 M.2 slots. The cooler is a 5 cm-tall hunk of extruded aluminium with a 30 mm fan ventilating it at roughly 5 CFM. There are five types of these coolers, each suitable for a particular type of ASRock motherboards. These coolers have been out since December 2022 as inclusions in motherboards, however, ASRock released the types 3, 4, and 5 (from the table below) today. The cooler is said to significantly lower temperatures of SSD controllers, minimizing performance losses to thermal throttling. These coolers are expected to be priced around $30 a pop.

GELID Announces IceCap Pro M.2 SSD Cooler

Tech innovator GELID Solutions uncovers the new IceCap Pro M.2 SSD Cooling Kit as a product of the GELID Solutions GAMER product line. IceCap Pro is designed to increase performance, lengthen Storage life and keep your M.2 SSD cool. High-performance thermal pads, active PWM fan, enhanced Heat Pipe direct contact, a newly developed aluminium heatsink and secure mounting is what takes the IceCap to the Pro level.

All to ensure the M.2 Type SSD Controller and Memory ICs, optimum heat dissipation and a considerably reduced operating temperature are provided. It comes with a Heatsink Dimensions of 73 x 24 x 16.6 mm and weight of 56 g. It also includes a 20 mm PWM Fan with 12000 RPM for active cooling. GELID Solutions offers a 2 year warranty. "Keep your SSD icy cool and blazingly fast!!" said Gebhard Scherrer, Sales Director of GELID Solutions Ltd. IceCap Pro has a MSRP of USD 16.00 or Euro 16.00. For more information visit GELID Solutions.

Noctua Confirms AM5 Heatsink Compatibility and Announces Free-of-charge Upgrades for Low-profile Coolers and Older Heatsink Models

Noctua today confirmed that all its CPU coolers and mounting-kits that support AMD AM4 also support the upcoming AM5 socket, except the NH-L9a-AM4 low-profile cooler and the NM-AM4-L9aL9i mounting-kit. For the latter, Noctua announced the new NM-AM5-L9aL9i kit that will be available free-of-charge from end of October. Mounting upgrade kits for older heatsink models that do not yet support AM4 will also be provided to customers at no additional cost.

"We have offered free-of-charge mounting upgrade kits to our customers ever since AMD introduced AM2 in 2006, and we're proudly continuing this tradition with the upcoming Ryzen 7000 series processors and their new AM5 socket", says Roland Mossig (Noctua CEO). "While all our current multi-socket coolers already support AM5 out of the box and don't require any updates, customers will be able to upgrade the NH-L9a as well as most older coolers at no additional cost, so even 15-year-old coolers can be used on the latest processors!"

Thermalright Intros HR-09 2280 Pro, a Humongous M.2 SSD Heatsink

We saw such a contraption taking shape for a while now, as M.2 NVMe SSD transfer-rates increase, and controller thermal-throttling begin to significantly impact performance. The new HR-09 2280 Pro by Thermalright is a humongous heatsink designed for SSDs in the M.2-2280 form-factor. Its design involves a nickel-plated copper base-plate, from which two 6 mm heat pipes convey heat through an aluminium fin-stack that's 74 mm tall. 24 mm wide, and 86 mm in length; weighing 90 g. The heatsink does not appear to have latches for fans, nor are any fan-clips included; but one can improvise clips for a 60 mm fan. The company developed a smaller version of this, called simply the HR-09 2280. This one uses a single 6 mm-thick heat-pipe, and its fin-stack is just 48 mm tall; with a total weight of 80 g. The company didn't reveal pricing.

SilverStone Intros TP06 PlayStation 5 M.2 NVMe SSD Heatsink and Cover

SilverStone today introduced the TP06, an M.2 NVMe SSD heatsink and cover for the PlayStation 5 system. The heatsink is designed for SSDs in the M.2-2280 form-factor that lack heatsinks, and is shaped to double up as a cover for the M.2 NVMe drive bay of the PlayStation 5. The heatsink is a 67.5 gram chunk of aluminium with a solid surface making contact with the drive, and ridges on the other side that dissipate heat. Besides the heatsink, the package includes a thermal pad, screws tested for compatibility with the PS5, and a screwdriver. The company didn't reveal pricing.

Samsung 980 PRO SSD Finally Gets a Stock Heatsink Option

Samsung's flagship client M.2 NVMe SSD, the 980 PRO, finally has a stock heatsink in new SKUs. Its design calls for what appears to be an aluminium monoblock with ridges for fins that join at the top. This heatsink is held in place by a metal shroud that covers the sides and back of the drive. The drive comes with its own retail SKUs and name—"980 PRO with Heatsink," much like how Western Digital segregates SKUs with or without heatsinks for its flagship WD Black SN850 drives. Retail channel availability of these variants remains to be seen, as The Verge reports that these drives will be sold as PlayStation 5-compatible drives. When they come out on October 29, the 1 TB variant is expected to be priced at $250, with the 2 TB variant going for $450.

be quiet! Announces Pure Rock Slim 2 CPU Cooler and MC1 Series M.2 SSD Heatsinks

be quiet!, market leader for PC power supplies in Germany since 2007, is expanding its portfolio with the revised Pure Rock Slim 2 CPU cooler and the MC1 and MC1 Pro SSD coolers suitable for M.2 2280 modules. With its reliable and quiet 92-millimeter Pure Wings 2 PWM fan and three 6 mm heat pipes, the Pure Rock Slim 2 can reliably dissipate waste heat of up to 130 W TDP. Thanks to its small dimensions the cooler is especially suitable for cases with limited space, while compatibility with AMD sockets has been improved over its predecessor. The new MC1 and MC1 Pro M.2 coolers reliably prevent modern SSDs from throttling due to excessive temperatures. Both models are equally suitable for single- or double-sided modules and feature an elegant black design that perfectly fits into any hardware layout.

The new be quiet! Pure Rock Slim 2 is a processor cooler with compact dimensions that dissipates waste heat of up to 130 watts thanks to its sophisticated design. With its optimized mounting system, the compact tower cooler's installation is child's play, even in tight spaces, and makes airflow-aligned installation on AMD sockets even easier. The single-tower cooler features a single Pure Wings 2 92 mm PWM fan. Thanks to its airflow-optimized fan blades this ensures that the cooler does not get louder than 25.4 dB(A) during operation.

GELID Unveils the Lumen RAM Heatsinks with RGB Lighting

GELID Lumen offers an easy way of adding RGB into your PC. It features the double-side vest heatsink to enhance DRAM cooling and the RGB module with a standard 3-Pin Fan connector that can be attached to any motherboard. The RGB functions are fully automatic and don't require external hardware or software to set lighting modes.

Made of high-grade components, Lumen supports all types and form-factors of DDR2/DDR3/DDR4 RAM modules designed for desktops. It ensures fast installation and perfectly fits high-performance DRAM to boost overclocking capabilities and energize your gaming rig with spectacular RGB lighting.

Noctua Readies High-Performance Fanless Heatsink Building on 2019 Prototype

Noctua is reportedly working on a high-performance fanless CPU cooler building on a 2019 prototype that was exhibited at last year's Computex. The final product should launch within 2020, according to an Overclock3D report. As of now there's no word on whether the said cooler will look identical to last year's prototype, but it provides a long list of capabilities that Noctua could build on. For starters, last year's prototype was capable of handling 120 W TDP in PC cases with good natural ventilation, and up to 180 W in cases with quiet fans. The company used a Core i9-9900K in a variety of workloads as a proof of the heatsink's capabilities. The prototype heatsink was also shown offering decent amount of clearance with the motherboard's memory- and VRM areas. Its only downside was the 1.5 kg weight.

Arctic Unveils the Freezer 7 X CPU Cooler

ARCTIC's long-running CPU cooler gets a worthy successor. It feels like the end of an era: the Freezer 7 Pro has long been one of our most loyal companions, and even though it wasn't a high-performance beast, it was known and loved by countless customers around the world. But after more than 10 years together, it's time to say farewell.

Out with the old, in with the new. With the new Freezer 7 X, we're able to present a successor that not only builds upon the success of its renowned predecessor - it outshines it. The Freezer 7 X reaps the benefits of an improved heatsink design along with a reworked heat pipe layout. In conjunction with the fan, which is optimized for high static pressure, the ARCTIC Freezer 7 X sets new standards in cooling. Compared to its predecessor, a performance increase of almost 10 % could be tested — and at a price that has been driven down by optimized and more efficient manufacturing processes.

Intel Recalls Boxed Xeon E-2274G Processors Due to Inadequate Stock Cooler Effectiveness

Intel issued a product change notification (PCN) dated November 13, calling for a recall of boxed Xeon E-2274G processors from customers and distributors. The boxed SKU of the E-2274G, which includes a stock cooling solution, has been marked as "discontinued" and "end of life." Intel is offering an E-2274G tray processor (chip-only) as replacement for the returned inventory. The cause for the recall is the cooling solution included in the boxed SKU, which has been found to be insufficient to cool the E-2274G, a 4-core/8-thread processor based on the 14 nm++ "Coffee Lake" microarchitecture, with a rated TDP of 88 W.

The E973708-003 fan-heatsink included with boxed Xeon E-2274G processors is supplied by Foxconn, and has been known to be bundled with Intel's entry-level client-segment processors, such as the Pentium Gold series and Core i3 series (chips with TDP typically rated 65 W or less). It features a thin, circular, all-aluminium heatsink, which lacks a copper core that certain other LGA115x-compatible stock coolers by Intel have. The heatsink makes contact with the CPU over pre-applied TIM on an aluminium surface, with spirally-projecting fins dissipating heat under the fan's airflow. It could be been an oversight bundling such an underpowered cooler with an 88 W TDP processor that's designed for the rigors of mission-critical use-cases such as workstations and small-business servers.
Heatsink images courtesy: AndyKingParts (Amazon seller)

Streacom Outs the UM2 Universal CPU Mount for its Fanless Heatsink Cases

Fanless mini-PC case maker Streacom introduced the UM2 Universal CPU Mount accessory, which lets you use the company's FC5, FC8, FC9 and FC10 cases with some of the newer CPU socket types. Streacom specializes in cases in which the body panels double up as a passive heatsink to cool the CPU, with a base and heatsinks transferring heat to the panels. The UM2 Universal CPU Mount uses oval shaped metal arms that you can orient across square (LGA115x), rectangular (AM4), or even trapezoid socket mount hole patterns, future-proofing these cases. The UM2 replaces the stock upper-mount your case comes with, hence its name. Streacom hasn't revealed pricing or availability.
